INTERCOM
OUTDOOR PANEL
VENUS
1. USER'S MANUAL
1.1 CALLING
In standby mode enter the Apartment number and push the
button. While the call is in
progress, the panel displays "CALLING". If you do not know the Apartment number, search
the resident name by using the
and
to scroll down/up in the name list then press
.
While the call is being directed "Calling" will be seen at the panel screen. With this note the
camera view will be visible at the Apartment to which the call is directed. Once the call is
answered "Connected" will be seen in the panel & the sides can hear other. The call will end
once the Apartment ends the call or the time set for the call is over.
1.2 BROWSING NAME LIST
If you do not know the number of the apartment you want to dial, pres (M). You can scroll up
and down with
and
. Once you find it, dial it on the keypad then press
.
1.3 OPENING DOOR WITH COMMON PIN (SUGGESTED)
In standby mode push (C) button."Enter the pin" will be seen at the panel screen.Enter the 4
digit pin. (C) button can be used to delete wrong entry. The door will open and "Door open"
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Venus and is the answer not in the manual?

Questions and answers

Summary of Contents for MAS Intercom Venus

  • Page 1 INTERCOM OUTDOOR PANEL VENUS 1. USER’S MANUAL 1.1 CALLING In standby mode enter the Apartment number and push the button. While the call is in progress, the panel displays “CALLING”. If you do not know the Apartment number, search the resident name by using the to scroll down/up in the name list then press While the call is being directed “Calling”...

  • Page 2: User Settings Menu

    will be visible at the panel screen once the correct pin is entered. If wrong pin is entered the warning “Wrong pin” will be seen at the panel screen with sound alert & the door will not open. The 4 digit pin should be entered in 15 sec. For your own safety it is suggested to change the default pin with the specific building pin defined.(Refer to 1.5.2 ) 1.4 OPENING DOOR WITH SPECIFIC PIN In standby mode push the...
  • Page 3 Enter User Settings Menu (Refer to 1.5), Press button on the menu. Enter the new welcome text by using above Table-1. Use to search through the letters. Use (C) button to correct wrong entries. Once the first line “Apartment name” is done press button to switch to 3-digit second line “Apartment number”.

  • Page 4: System Setting Menu

    number.All entries can be searched using . The maximum list of last entires stored is 64.. 1.5.7 Change Door Opening Time Enter User Settings Menu (Refer to 1.5). Press button on the menu : Change Door Opening Time. “Enter the door opening time” will be visible on the panel screen together with default door opening time of 1 sec.
  • Page 5 1.6.1 Change number of apartments Enter System Settings Menu (Refer to 1.6). Press button on the menu: Change number of Apartments. “Enter Apartment Number” will be visibile at the panel screen.Enter the Apartment number using the panel than press button.”Saving” will be visible at the screen and the number of Apartments will be changed.
  • Page 6 pin is correctly entered. Enter the new 4 digit pin. Use (C) button to correct wrong entries. Once the new pin is written press button. “Saving” will be visible at the panel screen and the new pin is set. 1.6.9. Extra camera Enter System Settings Menu (Refer to 1.6).

  • Page 7: Technical Data

    TECHNICAL DATA Power consumption at standby mode : 3W (18V-170mA) (daylight)" Internal power" Calling mode : 4W(18V-220mA) (dark) " Internal power " Max.Apartment number : 999 Pin digit number Number of cards per apt (max) Total number of cards : 9 x 999 Saved last entries number max : 64 Call time...
