- Page 1 Atik GP User Manual Version 1.1 – July 2015...
-
Page 2: Table Of Contents
Contents 1. Introduction ......................3 1.1 Further information ..................3 2. Pack Contents ......................4 3. Getting to know your camera ................5 3.1 Camera Parts ....................5 3.2 Mounting options..................... 5 3.3 Sensor ....................... 6 3.4 Analog to Digital Converter (ADC) ..............6 3.5 Power Consumption .................. -
Page 3: Introduction
1. Introduction Congratulations on your purchase of an Atik GP camera. This manual will help you get the most out of your Atik camera so please take the time to read it thoroughly and you'll soon be ready to discover new worlds. -
Page 4: Pack Contents
2. Pack Contents This pack includes: 1. Atik GP camera 2. CD with software and manuals 3. Quickstart guide 4. 1.8m MiniUSB cable Page 4... -
Page 5: Getting To Know Your Camera
1 – High-Speed MiniUSB 2.0 port 2 – Atik GP camera body 3 – Removable 1.25” adapter 3.2 Mounting options The Atik GP has M42x0.75 (T-thread) in the front. It permits the usage of any T- thread compatible accessory. Page 5... -
Page 6: Sensor
3.5 Power Consumption Since the Atik GP is USB powered, it is important to keep the camera on its own USB port. If a hub is needed, make sure you use an active one, with its own power source. -
Page 7: Technical Information Summary
4. Technical Information Summary Image sensor Sony ICX445 Resolution 1296x964 Pixel size (um) 3,75x3,75 12bit Readout noise (Typ.) Cooling Delta Passive Regulated cooler Water assist Maximum exposure Minimum exposure 0,001s Maximum Frame Rate 30 fps PC Interface USB2 Power requirements USB powered Backfocus distance ±0.5... -
Page 8: Declaration Of Conformity
5. Declaration of Conformity EU Declaration of Conformity This product carries the CE Mark in accordance with the related European Directive. CE Marking is the responsibility of: Perseu, SA R. Dr. Agostinho Neto, 1D 2690-576 Sta Iria da Azoia Portugal Critical Applications This product is not designed for any “critical applications”. -
Page 9: Servicing And Repairs
This means that Atik Cameras will repair or replace the equipment at its sole option, at no charge to the purchaser for parts or for labour, if the fault is reported within the guarantee period, provided however that Atik Cameras is able to duplicate the defect or problem at its facilities.
