Page 1: User Manual
Wireless Network Camera User Manual CIPCAM720PTIWL,CIPCAM720OD,CIPCAM720ODWDR,CIPDC AM720OD V1.0... - Page 2 Default DEFAULT SETTINGS IP Address 192.168.1.58 User/Password admin/123456 Notice 1、 Installation Environment Keep away from the places for high-temperature, heat source and direct sunlight; Keep away from water and if wet, cut off the power immediately. Avoid using in a damp environment; the reference range for operation humidity is below 85%RH.
-
Page 3: Table Of Contents
Initialize setting ......................21 3.5.4. System Log ........................21 PRODUCT FAMILY FOR SMARTP2P CAMERA ..............22 4.1. HD WDR CIPCAM720ODWDR ..........22 WATERPROOF CAMERA FOR 4.2. HD PTZ C CIPCAM720PTIWL ................22 AMERA FOR 4.3. HD W CIPDCAM720OD ..........23 UTDOOR ATERPROOF CAMERA... - Page 4 4.4. HD W CIPCAM720OD ................. 23 ATERPROOF AMERA FAQ ............................... 24...
-
Page 5: Product Introduction
1. Product introduction Main features: Monitor your home or office from anywhere in the world Built-in Infrared LEDs for night viewing Supports motion detection and event notification via e-mail or FTP Digital input/output (1DI/1DO) for sensor and alarm ... - Page 6 Insert attached CD to computer driver, double click “H&MSearch_en.exe” in the CD, will pop up the interface as figure 2, please operate as the following steps: Figure 2 Click “Search”（Please make sure your firewall will not block up the item to be searched）...
- Page 7 Figure 3 Notice: Need to download ActiveX when first use, click “download ActiveX( when first use)” in figure 3, will display prompt as figure 4, click ‘run’ will download and install the ActiveX automatically. Figure 4 Tips: You can hold on reset button on the camera for 10 seconds to restore factory default if you forget user name and password, or not sure the device parameters.
- Page 8 Status bar Figure 4-1 ① Display connection status; ② Display record status: if click “Record”, it will show “REC” which stands for recording; click record button again, it will stop; ③ Zoom out, zoom in and restore digital zoom; ④ Set saving file path: set the location for recording and capturing file storage; ⑤...
-
Page 9: View Video By Wifi Connection In Lan
set. Snap /record / SD card/playback Click “Snap” button, to save the picture to the specified file. Click “Record” button to start record. Click again to stop record. Click “Check TF/SD card” can browse the files in the SD card (If the SD card already inside the camera), you can select file to download it;... -
Page 10: View Video In Internet
Note: The camera will automatically stop the function when the matching is unsuccessful after continuing 50 seconds. Due to different kinds of the router, we don’t sure our camera can be connected to all routers successfully. 2.4. View video in internet You should connect your internal network to the internet first and configure port forwarding, consult your router’s manual for further details, as figure 6. -
Page 11: View Video By Pc Client Software
Choose “Add custom Service” ; Input IP camera http port; Input LAN IP Address of the camera, click “Apply” (port number and IP address as you set in figure 2） After finishing the port forwarding, you can use WAN IP address of router and http port of camera to visit the camera by remote computer as figure 6. -
Page 12: Other Common Software
In Mac computer, the Quicktime is installed by default, so the user simply accesses setting tool folder at application folder and run the command program, enter command by command line mode: qtdefaults write TransportSettings HTTP 80 And then run the Safari browser to view the video. Note: Please select the G.711 audio code format for hearing sound in Quicktime plug-in. -
Page 13: Video Parameters
3.1.1. Video parameters Figure 10 JPEG stream is for some views by non windows platform, for example, click ‘mobile view’ in first page, it will transmit JPEG stream actually. 3.1.2. Audio parameters... -
Page 14: Image Parameters
Figure 11 The camera supports G.711 and G.726 audio encoding format. The sound of the G.711 is better, but it occupies more bandwidth. If you click “On” of the audio capture, so it will transmit audio in corresponding video stream. Please open the audio here, should you hear the sound when clicking audio play button in figure 4-1. -
Page 15: Web Setting
3.2. Web setting 3.2.1. Basic web setting Figure 13 The cameras support RTSP protocol, if select “on” of “RTSP authority verification”, you need to enter user name and password when invoke video by RTSP protocol. 3.2.2. WIFI setting Please refer to chapter 2.3. 3.2.3. -
Page 16: Onvif Setting
Figure 15 Notice: Using the third party DDNS, if the http port is not 80, the port number should be adding to the domain name with colon. Example: http://mydomain.dyndns.org:81. 3.2.4. ONVIF setting Figure 16 The camera supports ONVIF protocol, so it can be interconnected with other factory camera with ONVIF. -
Page 17: Alarm Mode Setting
you can set up detect window here, tick a window, the corresponding green frame of motion detection window is displayed, you can tick four windows maximum for motion detection area as below. Figure 18 Please click “apply” after finishing the settings, and motion detection takes effect. The higher value, the higher sensitivity. -
Page 18: Alarm Time Setting
3.3.4. Alarm time setting Click SYSTEM SET->> ALARM->>Schedule to access it. Figure 20 The device will trigger the alarm only during the scheduled time period, you can select the scheduled time according to your request. Example of figure 20, set armed time from Mon 8:30 to 9:30, you only need to click the corresponding time block to set them, the time block will become green when you selected. -
Page 19: Auto Capture Setting
3.4.2. Auto Capture Setting Click SYSTEM SET->>ADVANCED->> Auto Capture to access it. Figure 22 Tick “Save Images to the TF/SD card”, the snap pictures will be stored into SD card during the setting time. 3.4.3. Timer recording Click SYSTEM SET->>ADVANCED->> Record to TF/SD to access it. Figure 23 For example, set up recording time from Mon 8:30 to 9:30 as figure 23. -
Page 20: Ftp Setting
Figure 24 The SMTP server name: It is mailbox server, for example of SOHU mailbox, it is “smtp.sohu.com”. Please fill all blanks which we filled above in figure 24 as example. Otherwise, the settings will fail. Please click “Test” to test if the E-mail setting is successful. 3.4.5. -
Page 21: Multiple Settings
3.4.6. Multiple settings Click SYSTEM SET->>ADVANCED->>Multiple Settings to access it. Figure 26 Please set multiple devices here first to view 4 or 9 split screen at chapter 3.1 browse interface. 3.5. System setting 3.5.1. Device information Click SYSTEM SET->>SYSTEM->>Device Information to access it. Figure 27 SD status shows the free capacity if SD card is installed. -
Page 22: Date And Time Setting
before purchasing the SD Card. 3.5.2. Date and time setting Click SYSTEM SET->>SYSTEM->>Time Settings to access it. Figure 28 Example of figure 28, please select the time zone at first and then select a NTP server and obtain time from network time server. 3.5.3. -
Page 23: Product Family For Smartp2P Camera
Figure 30 4. Product family for SmartP2P camera 4.1. HD WDR waterproof camera for CIPCAM720ODWDR Figure 35 4.2. HD PTZ Camera for CIPCAM720PTIWL Figure 36... -
Page 24: Outdoor Hd Waterproof Ptz Camera Cipdcam720Od
4.3. Outdoor HD Waterproof PTZ camera CIPDCAM720OD Figure 37 4.4. HD Waterproof Camera CIPCAM720OD Figure 39... - Page 25 5. FAQ 1. Does this device support multi-window viewing? Yes, it supports multi-window view. 2. Does this product support Wi-Fi connection? Yes. As long as the product is placed within 30 feet/10 meters of the router, and has correct settings, it can be connected using Wi-Fi. 3.
- Page 26 Statement： 1. This manual may be different with your using camera, if you have any questions of the manual, please contact our technical support. 2. This manual will be updated periodically; the company reserved the right without prior notice.
- Page 27 For complete DoC please visit http://www.conceptronic.net/download.php GPL License Agreement GPL may be included in this product, to view the GPL license agreement goes to http://download.conceptronic.net/GPL/GPL.pdf For GNU General Public License (GPL) related information, please visit http://www.conceptronic.net/download.php Enjoy the use of your Conceptronic IP Camera!
