Countryman E2 Earset User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
COUNTRYMAN
E2 EARSET

Advertisement

loading
Need help?

Need help?

Do you have a question about the E2 Earset and is the answer not in the manual?

Questions and answers

Related Manuals for Countryman E2 Earset

Summary of Contents for Countryman E2 Earset

  • Page 1 COUNTRYMAN E2 EARSET...
  • Page 2 We use innovative engineering to pack this great a sound into such a tiny mic. For this reason, getting the best results requires some simple techniques that might not be immediately intuitive. This booklet will help you get the most out of your E2 Earset.

  • Page 3: Table Of Contents

    Contents Handling the E2 Connecting E2 Snap-On Cables Custom Fitting the E2 Using Collar Clips Back Port Cleaning Procedure Specifications Declarations...

  • Page 4: Handling The E2

    Handling the E2 While the E2 Earset is designed for durability, moisture-resistance and flexibility, it is a high- precision instrument and we do suggest some basic precautions to prevent damage or sonic degradation: • Always use the E2 with its cap in place. The end...
  • Page 5 Handling the E2 (cont.) The E2’s earpiece and boom are constructed of an exceptionally flexible material which can be easily shaped to the wearer’s needs. To prevent damage to your Earset: • Avoid bending it over sharp angles (such as the ...

  • Page 6: Connecting E2 Snap-On Cables

    Connecting E2 Snap-On Cables The Earset cable is easy to remove and change, allowing you to swap transmitter types, switch colors, or replace damaged parts in the field. Exercise care in connecting and disconnecting the cable connector. • Always grasp the connectors near the outer ends of the rubber sleeves and pull the connectors straight apart.

  • Page 7: Custom Fitting The E2

    1/8” away from the face. Since every performer’s face is different, we’ve made it easy to custom fit the E2 Earset: 1. Curve the boom so that it will rest against your face when worn.
  • Page 8 Custom Fitting the E2 (cont.) 2. Put the loop over the ear with the base behind the earlobe and the capsule toward the mouth.
  • Page 9 Custom Fitting the E2 (cont.) 3. Tip the mic to point toward the mouth. The mic should be barely visible, resting about 1/8” from the face mid cheek or completely hidden by the hair.
  • Page 10 Custom Fitting the E2 (cont.) 4. Always use the collar clip to reduce clothing and cable noise. Leave enough slack in the cable such that the user can turn his/her head to both sides without tugging on the clip. Use the windscreen outdoors.

  • Page 11: Using Collar Clips

    Using Collar Clips The Earset comes with two collar clips: one black and one white. These clips prevent movement in the cable from dislodging the Earset and can reduce cable noise. They are specifically designed to match the diameter of your E2 cable. Gently pull the cable down into the opening to attach the clip.

  • Page 12: Back Port Cleaning Procedure

    Back Port Cleaning Procedure This procedure is rarely necessary, but it may help if frequency response and directionality have deteriorated because the back ports on the element are contaminated with dust or makeup. Make sure your hands, the work area, the Earset’s boom and end cap are clean. Take a 6”...

  • Page 13: Specifications

    Specifications Frequency Response: 20Hz to 20kHz The E2 Earset is available in two sensitivities to 500uA Operating Current: match a wide range of applications: 1 to 2 Volts Operating Voltage: Model E2W5 for general speaking 0.07oz (2g) Weight: Sensitivity: 3.0 mV/Pascal...
  • Page 14 Typical Directional Lav Specifications (cont.) 10k 20k Frequency (Hz) Frequency Response 1 kHz Polar Response 0° 30° 330° Countryman E2 60° 300° 90° 270° Typical Directional Lav 120° 240° Freq (Hz) 10k 20k 150° 210° 180° Countryman E2 Typical Directional Lav...

  • Page 15: Declarations

    Declarations We, Countryman Associates Inc., declare under our sole responsibility that the following products: Earset Microphone models E2*, E6*, E6D*, E6ID*, WCE6D*, WCE6ID* To which this declaration relates are in compliance with the essential requirements of: RoHS 2004/108/EC EN 55103-1...
  • Page 16 Countryman Associates, Inc. 195 Constitution Drive, Menlo Park, CA 94025 Phone: (800) 669-1422 or (650) 364-9988 Fax: (650) 364-2794 Email: sales@countryman.com Web: www.countryman.com...
