- Page 1 INSTRUCTION MANUAL ROOF MOUNT LCD COLOR TV RECEIVER TV-1836TFT DEAR CUSTOMER Congratulations for your purchase! Please read this manual carefully, and keep it for future reference. If you need extra support, please write to info@premiermundo.com...
- Page 2 This sign means that there are important instructions of operation and handling in the manual that comes with this Device. PREMIER CUSTOMER SERVICE Venezuela: 0800 ELECTRIC (353-2874) Colombia:...
-
Page 3: Table Of Contents
Table of Contents 1.Precautions 2.Accessories 3.Appearance 4.Remote Controller Operation 5.Basic Installation Methods 6.Basic Operation Methods 7.Menu Operation 7.1 Picture 7.2 Option 7.3 Clock 7.4 System 7.5 Preset 8.Before you request for repair 9.Technical Parameters Page 2... -
Page 4: Precautions
1. Precautions Storage and Keeping Keep this machine Never use this away from too hot machine near or too cold places. bathtub, The storage washbasin, and temperature of this kitchen, etc places machine is with water or at 20~60 , the damp basement, application swimming pool or... -
Page 5: Accessories
Operation Precautions 1.Only the attached automobile adapter (12V) is applicable. 2.For the sake of safety, when you are not intended to use the display, please plug off the automobile adapter. Warning! 1. For the sake of safety for yourself and others, please don't watch or turn on the TV set during driving. -
Page 6: Appearance
3. Appearance TFT-LCD screen Loudspeaker Volume increases, analog Channel decreases, option quantity selection + selection Volume decreases, analog Channel increases, option selection quantity selection - Remote receiving window Standby switch AV / TV Shift Roof Mount Menu Power indicator power on/off switch Audio / Video / +12V power supply / antenna /... -
Page 7: Remote Controller Operation
Calendar Return AV / TV Shift Horizontal Vertical Auto Search TV-1836TFT LCD display mode Caution 1) Please align the remote controller with the infrared-receiving window on TV set in operation. 2) Never oppress, drop, wet or disassembly the remote controller. - Page 8 (Channel selection) Press CH , the number of TV channel increases. Press CH , the number of TV channel decreases. VOL - / + (Volume adjust) Press VOL - , the volume of TV set decreases. Press VOL + , the volume of TV set increases. PICT (Mode): By pressing this button, users can realize the five picture statuses of Personal,Standard, Soft, Vivid and light.
-
Page 9: Basic Installation Methods
5. Basic Installation Methods (1) Fix the iron piece onto the TV top cover with attached screws as per illustration. (2) Perform connection as per car-backing rearview diagram. (3) Fix the TV top cover onto the automobile ceiling with attached screws. 6. - Page 10 (2)Connection Method of AV Conversion Line: Hold the AV conversion line, align the side marked with on the plug of conversion line with the side marked with on the plug of AV conversion line of TV set, and just insert. 1.
- Page 11 Basic TV set operation methods (1) Connect with power supply and turn on power switch. (2) Pull out telescopic antenna. (3) Press Channel Selection to choose the desired channel. (4) Adjust the sound volume of the TV signal. Volume Volume Menu AV / TV Shift decreases...
-
Page 12: Menu Operation
7. Menu Operation Press MENU to display options as follows: PICTURE OPTION CLOCK SYSTEM PRESET 7.1. Picture Contrast, bright, color, Sharp and TINT displays on the screen as illustrated below: Picture Contrast Bright Color Sharp Select Adjust / CH Select VOL + / VOL - : Adjust Press CH+ or CH- to select the item Contrast. - Page 13 Press VOL - / VOL + can realize selection of English, German, French, Spanish, Portuguese, Italian, Dutch, Russian, Chinese and Japanese OSD menu language. Press CH+ or CH- to select the item Calendar: Option Language English Calendar Game Select Adjust / CH Select VOL + / VOL - : Adjust...
-
Page 14: Clock
7.3. Clock Time, ON Time, OFF Time, Attention, Bespoke Time, and Position will display on the screen as illustrated below: Clock Time - - : - - ON Time - - : - - OFF Time - - : - - Attention - - : - - Bespoke Time... - Page 15 System Color system AUTO Sound system DK 6.5M Blue back Horizontal Vertical Zoom 16:9 / CH Select VOL + / VOL - : Adjust Then press VOL- or VOL+ to revolve the screen in the order of AUTO, PAL , NTSC and SECAM. Please choose carefully this system correctly. Otherwise, it may cause achromatic or inferior color.
- Page 16 Press CH- or CH+ to select the item Blue back: System Color system AUTO Sound system DK 6.5M Blue back Horizontal Vertical Zoom 16:9 / CH Select VOL + / VOL - : Adjust To set on or off of the Blue back by pressing VOL-/VOL+ key under no signal. Press CH-or CH+ to select the item Horizontal: System Color system...
-
Page 17: Preset
Press CH-or CH+ to select the item Zoom: System Color system AUTO Sound system DK 6.5M Blue back Horizontal Vertical Zoom 16:9 / CH Select VOL + / VOL - : Adjust Press VOL - / VOL + can choice LCD screen display mode: 16:9 mode and 4:3 mode. - Page 18 Press CH- or CH+ to select the item Auto Search: Preset Position Remember Band Swap Fine Search Auto Search / CH Select VOL + / VOL - : Adjust Press VOL- or VOL+ to start Auto Search, and put into automatic memory and storage upon completion of Auto Search.
-
Page 19: Before You Request For Repair
8. Before you request for repair Phenomena below are not necessary mean failure with TV set. Please check off per following methods before you request for repair. Phenomena Possible Causes Improper connection with automobile adapter. No picture, no sound Use of unauthorized power supply. Power Switch is on OFF position. -
Page 20: Technical Parameters
9. Technical Parameters Product Name: LCD Color TV Receiver Display Device: Color TFT-LCD Receiving Frequency range: 48.25MHZ~863.25MHZ Sound System: DK Screen Size: 7 inches Audio Output: 0.3W (Max) Loudspeaker: One 4.0 cm round loudspeakers Connecting Terminal: AV power supply jack: (1. - Page 21 Warning This operation instruction is only intended for reference. No further notice is available to any modification of all information contained therein. Warning No repairable components exist in the machine. Don't try to dismantle and improve the TV set, and the high voltage in the machine may cause danger.
