Sven MHL 11pin 0.2m User Manual

MHL 11pin
0.2m
MHL Adapter
USER'S MANUAL

COPYRIGHT

© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted efforts to make this Manual more exact, some discrep-
ancies may occur. The information in this Manual is given on «as is» terms.
The author and the publisher do not bear any liability to a person or an orga-
nization for loss or damage which has arisen from the information contained
in this Manual.

PURPOSE

MHL adapter will provide watching photos and videos with Full HD 1080p
quality with surrounding sound from your mobile device on a TV-set or moni-
tor with the simultaneous mobile device charging.

SPECIAL FEATURES

• Compatible with MHL-enabled mobile devices with Micro USB 11pin con-
nector
• Full HD 1080p image transmission

CONNECTION AND OPERATION

Note. Before using check the availability of MHL function in your mo-
bile device.
1. Connect HDMI cable (not included) to MHL adapter and your TV-set/mo-
nitor (see connection diagram).
2. Connect a charger (from the package of your mobile device) to MHL
adapter.
Charger
Micro USB
Mains
3
220 V
2
MHL adapter
Micro USB
4
Mobile
device
Connection diagram
HDMI cable
1
TV-set/
monitor
