Sineoji PL1800E User Manual

1800mbps gigabit homeplug av2 mimo
Hide thumbs
Table of Contents

Advertisement

Quick Links

1800Mbps Gigabit HomePlug AV2 MIMO
PL1800E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL1800E and is the answer not in the manual?

Questions and answers

Summary of Contents for Sineoji PL1800E

  • Page 1 1800Mbps Gigabit HomePlug AV2 MIMO PL1800E...
  • Page 2 Safety This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment is in compliance with the requirements of the following regulations: CE Mark, 89/336/EEC RoHS This product is RoHS compliant.

  • Page 3: Table Of Contents

    Table of Contents HomePlug Powerline ........................... 4 Introduction..............................4 System Diagram ............................. 4 Casing Details ..............................5 Front Casing ......................................5 Status Lights ......................................5 Bottom Casing ......................................6 Security / Reset Button ................................... 6 Initial Setup ..............................6 Connect the HomePlug AV2 Ethernet Bridge to a Computer or Modem/Router ..................6 Individual HomePlug AV2 Network Setup (Optional) .................

  • Page 4: Homeplug Powerline

    HD movies and music, play online multi-player games and much more. Note: HomePlug AV2 Ethernet Bridge needs to pair with at least one other HomePlug AV2 compatible device such as this one in order to create a working system. Modem | Router PL1800E Powerline Internet PL1800E...

  • Page 5: Casing Details

    1.3 Casing Details Front Casing The front casing contains 3 status lights: Power, PLC Link, and Ethernet Link. Ethernet PLC Link Light Power Status Lights Power On: This HomePlug Ethernet Bridge is receiving electrical power Off: Power off Flashing Green ( 1 second ON, 4 second OFF ) : Device in standby mode PLC Link The PLC (Powerline) Link light will indicate the overall speed of your network with 3 colors: Red: Minimum connection indicates weak signal and slower network speed: less than 50Mbps...

  • Page 6: Bottom Casing

    Bottom Casing The bottom casing contains a recessed Reset Button, a Security Button, and an Ethernet Port. Security / Reset Button Ethernet Port Security / Reset Button This button has dual functions : Security and Reset Security This function is designed to generate an individual HomePlug AV2 network group under multiple nodes environment. Please refer to the optional Individual HomePlug AV2 Network Setup section below for more details.

  • Page 7: Individual Homeplug Av2 Network Setup (Optional)

    2 Individual HomePlug AV2 Network Setup (Optional) All HomePlug AV2 Ethernet Bridges shi p with a default security key so they will automatically link to all other HomePlug AV2 Ethernet Bridges sharing the same electrical lines. If there are other HomePlug AV2 Ethernet Bridg- es in the building (such as in an office or apartment building), you may want to create your own individual HomePlug AV2 network group so other HomePlug AV2 Ethernet Bridges cannot connect to your network.

  • Page 8: Adding Bridge C To Existing Network Ab (Network Abc)

    2.2 Adding Bridge C to existing Network AB (Network ABC) One unassociated Bridge C is added to an existing Network AB. The procedure is as follows: 8. Press and hold the Security button on Bridge C for 5~8 seconds, then release. Once released, the power light will flash.

  • Page 9: Troubleshooting And Disclaimer

    The procedure is as follows: 1. Press and hold the Security button on Bridge B for 10 seconds, then release. Once released, the Power light will flash. The password to Bridge B has just been erased and removes itself from Bridge A & C. 2.

  • Page 10: Specification

    FCC Class B / CE Mark Product carried a warranty of 3 years from the date of purchase. Warranty registration can be done via online at http://www.sineoji.com/support/product-registration. Ensure a copy of the proof of purchase is submitted online during the registration process.
