- Page 1 Patio Heaters OPERATOR'S MANUAL MH-0040-PM10 CAUTION RISK OF INJURY! READ ENTIRE MANUAL BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT PART OF THE HEATER AND MUST REMAIN WITH THIS UNIT! ® 247218 ©Copyright 2009, Mi-T-M Corporation® Propane Patio Heater Manual 37-1070-E/F/S-102114...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................3 IMPORTANT SAFETY INSTRUCTIONS....................4 PATIO HEATER FEATURES ........................7 FEATURES ............................7 HEATER SPECIFICATIONS ........................7 GENERAL SAFETY INFORMATION ......................8 IMPORTANT SAFETY INFORMATION .....................8 ASSEMBLY ..............................9 ASSEMBLING THE HEATER (PM10 BEFORE SERIAL #5450 1014 00001) ........9 ASSEMBLING THE HEATER (PM10 AFTER SERIAL #5450 1014 00001) ......10-11 OPERATION ............................12 LIGHTING INSTRUCTIONS ......................12 AFTER FIRST LIGHTING .......................12... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your new Mi-T-M® Patio Heater! You can be assured your Mi-T-M® Heater was constructed with the highest level of precision and accuracy. Each component has been rigor- ously tested by technicians to ensure the quality, endurance and performance of this heater. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Hazard Potential Consequence Prevention RISK OF EXPLOSION OR Serious injury may occur if Always operate heater in a well FIRE the heater air inlet or outlet is ventilated area free of flammable blocked. vapors, combustible dust, gases or other combustible materials. - Page 5 IMPORTANT SAFETY INSTRUCTIONS NEVER USE THE HEATER IN LOCATIONS WHICH CONTAIN PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT THINNERS, DUST PARTICLES, VOLATILE OR AIRBORNE COMBUSTIBLES, OR ANY UNKNOWN CHEMICALS. WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
- Page 6 WARNING THE FOLLOWING PAGES CONTAIN OPERATING AND MAINTENANCE INSTRUCTIONS. DO NOT ATTEMPT TO OPERATE THIS PATIO HEATER UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MANNER!
-
Page 7: Patio Heater Features
Base FEATURES The Propane Patio Heater comes with safety features including anti-tilt switch and auto shutoff switch. The features of the Propane Patio Heater is shown. HEATER SPECIFICATIONS Model MH-0040-PM10 Rating BTU/Hr 40,000 Fuel Propane LP Supply Pressure 250 PSI max Manifold Pressure 11"... -
Page 8: General Safety Information
GENERAL SAFETY INFORMATION WARNING: IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE AND OR EXPLOSION. IMPORTANT: Read this User's Manual carefully and completely before attempting to operate or service this heater. Improper use of the heater can cause serious injury or death from fire and explosion. Every possible circumstance that may involve a hazard cannot be anticipated. -
Page 9: Assembly
ASSEMBLY FOR MH-0040-PM10 (BEFORE SERIAL # 5450 1014 00001) ASSEMBLING THE HEATER Note: Tools required: 7/16" Wrench, 3/8" Open End Wrench, Adjustable opening Wrench 8" long, Phillips screwdriver 1. Attach post to base assembly. Attach the Post to the post mounts using M5 x 12 Bolts (6 pcs). -
Page 10: Assembling The Heater (Pm10 After Serial #5450 1014 00001)
ASSEMBLY FOR MH-0040-PM10 (AFTER SERIAL # 5450 1014 00001) ASSEMBLING THE HEATER Note: Tools required: 7/16" Wrench, 3/8" Open End Wrench, Adjustable opening Wrench 8" long, Phillips screwdriver 1. Attach the wheel assembly with 2x 6mm washers / 2x 6mm lock washers / 2x M6x20 bolts. - Page 11 ASSEMBLY FOR MH-0040-PM10 (AFTER SERIAL # 5450 1014 00001) 7. Fill the base with sand as a counter weight. Fill the sand into the hole untill full. 8. Install cylinder guard to the base. 9. Connect gas line to LP cylinder. Attach Gas Hose to the Regulator with 3/8”...
-
Page 12: Operation
OPERATION Mi-T-M Propane Patio Heaters are designed for the heating of outdoor patios, decks, spas, pool and open working areas. WARNING: BEFORE TURNING GAS SUPPLY ON YOUR PROPANE PATIO HEATER WAS DESIGNED AND APPROVED FOR OUTDOOR USE ONLY. DO NOT USE THIS HEATER INSIDE A BUILDING, OR ANY ENCLOSED AREA. -
Page 13: Relighting
OPERATION WHEN HEATER IS ON The Emitter Screen will become bright red due to the intense heat. Burner may display tongues of blue flame. These flames should not be yellow or produce thick black smoke, which indicates that there is an obstruction of airflow through the burners. -
Page 14: Maintenance
MAINTENANCE To enjoy years of performance from your heater be sure to perform the following maintenance activities on a regular basis: 1. The flame pattern at the Emitter Screen should be visually checked whenever the heater is operated. Normally the burner flame is blue, but little yellow flame is acceptable. 2. -
Page 15: Troubleshooting
TROUBLESHOOTING SYMPTOM PROBABLE CAUSE REMEDY Burner will not light. 1. Pressure is low. 1. LP cylinder is near empty. Refill LP cylinder. 2. Orifice blocked. 2. Remove and clean and replace if needed. 3. Control valve is not ON. 3. Turn valve to ON. 4. -
Page 16: Statement Of Warranty
Upon receipt of damaged item, Mi-T-M will examine the item and determine if defective. Mi- T-M will repair or replace and return the item, freight pre-paid. If Mi-T-M finds the item to be in normal operating condition, or not defective, the item will be returned freight collect.
