aQuila Track S101 User Manual

Vehicle tracking and fleet monitoring solution

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Vehicle Tracking and Fleet Monitoring Solutions

User Manual - aQuila Track S101

No. 3420, 1

Floor, Service Road, RPC Layout (West), Vijayanagar, Bangalore – 560040

Phone: +91-80-23180601 | Email: customercare@itriangle.in

URL: www.itriangle.in | Tracking: www.aquilatrack.com

Foreword

Dear Customer,

Thank you for purchasing aQuiLa

Track.

Table of Contents

Need help?

Do you have a question about the S101 and is the answer not in the manual?

Questions and answers

Summary of Contents for aQuila Track S101

Page 1 Vehicle Tracking and Fleet Monitoring Solutions User Manual - aQuila Track S101 No. 3420, 1 Floor, Service Road, RPC Layout (West), Vijayanagar, Bangalore – 560040 Phone: +91-80-23180601 | Email: customercare@itriangle.in URL: www.itriangle.in | Tracking: www.aquilatrack.com Foreword Dear Customer, Thank you for purchasing aQuiLa...
Page 2 Track S101 is a compact, easy to install and highly reliable Vehicle Tracking and Fleet Management System that increases the efficiency, productivity and safety, through real-time & precise tracking of position and status of your vehicle. aQuiLa Track S101 is developed using Global Positioning System (GPS), coupled with Google Maps and GSM Mobile...
Page 3: Copyright Notice
Copyright Notice: The information disclosed herein is the exclusive property of iTriangle Infotech Pvt. Ltd and no part of this document can be reproduced or transmitted in any form or by any means including electronic storage, reproduction, and/or execution without the prior written permission from iTriangle Infotech Pvt.
Page 4: Table Of Contents
How aQuila Track Hardware works? 1.8. aQuila Track Working Diagram 1.9. Device parts 1.10. Section 2: aQuila Track S101 Device Installation 1.11. Tools required for installation 1.12. Consumable material required for installation 1.13. Installation Steps 1.14. POWER CONNECTION – COMMERCIAL VEHICLES...
Page 5 1.15. POWER CONNECTION – PERSONAL 4 WHEELERS 1.16. CONNECTION TO IGNITION OUTPUT IN THE VEHICLE 1.17. FUEL WIRE CONNECTION AND CALIBRATION 1.18. PICTURE – DEVICE PLACEMENT IN CAR 1.19. PICTURE – DEVICE PLACEMENT IN TRUCK 1.20. PICTURE – DEVICE PLACEMENT IN 2 WHEELER 1.21.
Page 6: About This Document
This manual is designed to guide you through installation of aQuiLa Track S101device and trouble shooting of problems step-by-step. The manual is divided in to two sections. Section-1 covers the various features of S101 and Section-2 covers installation and trouble shooting.
Page 8: Section 1: Introduction To Aquilatrack S101
Track helps user to get data on different events of the vehicle, while on move as well as when stationary. It gives vital information like vehicle location, speed, date, time, distance and usage of selected in-vehicle gadgets and equipment like, Engine usage and Fuel.
Page 9 Reducing tracking interval increased the GPRS data usage and expenses. iTriangle will not be liable to pay any compensation and/or penalty for the increased expenses due to increase in GPRS usage aQuila TrackS101uses in-vehicle battery power source in the range of 9 – 32 V and works only on DC Power. It is built to take care of Spikes and Surges.
Page 10: Aquila Track Working Diagram
Track Working Diagram...
Page 11: Device Parts
Device parts USB Indicator GPS indicator Processor Indicator GSM indicator USB Port RESET switch On / Off Switch Connectors Red – Vehicle Battery 10. Yellow – Fuel 11. Black – Ground 12. Green – Ignition 13. Wiring kit 14. Fuse...
Page 12: Section 2: Aquila Track S101 Device Installation
Section 2: aQuila Track S101 Device Installation It is highly recommended that Installation of aQuila Track S101 and its accessories must be done by a trained technician only. All the material mentioned in this section are for indication purpose only...
Page 13: Tools Required For Installation
Tools required for installation Portable drilling machine for making holes (in case necessary to mount the device) A standard screwdriver set comprising cross/flat/Phillips screwdrivers of small/medium sizes and a poker. Choosing one with a magnetic head would be better. Pliers can be used as an auxiliary tool to pull out the power connectors, hold wires, etc Forceps can be used to pick up tiny screws and/or SIM card Rubber gloves can prevent you from being incised and suffering the static charge.
Page 14: Consumable Material Required For Installation
Micro USB Cable for uploading Configuration, Firmware, etc Glue Gun to seal any connectors Consumable material required for installation Cable ties for tying the wires together Self-adhesive cable tie mounts to hold the wire harness / wires in a line. Insulation tape to cover the electrical joints and protect open wires from short circuit Fevi kwik –...
Page 15: Installation Steps
Installation Steps Open the Box and check for contents as specified on the box Take the SIM card that you have purchased from a Mobile Operator Insert SIM card in any Mobile Phone to check, SIM card for Registration, Activation and GPRS connectivity If all parameters are found working, insert the SIM card in the holder as shown in the picture below in this document Switch ON internal Device Battery Connect device to vehicle battery / continuous power source in the vehicle as explained below in this document...
Page 16: Power Connection - Commercial Vehicles
5-10 minutes after connecting the device to the vehicle battery, all the 3 LEDs start to blink indicating that the device is communicating with the configured server POWER CONNECTION – COMMERCIAL VEHICLES MINI TRUCKS, TRUCKS, BUSES, MINI BUSES, TEMPO / FORCE TRAVELLER, GOODS AUTO, APE, ACE, AND ALL TYPES OF GOODS VEHICLES Remove the ignition key Run RED (+ve) and BLCK (-ve) wires from battery till the location of device placement.
Page 17: Connection To Ignition Output In The Vehicle
wire coming in to the ignition switch assembly. See if the metal conductor in the connector or wire connection point at the ignition switch is accessible, else remove the skin from each of the wire Firmly hold the +ve (RED) probe of the multimeter to the wire conductor and –ve (BLACK) probe of the multimeter to the GROUND point (- ve terminal of the vehicle battery OR any screw / bolt directly connected to metal body of the vehicle) Voltage at the +ve wire of the (incoming supply line) ignition should be matching to the battery voltage of the vehicle Check the Voltage at the Ignition input point at...
Page 18: Fuel Wire Connection And Calibration
Firmly hold the RED probe of the Multimeter at the skinned portion of each of the wire one-by-one and BLACK probe of the Multimeter to the GROUND (- ve terminal of the vehicle battery OR any screw / bolt directly connected to metal body of the vehicle) and measure the Voltage.
Page 19 –ve terminal of the vehicle battery Confirm that the device is tracking and ignition status changes in the aQuila Track Web Application Empty the tank to dry and measure the voltage and note the same...
Page 20 Calibrate Fuel Tank based on the capacity by filling Fuel at consistent regular steps as per below table: TANK RECOMMENDED CAPACITY FILLING STEPS Up to 30 ltr 1 ltr 30 - 80 ltr 2 ltr 80 - 150 ltr 5 ltr 150 and above 10 ltr Wait for 1 –...
Page 21: Picture - Device Placement In Car
PICTURE – DEVICE PLACEMENT IN CAR...
Page 22: Picture - Device Placement In Truck
PICTURE – DEVICE PLACEMENT IN TRUCK...
Page 23: Picture - Device Placement In 2 Wheeler
PICTURE – DEVICE PLACEMENT IN 2 WHEELER...
Page 24: How To Insert Sim Card In To The Device
How to insert SIM card in to the device...
Page 26: Troubleshooting
1. Remove SIM card from the device and check in a mobile for SIM registration 2. Check for GPRS connectivity If none of the above steps resolve any / all of the problems listed above, please contact aQuila Track Customer Care...
Page 27: Warranty Policy
Warranty Policy Limited Warranty iTriangle InfoTech Pvt. Ltd. warrants that this Vehicle tracking/fleet management device will be free from defects in materials and workmanship during the shelf life of the product, according to the following terms and conditions: 1. The limited warranty for the product extends for the first twelve (12) months beginning on the date of purchase of the device.
Page 28 neglect, abusive, accident, alteration, improper installation, Acts of God, spill of foods or liquids, maladjustments to customer controls or other acts which are beyond the responsibility of iTriangle, including deficiencies in consumable parts such as fuses and breakage or damage to antennas, unless caused directly by defects in materials or workmanship, and normal wear and tear of the product.
Page 29 b. If „a‟ above is not convenient, the consumer may also contact to the place of purchase for the location of the nearest authorized service center. c. The consumer shall arrange for the product to be delivered to the authorized service center. d.
Page 30: Contact Us
Contact Us: iTriangle Infotech Pvt. Ltd #3420, 1 Floor, Service Road RPC Layout (West) Vijayanagar Bangalore – 560040 Customer Care: Email: customercare@itriangle.in Phone: +919739008344...
