Summary of Contents for Mirasys N Series
- Page 2 Mirasys N™ series Network Video Recorder Quick Guide...
- Page 3 No part of this document may be reproduced for any purpose, even in part. TRADEMARKS Mirasys and Mirasys N are the trademarks of Mirasys Ltd. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 4: Table Of Contents
ONTENTS DEFAULT USER NAME AND PASSWORD ........1 BEFORE YOU BEGIN ............1 SYSTEM COMPONENTS ............1 INSTALLATION..............2 Removing previous software version ........2 Installing new software version .........2 Getting a license key .............3 Installing client programs ..........3 Setting the IP address to system configuration files ....4 CONFIGURATION .............. -
Page 6: Default User Name And Password
DEFAULT USER NAME AND PASSWORD User name: Admin Password: 0308 BEFORE YOU BEGIN This guide is an abbreviated version of the N series help document set. It includes the following topics to get you started: • Installing the NVR software • Adding IP cameras •... -
Page 7: Installation
Mirasys N Series INSTALLATION Removing previous software version If there is a previous version of the recorder installed, follow these steps: NOTE: Before removing the current software version, back up system and recorder setting in System Manager to be able to restore the settings should any problems occur. -
Page 8: Getting A License Key
For the license key, send the MAC address of the NVR and the serial number of the N series software to Mirasys. The serial number is on the cover of the DVMS Installation CD. -
Page 9: Setting The Ip Address To System Configuration Files
If the recorder is accessed locally, there is no need to set the address. CONFIGURATION Use the Mirasys N System Manager program to configure the system settings. Only users with administrator’s rights are allowed to change settings. Configuring the system To configure the system: Start System Manager. -
Page 10: Adding Cameras
Configuration Adding cameras To add IP cameras to the NVR: In the camera’s internal settings, give the camera a static IP address, a user name, and a password. See the camera manual for details. Start System Manager. Click the Recorders tab and double-click Hardware settings. On the Video tab, click Add. -
Page 11: Motion Detection Settings
Mirasys N Series Motion detection settings By default, video is recorded when the system detects motion in the camera scene. You can create custom motion detection masks for each camera on the Motion Detection tab. For example, if there is movement in the camera scene that you do not want to trigger recording, you can exclude those areas from motion detection. -
Page 12: Scheduler
Configuration Adaptive detection compares each image to a background image. The system learns the background image and the movement that belongs there automatically. Thus, the system does not interpret, for example, moving leaves, as motion. Sensitivity and quantity The system detects motion when: •... -
Page 13: Profiles
Mirasys N Series Profiles A profile specifies the cameras and other devices that a user is allowed to access. The system has one default profile “Service”, which contains the devices that the license key specifies. You can use the default profile as such or modify it freely, for example, group together cameras that are at the same location. - Page 14 Configuration To edit the default profile or add a new profile: On the Profiles tab, do one of the following: • Click the Edit Profile button in the lower-right corner of the navigation pane. • Click the Add Profile button the lower-left corner of the navigation pane.
-
Page 15: Users
Mirasys N Series Users There are three types of user accounts in the system: Users are allowed to log on to Workstation but not to System Manager. Users with monitoring rights are allowed to log on to System Manager and monitor the system on the System tab, but they are not allowed to change the settings. -
Page 16: Monitoring
Monitoring MONITORING Use the Mirasys N Workstation program for monitoring real-time video and playing back recorded video. You can use the program on the same computer where the NVR is installed or over a network from any computer where the client programs have been installed. -
Page 17: Real-Time Monitoring
Mirasys N Series Real-time monitoring To monitor real-time video from one camera: Select the profile that you want to use from the Navigator. Right-click the camera and choose Show Real-Time View from the menu. To monitor real-time video from multiple cameras: •... -
Page 18: Working With Group Windows (Device Windows)
Monitoring Working with group windows (device windows) To change the shape of a device window: • Put the mouse pointer on the edge of the device window, and drag the edge to the direction you want. To change the dimensions of a device window: •... -
Page 19: Using Layouts
Mirasys N Series To close a view from a device window: • Right-click on the device view and choose Close. To change the order of the devices views: • Drag a view to a new position. To add a device view: •... -
Page 20: Controlling Dome Cameras
Monitoring Controlling dome cameras Dome cameras (PTZ cameras) are shown with the dome camera icon on the Navigator. To activate dome control: • Right-click on the camera view, and choose Dome Control from the menu. The zoom, iris, and focus controls appear on the camera view. To pan and tilt the camera: •... -
Page 21: Multiview Playback
Mirasys N Series Multiview playback You can play back synchronized video from as many as eight cameras. A. Save and print images B. Playback controls C. Search Tools To play back video from multiple channels, do one of the following: •... -
Page 22: Activity Search
Monitoring This guide shows how to use Activity Search. Activity Search To show Activity Search: • Right-click the camera on the Navigator and choose Activity Search. The Activity Search window shows recorded video or audio as a bar graph. The horizontal axis shows the time, and the vertical axis shows the quantity of recorded video or audio. -
Page 23: Multiview Search
Mirasys N Series Multiview search You can show as many as eight video or audio views in Activity Search at the same time. To add a camera or audio channel to the search window: • Drag the camera or audio channel from the Navigator or the work space to the search window. -
Page 24: Image Tools
Monitoring To bookmark an event: • Right-click on a video view in playback mode and choose Add to Bookmarks. Image tools You can enhance real-time and recorded video by using the image tools. For example, you can adjust brightness or contrast. These image tools are available: sharpen, reduce noise, find edges, grayscale, equalize, deinterlace, mirror, and flip. -
Page 25: Playing Video Clips
Video clips are exported as Windows Media files (WMV). They can be played using Mirasys Media Player or Windows Media Player 10. To play a media clip from a CD or DVD using Mirasys Media Player: • Put the CD or DVD into the CD/DVD drive. Mirasys Media Player starts automatically and starts to play the clip.
