Introducing the
Powerwise
Save These Important Informations Importantes
Safety Instructions
This manual contains important safety, operat- Conserver ces instructions. Ce manuel contient
ing, and installation instructions. Read before des instructions importantes concernant la
using charger. sécurité et le fonctionnement.
Battery Safety Information Information de Sécurité de
Use charger only on 36 volt battery
systems. Other usage may cause per-
sonal injury and damage. Lead acid
Utiliser seulement sur les batteries
batteries may generate explosive
avec un algorithme approprié au type
hydrogen gas during normal opera-
spécifique de batterie – voire le man-
tion. Keep sparks, flames, and smok-
uel. D´autres types de batteries pour-
ing materials away from batteries.
raient éclater et causer des blessures
Provide adequate ventilation during
ou dommages. Les batteries peuvent
charging. Never charge a frozen bat-
produire des gaz explosives en ser-
tery. Study all battery manufacturers'
vice normal. Ne jamais fumer près de
specific precautions such as recom-
la batterie et éviter toute étincelle ou
mended rates of charge and removing
flame nue à proximité de ces derniers.
or not removing cell caps while charg-
Fournisser la bonne ventilation lors du
ing.
chargement. Ne jamais charger une
batterie gelée. Prendre connaissance
Electrical Safety
des mesures de précaution spécifiées
Information
par le fabricant de la batterie, p. ex.,
vérifier s´il faut enlever les bouchons
DANGER des cellules lors du chargement de la
batterie, et les taux de chargement
recommandés.
Risk of electric shock. Connect charg-
er power cord to an outlet that has
Information de Sécurité
been properly installed and grounded
in accordance with all local codes and
ordinances. A grounded outlet is
required to reduce risk of electric
shock – do not use ground adapters or
Risque de chocs électriques. Ne pas
modify plug. Do not touch uninsulated
toucher les parties non isolées du con-
portion of output connector or uninsu-
necteur de sortie ou les bornes non
lated battery terminal. Disconnect the
isolées de la batterie. Toujours con-
AC supply before making or breaking
necter le chargeur à une prise de cou-
the connections to the battery while
rant mise à la terre. Ne pas ouvrir ni
charging. Do not open or disassemble
desassembler le chargeur – referer
charger. Do not operate charger if the
toute reparations aux personnes quali-
AC supply cord is damaged or if the
fiés. Pas à l´usage des enfants.
charger has received a sharp blow,
been dropped, or otherwise damaged
in any way – refer all repair work to
qualified personnel. Not for use by
children.
Instrucciones Importantes
Este manual contiene instrucciones de segu-
ridad importantes para la operación e insta-
lación del cargador – lea antes de utilizar el
cargador.
E-Z-GO Division of Textron, Inc., 1451 Marvin Griffin Road, Augusta, Georgia
USA 30906-3852 Phone: 1-800-241-5855
QE
™
36 Volt Battery Charger
Información de seguridad
De Sécurité de batería.
¡A T E N C I O N!
Utilice el cargador sólo en sistemas de
batería con un algoritmo escogido que
es apropiado al específico tipo de bat-
la Batterie
ería. Otro uso puede causar la herida
y daño personal. Las baterías de plo-
ATTENTION
m o - á c i d a s p r i n c i p a l e s p u e d e n
engendrar gas explosivo de hidrógeno
durante la operación normal. Manten-
ga las chispas, las llamas y las mate-
rias humeantes lejos de baterías.
Proporcione la ventilación adecuada
durante la carga de la batería. Nunca
cargue una batería congelada. Estud-
ie las precauciones específicas de
todos los fabricantes de baterías, las
tasas tal como recomendadas de la
carga y quitando o no quitando la
célula las tapas al cargar... – Use
solamente para aplicaciones de 36
voltios.
Información eléctrica de
seguridad
¡P E L IG R O!
El riesgo de calambre. Conecte la
cuerda del cargador a una salida de
Électrique
corriente o enchufe que ha sido instal-
DANGER
ada apropiadamente y basada en la
conformidad a códigos y ordenanzas
locales. Una salida de corriente firme
es requerida para reducir el riesgo de
calambre. No utilice adaptadores de
suelo ni modifique tapón. No toque la
porción aislada del conector de salida
n i t e r m i n a l a i s l a d a d e b a t e r í a .
Desconecte el suministro de A.C.
antes de hacer o romper las conex-
iones a la batería al cargar. No abra ni
desmonte el cargador. No opere el
cargador si la cuerda del suministro
de A.C. ha sido dañado o si el carga-
dor ha recibido un golpe agudo, fue
dejado caer, o de otro modo dañado
Guarde Estas
en ninguna manera. Refiera todo tra-
bajo de la reparación al personal califi-
De Seguridad
cado. Este cargador no es para uso
por niños.
710-0016Rev1
Introducing the
Powerwise
OPERATING INSTRUCTIONS
1. With the enclosed case design, the charger may be
placed virtually anywhere, but the choice of place-
ment and orientation is extremely important. For
optimum performance and shortest charge times,
place the charger in an area with adequate ventila-
tion. The charger should also be placed in an area
that will be relatively free of dirt, mud, or dust since
accumulations within the fins of the charger will
reduce their heat-dissipating qualities. Optimal cool-
ing also occurs when the charger is placed on a hor-
izontal surface with the fins vertical. More airflow
from below the charger will help cool the fins, so
placement above open areas or areas with cut-outs
for airflow is desirable. As the charger may get hot
in operation, the charger must be placed such that
risk of contact by people is reduced. Wall mount or
shelf mount using #10-M5 screws. The charger's
status display must be visible to the user.
2. Always use a grounded outlet. When using an exten-
sion cord, avoid excessive voltage drops by using a
grounded 3-wire 14 AWG cord.
3. When plugged into the vehicle's charger receptacle,
the charger will automatically turn on and the
charger's LED will start flashing GREEN to indicate
the battery is charging.
4. Once a minimum battery voltage of 2 volts per cell
(Vpc) is reached, the charger's output current will
change from a trickle current to the full rated charg-
ing current. The length of charge time will vary by
how depleted the battery pack is, the input AC volt-
age, and/or charger ambient temperatures. The
charger's LED will flash a SHORT flash (off more
than on) if charge is <80% and a LONG flash if
>80%.
5. When the charger's LED is continuously GREEN,
the batteries are completely charged. The charger
may now be unplugged from the vehicle. If left
plugged in and the battery pack voltage drops below
a minimum voltage or 30 days has elapsed, the
charger will automatically restart a complete charge
cycle.
6. If a fault occurred anytime during charging, a fault
indication is given by quickly flashing the RED LED
on the charger. The specific fault is indicated on the
charger by flashing RED a number of times, paus-
E-Z-GO Division of Textron, Inc., 1451 Marvin Griffin Road, Augusta, Georgia
USA 30906-3852 Phone: 1-800-241-5855
QE
™
36 Volt Battery Charger
ing, and then repeating. There are several possible
conditions that generate errors. Some errors require
human intervention to first resolve the problem and
then to reset the charger by unplugging the DC cord
from the vehicle. Others may be simply transient
and will automatically recover when the fault condi-
tion is eliminated. If the AC voltage is interrupted
and restored, the charger will turn back on automati-
cally.
Visual LED Display Information
LED Operation Codes:
SHORT LED flash green = less than 80% charged
LONG LED flash green = more than 80% charged
SOLID LED green = 100% charged
RED LED flash = fault code
LED Fault Code Display Information
LED Fault Code:
0-FLASH RED Light turns on briefly but nothing after
that - Check for valid AC voltage.
1-FLASH RED Charge Enable Fault: Poor contact in
DC connector.
2-FLASH RED Battery Voltage Fault: Battery Pack is
< 27.0V or > 50.4V. Battery is too discharged or
overcharged to be charged.
3-FLASH RED Battery Charge Timeout: Charge time
24hrs. exceeded. This may indicate a problem with
the battery pack (old battery pack) or that the
charger output current was severely reduced due to
high ambient temperatures.
4-FLASH RED Battery Fault: Charge time exceeded.
This indicates a problem with the battery pack volt-
age not attaining the required nominal level within
tmax.
6-FLASH RED Charger Fault: an internal fault has
been detected. If Fault 6 is again displayed after
unplugging and then plugging the DC power cord,
the charger must be brought to a qualified service
center.
