1.FS.1A
TYPICAL JETMASTER FREE STANDING INSTALLATION INSTRUCTIONS
WOOD / GAS
WOOD INSTALLATION TO COMPLY WITH AS/NZS2918:2001
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions
may result in a fire hazard and will void the warranty
7/2013
Advertisement
Related Manuals for Fireplace 700 D
Summary of Contents for Fireplace 700 D
- Page 1 1.FS.1A TYPICAL JETMASTER FREE STANDING INSTALLATION INSTRUCTIONS WOOD / GAS WOOD INSTALLATION TO COMPLY WITH AS/NZS2918:2001 IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions may result in a fire hazard and will void the warranty 7/2013...
- Page 2 Fig. 5 & 6 and AS/NZS 2918:2001 4.6.3(b) Fig. 1 Jetmaster Table 1 Solid Fuel 700 D *Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch 1100 prior to ordering the ceiling plate ** A minimum 75mm thickness refers only to Hebel Block.
- Page 3 1.FS.1C PARALLEL POSITIONING Fig. 2 Table 2 Solid Fuel Description 700 D Min. distance from flue centre to side wall 302.5 Min. distance from flue centre to back wall Min. distance from firebox opening to floor protector lateral side 1100 Min.
- Page 4 CORNER POSITIONING (45˚) Fig. 3 ¯ Table 3 Solid Fuel Description 700 D Min. distance from flue centre to side wall 302.5 Min. distance from firebox opening to floor protector lateral side 1422 Min. floor protector dimension 1100 Min. floor protector front width Min.
-
Page 5: General Instructions For Flue System
1.FS.1E GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including firebox spigot. - fix with a minimum of 3 stainless steel rivets ▪... - Page 6 FLUE PENETRATION - WOOD 1.FS.1F Tested flue systems, as per AS/NZS 2918:2001 ADD Cowl ADD Cowl Fig. 4 Casing cover Casing Cover oversized casing cover minimum 25mm gap is necessary between flue pipe casing & Spider bracket Spider Bracket combustible material Non combustible material Hebel block or 12mm Promina board or similar...
- Page 7 1.FS.1G FLUE PENETRATION - WOOD Un-tested flue systems, as per AS/NZS 2918:2001, 4.6.3(b) AS/NZS2918:2001 ADD Cowl Fig. 5 Un-tested flue with sloped ceiling penetration greater than 30° from horizontal Casing Cover Spider Bracket 4.5.1.2(b) = 50mm clearance to combustible material A = 62.5mm for 225mm Ø...
- Page 8 Table 4 Wood MODEL FLUE SYSTEM MINIMUM TRIM OUT DIMENSION X (min) Y (min) 700 D 225/275/325 MINIMUM HEIGHT OF FLUE SYSTEM EXIT - WOOD As per AS/NZS 2918:2001 4.9.1 Fig 4.9 Fig. 9 3000 More than 3000 or less 3000 600 min.
- Page 9 The Fireplace Ltd specifies that allowances must be made for air replacement vents to be located near the fireplace, to aid combustion and reduce the possibility of back venting. Refer to Table 5 for air vent sizing and suggested location see Fig 9.
- Page 10 1.FS.1L AS/NZS2918:2001 General Notes WARNINGS: WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. CAUTION: MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT IN HAZARD- OUS CONDITIONS.
