- Page 1 Model No. 2007 QuickBoost Instruction Manual MobilePower, LLC. Bluffton, SC 29910 www. Mobilepower-us.com Office: (800) 708 - 8550 support@mobilepower-us.com customerservice@mobilepower-us.com...
- Page 2 Model No. 2007 QuickBoost in ONE Multi-Purpose Vehicle Jumpstart System USB ON/OFF Toggle Switch USB 5 Volt Output Port LED Area Light ON/OFF with Protective Dust Cover Toggle Switch LED Area Light Double Injection Casing with Rubberized Protective Bumper Guards Reverse Jumpstart Polarity Protection LED Main Power Booster Clamps...
- Page 3 Model No. 2007 Internal Battery Charging Port USB Port with Protective Cover Charging Indicator LED USB ON/OFF Toggle Switch Battery Charge Level Status Push Button 12 Volt DC - 10A Accessory Port with Protective Cover Vehicle Jumpstart System through Cigarette Lighter Socket Main Power Booster Clamps ON/OFF Rotary Switch IMPORTANT INFORMATION...
- Page 4 Model No. 2007 IMPORTANT ADVISORY NOTES Do not use with dry cell batteries. These batteries may burst and cause injury to person or damage personal property. Do not attempt to face the battery being jumped. Stay away as far as possible from the battery when making the final connection.
- Page 5 Model No. 2007 FEATURES: 8 in One Multipurpose DC Power Supply with Instant Vehicle Jumpstart System. The unit provides: Air Compressor with Pressure Air gauge - Heavy Duty Booster Cables with Insulated Clamps - Main Power Booster Cables ON/OFF Switch - Reverse Polarity Protection - Internal Battery Charge Level Status Indicator LED Bars - LED Area Light with ON/OFF Switch - 12 Volt DC Accessory plug with Charge/ Booster Cable through vehicle 12 Volt DC cigarette lighter socket - USB power port with Protective Cover - Air Nozzle Adaptors for most Inflatables Foldable Handle for Vertical and Horizontal Operation...
- Page 6 Model No. 2007 INTERNAL BATTERY CHARGE LEVEL: Battery Charge Level Press and hold the Battery Charge Level Status Push Button to determine the unit internal battery charge level prior to each use. The battery Charge Level bars illuminate indicating the Status of the battery Charge Level.
- Page 7 Model No. 2007 AIR COMPRESSOR OPERATING INSTRUCTIONS: CAUTIONS Do not operate the Air Compressor more than 10 Minutes continuously. Allow the compressor to cool down for 10 to 15 minutes between each continuous operation. Review the products to be inflated for manufacturer’s recommended maximum inflation pressure.
- Page 8 Model No. 2007 VEHICLE BOOST START USING THE DUAL 12VDC PLUG BOOSTER CABLE: WARNINGS: Vehicles equipped with on-board computers may be damaged if the vehicle is jump started. Read and understand your vehicle owner’s manual instructions before attempting to jump-start your vehicle. Failure to follow these advisory instructions my result in explosion. 1.
- Page 9 Model No. 2007 4. Determine whether your vehicle designed with a negative or positive grounded system: In the Negative Ground System, the negative battery terminal is grounded to chassis of the vehicle. Most vehicles use this type of system. Positive Grounded battery terminal is grounded to chassis or any other part of the vehicle.
- Page 10 Model No. 2007 TROUBLESHOOTING GUIDE: TROUBLE RECOMMENDED SOLUTION Vehicle does not start Make sure the Polarity Protection Green LED is illuminated. Turn the Main Power Switch to ON Position to allow power into the booster clamps. DO NOT turn the Main Power Switch to ON position if the Polarity Protection RED LED is illuminated.
- Page 11 Model No. 2007 SPECIFICATIONS: Battery rated capacity ——————————————— 12 Volt - 10 Ah Air Compressor —————————————————– 260 PSI with 100 PSI Air Pressure Gauge 12 Volt DC output ports output Amp.————————– 10 A USB ports output rating —————————————— 5 Volt - 500 mA ...
- Page 12 Model No. 2007 MobilePower, LLC. Bluffton, SC 29910 www. Mobilepower-us.com Office: (800) 708 - 8550 support@mobilepower-us.com customerservice@mobilepower-us.com Made in China...
