SMAX GP1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.smax.com.tw
G
P1
2MP Pan-Tilt Camera, PoE
User
Manual
Ver 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP1 and is the answer not in the manual?

Questions and answers

Related Manuals for SMAX GP1

Summary of Contents for SMAX GP1

  • Page 1: User Manual

    2MP Pan-Tilt Camera, PoE User Manual Ver 1.2...

  • Page 2: Table Of Contents

    Chapter 5. Configuration Chapter 2. Installation 5.1. System Setup 2.1. Hardware Installation 5.2. Network Setup 2.2. SMAX Finder Installation 5.3. Video & Audio Setup 2.3. Ready to Use 5.4. SD Card Setup Chapter 3. Accessing 5.5. Event Setup 3.1. Network Deployment 5.6.
  • Page 3 CONTENTS Chapter 6. Appendix 6.1. URL Commands 6.2. Technical Specifications 6.3. Onvif Supports List 6.4. Liability 6.5. Copyright www.smax.com.tw...

  • Page 4: Read Before Use

    This product service may be different since the diversity of distributors. We suggest to purchase SMAX product from SMAX direct distributors or system integrators to get the most complete after service. Please first check the package contents are complete with nothing missing.
  • Page 5 Chapter I. Overview 1.2. Physical Description 1.2.1. Mechanical and hardware interface GP1 is built in with fixed lens network camera. It can be placed indoor environment where there is pan-tilt MicroSD/SDHC Card Slot function needed. GP1 accepts both POE or DC 12V as power supply.

  • Page 6: Physical Description

    Digital Input (DI) & Digital Output (D0) Item Description DI 2 DI 1 Digital Output Notes Specifications DI is floating, trigger is “high” Max current input: DI is high, trigger is “low” 30mA Suggested Component Value : Power(VDC) RL(Ω) 3.3V 100Ω 200Ω 510Ω www.smax.com.tw P 03...

  • Page 7: Safety Instructions

    Please do not attach DC/AC power directly to the camera’s DI/DO port.  Please check the correct direction when insert the SDHC card into camera device.  Please contact your sales channel or find a regional SMAX distributor for any warranty issues.  www.smax.com.tw P 04...

  • Page 8: Package Contents

    Chapter I. Overview 1.4. Package Contents Description Network Camera Tools package (Screw Kit…etc.) A. Software: SMAX VMS64 x 1 Network Camera Bracket B. Doc: Datasheet, User Manual, Quick Installation Guide www.smax.com.tw P 05...

  • Page 9: Electromagnetic Compatibility

    CE Mark Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. www.smax.com.tw P 06...

  • Page 10: Installation

    ＊. The network camera Setup 2. Please fix the wall mount bracket on supports both PoE power the wall or ceiling with supplied or DC 12V adapter screws. Setup 5. Please connect the network cable to network Camera. DC 12V www.smax.com.tw P 07...
  • Page 11 Chapter 2. Installation Network Camera IP address: 192.168.1.99 Subnet Mask: 255.255.255.0 Gateway: 192.168.1.1 4+2 ports PoE Switch IP address: 192.168.1.10 Subnet Mask: 255.255.255.0 Gateway: 192.168.1.1 or NVR / VMS IP address: 192.168.1.88 Subnet Mask: 255.255.255.0 Gateway: 192.168.1.1 www.smax.com.tw P 08...
  • Page 12 Chapter 2. Installation www.smax.com.tw P 09...

  • Page 13: Accessing

    IP address to mana ge. However, please noted that the performance of the camera will be s trongl y depends on the performance of the router. It ma y cause abnormal connecting due to this issue. <Please refer to 3.1. B. setting > Internet and Intranet setting structure illustration www.smax.com.tw P 10...
  • Page 14 Chapter 3. Accessing www.smax.com.tw P 11...
  • Page 15 Chapter 3. Accessing www.smax.com.tw P 12...
  • Page 16 Chapter 3. Accessing www.smax.com.tw P 13...
  • Page 17 SMAX network camera supports multiple connections for accessing. Includes multiple browsers connection, video player connection that supports RTSP, SmaxViewer APP connection, or SMAX VMS or CMS software to access. Each connection fulfill different surveillance application for different purpose. 3.2. Accessing via Web UI...
  • Page 18 Chapter 3. Accessing www.smax.com.tw P 15...
  • Page 19 Chapter 3. Accessing www.smax.com.tw P 16...
  • Page 20 Chapter 3. Accessing Setup 3. Setup 4. 3.5. Accessing via SMAX VMS Please select Setup.exe from the SMAX VMS folder content. Follow installation procedure and setting. Then you can run the SMAX VMS software to use. 3.5.1. SMAX VMS Installation procedure：...
  • Page 21 Chapter 3. Accessing www.smax.com.tw P 18...
  • Page 22 Chapter 3. Accessing www.smax.com.tw P 19...
  • Page 23 Chapter 3. Accessing www.smax.com.tw P 20...
  • Page 24 Chapter 3. Accessing www.smax.com.tw P 21...

  • Page 25: Web Ui

    Chapter 4. WEB UI 4.1. Home page You can access SMAX network camera via web browser to monitor live view, manage setting, SD card recording…etc. There is a complete introduction procedure of all function in the following chapter four and five.
  • Page 26 Press Browse button to set your folder path name. You can also name the Prefix of recording file and select to Add date and time suffix to file name. At last, press Apply to complete setting. www.smax.com.tw P 23...

  • Page 27: Configuration

    In the menu of configuration, it includes all operating function for settings, maintenance, log and device information…etc. Configuration menu as shown below： 1)System 2)Security 3)Network 4)IP Filter 5)Video 6)Audio 7)Motion Detection 8)Privacy Mask 9)PTZ Control 10)Event 11)Recording 12)SDHC 13)Log 14)Device Info 15)Maintenance www.smax.com.tw P 24...
  • Page 28 Chapter 5. Configuration www.smax.com.tw P 25...
  • Page 29 Chapter 5. Configuration www.smax.com.tw P 26...
  • Page 30 Chapter 5. Configuration www.smax.com.tw P 27...
  • Page 31 When your surveillance system has lower than 4pcs of network camera, we suggest to set DHCP IPv4/IPv6. You can search the camera’s IP with Smax Finder software. Please refer to chapter 3.1 for further description. If the total pcs of network camera is greater than 4pcs.
  • Page 32 Chapter 5. Configuration www.smax.com.tw P 29...
  • Page 33 Chapter 5. Configuration www.smax.com.tw P 30...
  • Page 34 Chapter 5. Configuration www.smax.com.tw P 31...
  • Page 35 Chapter 5. Configuration www.smax.com.tw P 32...
  • Page 36 Chapter 5. Configuration www.smax.com.tw P 33...
  • Page 37 Chapter 5. Configuration www.smax.com.tw P 34...
  • Page 38 Chapter 5. Configuration www.smax.com.tw P 35...
  • Page 39 Chapter 5. Configuration www.smax.com.tw P 36...
  • Page 40 Chapter 5. Configuration www.smax.com.tw P 37...
  • Page 41 Chapter 5. Configuration www.smax.com.tw P 38...
  • Page 42 2000~3000 kbps 1920 x 1080 1000~2000 kbps 1280 x 960 2000~3500 kbps 1280 x 960 1000~2500 kbps 1280 x 720 800~2300 kbps 720 x 480 768~1500 kbps 640 x 480 512~1200 kbps 320 x 480 256~900 kbps www.smax.com.tw P 39...
  • Page 43 1000kbps as Bitrate setting, how many space does a storage need to hold at least a monthly(30days) recording files? Answer： ----------------------------------------------------------------------- 1000(kbps) / 8 x 60 x 60 / 1000 / 1000 x 24(hrs) x 30(days) = 324(GB) / 1000 = 0.324(TB) ----------------------------------------------------------------------- www.smax.com.tw P 40...
  • Page 44 Chapter 5. Configuration Resolution Bitrate suggestion 720 x 480 Normal (1000~2000 kbps) 640 x 480 Normal (800~1800 kbps) 320 x 480 Normal (200~600 kbps) www.smax.com.tw P 41...
  • Page 45 Chapter 5. Configuration Resolution Bitrate suggestion 320 x 240 Max. 30 Normal (500~1000 kbps) www.smax.com.tw P 42...
  • Page 46 Chapter 5. Configuration www.smax.com.tw P 43...
  • Page 47 5.３.3.１. Exposure Setting SMAX network camera supply two Exposure Mode. Default set as Auto mode. User can change to Manual mode for further exposure setting of day and night mode.
  • Page 48 Chapter 5. Configuration www.smax.com.tw P 45...
  • Page 49 Chapter 5. Configuration www.smax.com.tw P 46...
  • Page 50 Chapter 5. Configuration www.smax.com.tw P 47...
  • Page 51 Chapter 5. Configuration www.smax.com.tw P 48...
  • Page 52 Chapter 5. Configuration www.smax.com.tw P 49...
  • Page 53 Chapter 5. Configuration www.smax.com.tw P 50...
  • Page 54 Chapter 5. Configuration www.smax.com.tw P 51...
  • Page 55 Chapter 5. Configuration www.smax.com.tw P 52...
  • Page 56 Chapter 5. Configuration www.smax.com.tw P 53...
  • Page 57 Chapter 5. Configuration www.smax.com.tw P 54...
  • Page 58 You can set multiple event setting base on different needs of different applications. SMAX network camera has two was of event trigger settings： 1)Motion Detection 2)Digital Input signal Proceed actions includes：...
  • Page 59 Chapter 5. Configuration www.smax.com.tw P 56...
  • Page 60 Chapter 5. Configuration www.smax.com.tw P 57...
  • Page 61 Chapter 5. Configuration www.smax.com.tw P 58...
  • Page 62 Chapter 5. Configuration www.smax.com.tw P 59...
  • Page 63 Chapter 5. Configuration www.smax.com.tw P 60...
  • Page 64 There are two ways of factory reset procedure. One is completely reset back to factory default setting. The other one is reset back to default setting except IP address and time setting. Reset procedure: When press Reset button, it can remotely reset the camera. www.smax.com.tw P 61...
  • Page 65 When press Backup button, SMAX camera will back up setting to your computer. When press Backup to SD card device button, SMAX camera will back up setting to your SD card. 5.6.4. Restore SMAX camera can also restore your back up setting from above procedure.
  • Page 66 5.6.5. Upgrade SMAX camera contain its original firmware version when first leave the factory. If for any reason, such as debug or new features, SMAX will put the latest firmware version on SMAX website for download and upgrade purpose. Firmware upgrade procedure:...
  • Page 67 Chapter 5. Configuration 5.7. Camera Information SMAX network camera provide two ways of checking information. One is for the device information, it includes the fundamental of network setting and basic function of the camera. The other one is system log, it records all the operation or event history.
  • Page 68 5.7.2. System Log System log display procedure: To access system log, click Configuration from the menu then click Log button. You can check the usage log of this camera as shown in the picture from the right. www.smax.com.tw P 65...
  • Page 69 Chapter 6. Appendix 6.1. URL SMAX HTTP API Version: 1.0.10 Style Convention In URL syntax and in descriptions of CGI parameters, text in italics within angle brackets denotes content that should be replaced with either a value or a string. When replacing the text string, the angle brackets must also be replaced. URL syntax is written with the word “Syntax:”...
  • Page 70 Value Description IP Address:XXXXXX action=<string> add, add = create a new user MAC Address: XXXXXX update, account. Model Number:XXXXXX remove , update = change the Product Number:XXXXX information of specified H/W Version:XXXXXX parameters if the account exists. www.smax.com.tw P 67...
  • Page 71 Content-Type: text/plain\r\n Example (a) : Create a new administrator account. Content-Length: <content length>\r\n http:// camera_ip:port /cgi/admin \r\n /pwdgrp.cgi?action=add&user admin=”root,stanley,…”\r\n =paul&pwd=foo&grp=admin users=”jack,brian,…”\r\n guest=”angus,becky,…”\r\n FAIL HTTP/1.1 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <content length>\r\n \r\n Request failed: <error message>\r\n www.smax.com.tw P 68...

  • Page 72: System Date And Time

    <string> Current year. considered valid input. The month=<string> <string> Current month. rest of the time zones are subject day=<string> <string> Current day. to future edition. hour=<string> <string> Current hour. minute=<string> <string> Current minute. second=<string> <string> Current second. www.smax.com.tw P 69...

  • Page 73: Maintenance 61

    1 : Reset all parameters to HTTP/1.1 200 OK\r\n the original factory settings. Content-Type: text/plain\r\n 2 : Reset all parameters Content-Length: <content length>\r\n except the IP, time zone and \r\n daylight saving to the ok\r\n original factory settings. www.smax.com.tw P 70...
  • Page 74 6.1.2.2. Firmware upgrade Return: Method: POST Syntax: HTTP/1.1 200 OK\r\n Content-Type: text/plain\r\n --------------------------------------------------------------------------- Content-Length: <content length>\r\n http:// camera_ip:port /cgi/admin \r\n /firmwareupgrade.cgi OK\r\n --------------------------------------------------------------------------- FAIL HTTP/1.1 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <content length>\r\n \r\n Request failed: <error message>\r\n www.smax.com.tw P 71...
  • Page 75 \r\n \r\n OK\r\n --myboundary\r\n Content-Length: <content length>\r\n FAIL HTTP/1.1 200 OK\r\n \r\n Content-Type: text/plain\r\n <Payload Header> Content-Length: <content length>\r\n <Payload Data> \r\n --myboundary\r\n Request failed: <error message>\r\n Content-Length: <content length>\r\n \r\n <Payload Header> <Payload Data> …. www.smax.com.tw P 72...
  • Page 76 7: SXGA Bit0-3 type 8: 4CIF (NTSC) 2: PCM 9: CIF (NTSC) 3: uLaw 10: QCIF (NTSC) 4: AMR 11: 4CIF (PAL) Bit4-5 sample size 12: CIF (PAL) 0: 8bits 13: QCIF (PAL) 1: 16bits www.smax.com.tw P 73...
  • Page 77 (0 – 255) \r\n Bit 24: trigger input 1 <Payload Header> status (1:high/0:low) <Payload Data> Bit 25: trigger input 2 …. status (1:high/0:low) Bit 26: trigger output 1 status (1:high/0:low) Bits 27 – 31: reserved www.smax.com.tw P 74...
  • Page 78 Description Example: listen Query the listening status http:// camera_ip:port /cgi/jpg/image.cgi (Server to PC) 0: free to connect Return: 1: microphone not available HTTP/1.1 200 OK\r\n 2: device is disable Content-Type: text/plain\r\n Content-Length: <content length>\r\n \r\n <image data>\r\n www.smax.com.tw P 75...
  • Page 79 Content-Length: <content length>\r\n Byte6 Byte7 Byte8 Byte9 Byte10 Byte11 \r\n 0x56 0x9c 0xab 0x45 0xa2 0x07 <Payload Header> <Payload Data> --myboundary\r\n Content-Length: <content length>\r\n \r\n <Payload Header> <Payload Data> …. FAIL HTTP/1.1 503 Service Not Available\r\n Content-Length: 0\r\n \r\n www.smax.com.tw P 76...
  • Page 80 Do auto focus quickly http://192.168.101.102:80/cgi/f /focuszoomctl.cgi?focusminus fzisbusy Check the motor lens is busy or not getmotorcuspos Get current position both of focus & Example: (Server sends setup to network camera.) zoom motor lens [movezoom] http://192.168.101.102:80/cgi/fz /focuszoomctl.cgi?movezoom=6 www.smax.com.tw P 77...
  • Page 81 List order by key value [Current Zoom Index Of Position] | [Current Focus Index order ascend List order by order value Of Position] record, List working folder Ex: 6|55 event List channel page 1, 2, 3, … List Page Index www.smax.com.tw P 78...
  • Page 82 Example: (Format SD Card.) \r\n [Format SD Card] <Result> http://192.168.101.102:80/sdcard.cgi?action=format& \r\n Return: FAIL HTTP/1.1 200 OK\r\n Content-Type: text/plain\r\n [Result] Content-Length: <content length>\r\n 1 : SD Card Format success \r\n 0 : SD Card Format fail Ex: 1 www.smax.com.tw P 79...
  • Page 83 [Path],[Total File],[Total Page],[List Page],<File name|File ir=record&fname=5MP_IP_BOX-03 Time|File Size(KB)>,… 212012-142806.avi& Return: /tmp/mmc_dir/Backup/,2,1,1,SICPT501U-01082014- [Result] 200248.avi 1 : File Delete success |Thu Jan 9 12:02:48 2014 0 : File Delete fail |10808,SICPT501U-01082014-201533.avi|Thu Jan 9 Ex: 1 12:15:33 2014 |10815 www.smax.com.tw P 80...

  • Page 84: Technical Specifications

    116.4(D) x 108(W) x 122.6(H), Dimensions, Weight PoE / DC Power PoE (IEEE802.3af) / DC12V Net 322g Power Consumption Max. 10W Pan-n-Tilt Pan: 350°±5° ; Tilt: 120°±5° Environment Operating Temp. 0°C~45°C (32°F~113°F) Humidity 20%~85% RH Storage Temp. -20°C~60°C (-4°F~140°F) www.smax.com.tw P 81...
  • Page 85 Multi-Level User Access Up to 5 Clients Multiple Streaming Max. 3 Streams Configuration File Backup to PC / Backup to SD card Web Browser Internet Explorer 9.x above Operating System Suggest Windows 7/8/8.1 above Language Supports multiple languages www.smax.com.tw P 82...

  • Page 86: Onvif Supports List

    Chapter 6. Appendix 6.3. Onvif Supports List 6.3.1. NVR SMAX Camera NVR Models Motion SD Card Version Brand Model FW ver. NVR Onvif Live View Playback DIDO Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x SMAX V1.1 V1.03.20x V1.03.20x V1.03.20x V1.03.20x...
  • Page 87 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.1. NVR SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x QNAP VS-xxxxx V5.0.0 /VioStor Products V1.03.20x /V4.3.x V1.03.20x...
  • Page 88 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.1. NVR SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x RSxxxx V1.03.20x DSxxxx Synology Products V5.0xx V1.03.20x V1.03.20x V1.03.20x...
  • Page 89 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.1. NVR SMAX Camera NVR Brand Motion SD Card Version Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x DS7600 DS7700 V1.03.20x HIKVISION DS8600 V1.03.20x DS9600 Products V1.03.20x...
  • Page 90 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x SMAX SMAX V1.1x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x...
  • Page 91 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x NEXT V1.03.20x Intellect axxonsoft Enterprise V1.03.20x Products V1.03.20x V1.03.20x...
  • Page 92 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x NEXT V1.03.20x Intellect axxonsoft Enterprise V1.03.20x Products V1.03.20x V1.03.20x...
  • Page 93 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V6.11 Symphony Aimetis V6.12 Products V1.03.20x V1.03.20x V1.03.20x...
  • Page 94 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x Crystal NUUO Products V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x...
  • Page 95 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.2. VMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x VAST v1.8.x VIVOTEK Products V1.03.20x V1.03.20x V1.03.20x V1.03.20x...
  • Page 96 Chapter 6. Appendix 6.3. Onvif Supports List 6.3.3. CMS SMAX Camera Motion SD Card Version Brand Models Model FW ver. Live View Playback DIDO Onvif Detection Recording V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x V1.03.20x SAMX SMAX V1.1x CMS512 V1.03.20x V1.03.20x V1.03.20x V1.03.20x...

  • Page 97: Liability

    Chapter 6. Appendix 6.4. Liability SMAX Technology Co., Ltd. does not responsible WEEE Directive & Product Disposal for any printing errors or any related issues. And At the end of its serviceable life, this product should not be hereby to claim that all specification or description treated as household or general waste.

  • Page 98: Copyright

    SMAX Technology Co., Ltd. reserves the right to revise this publica tion and to make changes from time to time in the contents hereof wi thout the obliga tion to notify any person of such revision or changes.
