Summary of Contents for MP-Man BT-20
-
Page 2: Table Of Contents
BT20 Contents Precautions................4 Characteristics................5 Player description..............7 Touch key function description:..........8 Forward / backward under movie playing status:..8 Finger Touch operation:............8 ! Important Note:...............6 Main Menu................9 Basic Operation................ 9 Power On/Off............... 9 Hold On/Off..............10 Power Reset.............. 10 Battery................ - Page 3 Charging Battery Mode..........19 Download operation of WMA music with DRM protection to MP3-Player................20 Convert and Play Video File..........27 Upgrade Player Driver............29 Troubleshooting..............31 Specifications:................ 32...
-
Page 4: Precautions
Precautions This manual contains important safe measurements and correct operational information, so please read all the information carefully before you use the device in order to avoid any unexpected accidents. Do not put the player in high temperature, humidity or dust place (over 40℃), especially not in the cars with window closed in summer. -
Page 5: Characteristics
Please charge in the following conditions: A. Battery electricity icon displays no electricity. B. When the system show power used up warning, C. No response with the pressing keys. D. The player shows “Good-Bye” automatically. ※Our Company reserves the right for the improvement of the product. -
Page 6: Player Description
Player description 1. Power on/off or Lock Long touch “<“: Fast on/off backward playing 2. Earphone Jack 6. “-”: Volume - and 3. Micro USB Jack moving down 4. “+”: Volume + and 7. “>”: Next moving up Long touch “>”: Fast 5 <“... -
Page 7: Touch Key Function Description
8. “ ”: Confirm / Enter 9. “M”: Short touch: Exit to into submenu, play and superior menu / Back pause 10. Micro SD card slot. Touch key function description: “+”: Volume + and moving up “-”: Volume - and moving down “... -
Page 8: Main Menu
Main Menu... -
Page 9: Basic Operation
Basic Operation Power On/Off Long pressing the power keys for three seconds, the MP4 player will be powered on. Long pressing the power keys for three seconds when MP4 player is on, the player will be powered off. *Important: If your MP3 player is blocked or doesn’t work, please Reset it and after two seconds, restart it again. -
Page 10: Music
The usable time of battery electricity may be various according to different volume, type of playing file and pressing operation. The player can save battery as per the set [Customized Power Off Time] or [Display Setting]. Music Select “Music display” in main menu and touch “ ” to enter into music playback status. -
Page 11: Radio
Touch “ ” key to exit to main menu. Radio Select “FM” in main menu and touch “ ” to enter into FM radio status. Then touch “ ” again, It will enter into FM submenu automatically first. (FM submenu includes: Manual, Auto, Mem, Preset, Del ) Touch “... -
Page 12: Photo
Preset: Touch “ ” to enter into “Pres” , you will see the FM channel you preset or saved before, touch “>” and “<” to choose the channel you prefer. Del: Delete the saved channel. There will be a window popped up to ask for confirmation of “Yes”... -
Page 13: Record
Store Bookmark When you are reading the book, touch the “<” icon and “ ” to save the bookmark, there are total eight bookmarks can be saved. Touch “ ” to confirm and save bookmark in the current page. Short touch “ ”... -
Page 14: Explorer
REC Volume: Five options of +1, +2, +3, +4 and +5. The higher level, the larger recorded volume. *When recording, please disconnect earphone to improve the recording effect ; *The recorded voice files can be found in Music Play menu and play to try the effect. -
Page 15: Settings
Settings Music Setup: 1) Repeat mode: Once: Stop when every one song is played over Repeat 1: Repeat a single song Folder once: Stop after finishing playing songs in one subfolders Folder Repeat: Repeat songs in subfolders All Once: Stop after playing all songs All Repeat: Repeat all songs continuously Intro: Play the first 10 seconds of songs in the current folder. -
Page 16: Fm Radio Setup
User EQ. User EQ operation: After choosing User EQ, touch “>” “<” key to shift to the frequency one by one (60Hz / 300Hz / 1KHz / 3KHz / 6KHZ) < you want to adjust and adjust dB by “^” or “v“ key, touch “ ”... -
Page 17: System Setup
Electricity-saving modes. System setup 1) About:: It shows the information of Firmware version, Date and Memory capacity. 2) Firmware Upgrading Touch “ ” to see the window as following: it reminds you whether to upgrade the firmware, it will exit if no firmware upgrading. -
Page 18: Connecting With Computer
( Pyccknn ) Connecting with computer USB Display Mode The player has a high-speed USB2.0 port, supports the systems including Windows98 (it needs to install the driver), over Windows2K (it’s unnecessary to install the driver), Mac OS 10.3 and over, Linux Redhat 8.0 and over. It supports USB power supply and can be played without battery. -
Page 19: Download Operation Of Wma Music With Drm Protection To Mp3-Player
! Warning: 1. Before charging, please turn off mp4 player, otherwise it will cause MP3 player abnormal working; 2. If you want MP4 working during charging when connecting computer, please remove the USB disk function first from your computer Download operation of WMA music with DRM protection to MP3-Player On Window 98SE/ Window ME / Windows 2000/ Windows XP, WMA music with DRM should be transferred by... - Page 20 3) In Windows Media Player 9.0 , open the desired WMA music with DRM System maybe request to download the license in case if user does not download the WMA music with DRM properly from the website . In this case, user need download the license from music publisher as instruction of Microsoft Website.
- Page 21 6) Then click Icon “Copy ” to transfer the WMA music with DRM to your MP3-Player...
- Page 22 7) Safely remove your MP3-Player from PC B) On Windows Media Player 10.0 version (Windows XP only) 1) Connect your MP3-Player to PC 2) Choose the desired WMA music with DRM...
- Page 23 3) Click Right button of mouse and choose “Add to Sync list”...
- Page 24 4) On the open windows , choose “Sync ” option...
- Page 25 5) On “Sync ” window , choose the desired WMA music with DRM as step 2) And choose “Removable Disk” 6) Click “start Sync “ to transfer the WMA music with DRM to your MP3-Player...
-
Page 26: Convert And Play Video File
Safely remove your MP3-Player from PC. Convert and Play Video File This player can convert the WMV, RM, AVI, VOB or DAT into AVI video format via the attached video convert software in CD driver. 1. Click and run the program of “AV Converter.exe”, shown as follows:... - Page 27 2.click "add ", show dialog as follows: 3.Select and set your desired parameters, select your desired video/audio file and AVI video file routine to be generated, save it and close the window. Then click [Start to Convert] button, it begin to convert to AVI file.
-
Page 28: Upgrade Player Driver
4.The successfully converted AVI video file can be played in MP3 player. Upgrade Player Driver The player can be upgraded or resume the damaged player driver via the firmware software in the attached CD. 1. Run the Setup.exe in the folder named “Update tool” in the CD driver, just follow the dialogue to finish installation. - Page 29 (the Interface is as follows) 3. Power on your MP3 player enter into “Settings” and select “System”, choose “Upgrade” item, you will be asked “Firmware upgrade?”, choose “Yes”, then connect the player to PC via USB cable. After 3 seconds, click [Update] till the Auto Upgrading is achieved.
-
Page 30: Troubleshooting
formatting is completed, you can download files and use it again. Note: Firmware upgrade is to improve and optimize the performance of the player. The normal work of the player would not be affected even if the firmware isn’t upgraded. The wrong operation of upgrading firmware would cause the device not to work normally! The firmware upgrade software of this player is not applied to other series of... - Page 31 It can not be used normally after Upgrade again in Windows 2000 upgrading MPmanager For movie and music synchronization and conversion, use MPMANAGER software included in device memory. This software can be used also for update of device. MPmanager manual is included in device memory.
-
Page 32: Specifications
Specifications: Items Specifications Dimensions 86×40×10.5 mm (W*H*D) 1.8inch TFT; 65K real color display, TFT colored display Diagram (160 x 128) Language support Multiple languages Data transmission High speed USB2.0 speed Read: 4Mbps, Write: 1Mbps Music: MP3: 8K bps – 320K bps Supportable file WMA: 32K bps –... - Page 33 ALL INFORMATION IS SUBJECT TO BE CHANGED WITHOUT PRIOR NOTICE! Recycling This symbol bears the selective sorting symbol for waste electrical and electronic equipment(WEEE). This means that this product must be handled pursuant to European Directive 2002/96/EC in order to be recycled or dismantled to minimize its impact on the environment.
- Page 34 human health due to the presence of hazardous substances. For more information please check our website www.mpmaneurope.com...
