Summary of Contents for LaView LV-N9808C8E

  • Page 2 www.LaViewUSA.com...

  • Page 3: Front Panel Of

    The mouse should automatically be detected. In the rare case that the mouse is not detected, the possible reason may be that the two devices are not compatible, LV-N9808C8E please refer to the recommended device list from your provider. LV-N9916C6E...

  • Page 4: Starting Up And Shutting Down The Nvr

    NVR. Steps: Enter the Shutdown menu by clicking Menu > Shutdown. Click the Logout button to lock the NVR Starting Up and Shutting or the Reboot button to reboot the NVR. Down the NVR Password Before you start: Check that the voltage of the extra power supply is The default password for the NVR is 12345.
  • Page 5 Auto Adding IP Camera Interface Manual Adding IP Camera Interface Note: If the user name and password are You can edit the IP address, changed, the auto adding of IP camera may protocol, management port, fail. you may add it manually if necessary. and other information for the IP •...

  • Page 6: Editing The Connected Ip Cameras And Configuring Customized Protocols

    Camera Settings Interface Edit the Parameters Check the box next to cameras to be Click apply to save the settings and click OK added. to exit the editing interface. Click Quick Add to add the camera. To add other IP cameras: On the left side of the interface, you can enter the IP address, protocol, Configuring customized protocols...

  • Page 7: Editing Ip Cameras Connected To The Poe Interfaces

    The PoE interface supports the Plug-and-Play function. Example: For LaView NVRs, when you want to connect 1 online camera and connect 3 network cameras via PoE interfaces, you must disable 1 PoE interface in Edit IP Camera Interface the Edit IP camera panel.
  • Page 8 List of Connected Cameras Note: The cameras connected to the built- in switch interface cannot be deleted in this menu. Click the Edit button. Edit IP Camera Interface Note: Plug-and-Play means that the camera is connected to the switch interface. The parameters of the camera can’t be edited here.

  • Page 9: Introduction Of Live View

    Note:  Two ways to show the Right-click Menu Bar: right-clicking or moving the mouse to the bottom of the screen. Introduction of Live View  You can click on the right side of the menu bar to clip the menu on the screen. Live view shows you the video captured by each camera in real time.

  • Page 10: Adjusting Live View Settings

    Adjusting Live View Select the small box, and double- click on the camera number Settings to display that channel on the window. Purpose: Live View settings can be customized according to You can click button to your needs. You can configure the output interface, enable live view for all the dwell time for each channel, mute /volume for channels and click...

  • Page 11: Configuring Ptz Settings

    Configuring PTZ Settings Purpose: Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters must be done before you can control the PTZ camera. Steps: Enter the PTZ Settings interface. Menu >Camera> PTZ PTZ- More Settings Use the directional button to wheel the camera to the location that you want to as preset.
  • Page 12 PTZ- Call Preset Choose the preset number. Call preset in live view mode: Steps: Press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar to enter the PTZ setting menu in live view mode. PTZ Toolbar Choose Camera in the list on the menu.

  • Page 13: Configuring Encoding Parameters

    Encoding Parameters for Recording Select Record tab page to configure stream type, resolution, and other parameters as needed. Pre-record: The amount of time to be recorded prior to an alarm-triggered event. For example, if Configuring Encoding you set the pre-record time as 5 seconds, when an alarm triggers recording at 10:00, the camera saves Parameters video starting at 9:59:55.
  • Page 14 Menu>Record>Schedule To arrange any other schedule, leave the All Day Configure Record Schedule checkbox blank and set the Start/End time. Select Record Schedule. Note: Up to 8 periods can be configured for each day. The time periods cannot be overlapped. Repeat these steps to schedule recording for other days of the week.

  • Page 15: Configuring Motion Detection Record

    Descriptions of the scheduled recording icons are shown in the figure below. Descriptions of the scheduled recording icons Motion Detection Click the Apply button to validate the settings. Configure Motion Detection： If you wish to use these settings for other channels, Choose camera you want to configure.

  • Page 16: Manual Record

    Select the channels for which you want the motion detection event to trigger recording. Click Apply to save the settings. Click OK to go back to menu. Exit the Motion Detection menu. For detailed information on schedule configuration, see Chapter Configuring Record Schedule. Manual Record Motion Detection Recording Purpose:...

  • Page 17: Playing Back Record Files

    Playing Back Record Files Playing Back by Channel Purpose: Play back the recorded video files of a specific channel in live view mode. Channel switch is supported. OPTION 1: Playback Interface Choose a channel in live view mode using the mouse and click the button in the quick setting toolbar.

  • Page 18: Playing Back By Event Search

    Note: indicates the start/end time of the recording. Detailed Explanation of Playback-by-time Interface Note: Playback progress bar: Use the mouse to click on any point in the progress bar or drag the progress bar to locate specific frames. Playing Back by Event Search Purpose: Play back specific files on one or several channels by restricting event type (e.g.

  • Page 19: Smart Search

    Click the Search button to get search results from the information provided. Refer to right-side bar for results. Interface of Playback by Event Toolbar of Playback by Event Detailed Explanation of Playback-by-Event Toolbar Note: Playback progress bar: Use the mouse to click on any point in the progress bar or drag the progress bar to locate specific frames.
  • Page 20 Crop of Smart Search Area Motion Detection Settings Smart search findings will be marked as in the Enable the motion detection function and set the progress bar. arming area to full screen using the NVR’s local The hidden list of recorded files appear when mouse menu.

  • Page 21: Digital Zoom

    Digital Zoom Steps: Click the button on the playback toolbar to enter Digital Zoom interface. Use the mouse to crop an area and the cropped image will be enlarged up to 16 times. 4-ch Synchronous Playback Interface Click to play back recordings in reverse. Draw Area for Digital Zoom Right-click the image to exit the digital zoom interface.

  • Page 22: Backing Up Files

    Backing Up Files Quick Export Export Finished Purpose: Check backup result. Export record files to backup device(s) quickly. Choose the file in the Export interface and Steps: click to check it. Enter Video Export interface. Note: The Player (player.exe) will be Menu>Export>Normal exported automatically.
  • Page 23 Normal Video Search for Backup Select the files you want to back up. Click to play the file if you want to check it. Export by Normal Video Search using USB Flash Drive Check the checkbox next to the files you want to back up.
  • Page 24 Checkup of Export Result using USB Flash Drive Checkup of Export Result using USB Writer www.LaViewUSA.com...

  • Page 25: Configuring General Settings

    (DDNS) to be used for network access. Note: For the LV-N9808C8E series NVR, Prior registration with your ISP is required before you need to configure the internal NIC configuring the system to use DDNS.

  • Page 26: Configuring Ntp Server

    Configuring NTP Server Purpose: A Network Time Protocol (NTP) Server can be configured on your NVR to ensure the accuracy of RTSP Settings Interface system date/time. Steps: Enter the Network Settings interface. Enter the RTSP port in the text field Menu >...
  • Page 27 Before configuring the email Settings, the NVR E-mail Test: Sends a test message to verify must be connected to a local area network (LAN) that the SMTP server can be reached. that maintains an SMTP mail server. The network Click the Apply button to save settings. You can click Test button to test whether must also be connected to either an intranet or the Internet depending on the location of the e-mail...

  • Page 28: Initializing Hdds

    After the HDD has been initialized, the status of the HDD will change from Uninitialized to Normal. Initializing HDDs HDD Status Changes to Normal Purpose: A newly installed hard disk drive (HDD) must be initialized before it can be used with your NVR. Note: Initializing the HDD will erase all data on it.

  • Page 29: Managing Hdd Group

    Add NAS Disk Initialize Added NetHDD • Add IP SAN: 1) Enter the NetHDD IP address in Managing HDD Group the text field. 2) Click the Search button to view Setting HDD Groups available IP SAN disks. 3) Select the IP SAN disk from the list shown.

  • Page 30: Setting Hdd Property

    After reboot of device, enter the HDD HDD and the R/W HDD simultaneously so as to Information interface. ensure that reliability of video data is highly secured Menu > HDD> General and realiable. Steps: Select HDD from the list and click the Enter the HDD Information interface.

  • Page 31: Configuring Osd Settings

    Use the mouse to crop a zone on the window. Different zones will be marked with different frame colors. Note: Up to 4 privacy masks zones can be configured and the size of each area can be Configuring OSD Settings adjusted.

  • Page 32: Viewing Device Information

    Viewing Device Information Steps: Enter the System Information interface. Record Information Menu Menu >Maintenance>System Info Click the Device Info tab to see the Device Information menu where you can Viewing Alarm Information access the device name, model, serial No. , firmware version and encoding version. Steps: Enter the System Information interface.

  • Page 33: Searching & Export Log Files

    Information menu where you can view the HDD status, free space, property, etc., Log Search Results HDD Information Menu Note: Up to 2000 log files can be displayed at Searching & Export Log once. Files You can click the button of each log or double click it to view its detailed Purpose: information, you can also click the...

  • Page 34: Restoring Default Settings

    Upgrading by Local Backup Device Steps: Connect your NVR with a local backup device where the update firmware file is located. Enter the Upgrade interface. Menu >Maintenance>Upgrade Click the Local Upgrade tab to enter the local upgrade menu, as shown in Figure 12.

  • Page 35: Configuring Dst Settings

    Configuring DST Settings Steps: Enter the General Settings interface. Configuring General Menu >Configuration>General Select the DST Settings tab. Settings Purpose: Configure the output resolution, system time, and mouse pointer speed. Menu > Configuration > General interface. DST Settings Interface Steps: Enter the General Settings interface.
  • Page 36 Add User Menu User Permission Settings Interface Enter the information for a new user: Set the operating permissions (Local User Name, Password, Level and User’s Configuration, Remote Configuration and MAC Address. Camera Configuration) for the user. Level: Set the user level to Operator or Local Configuration •...

  • Page 37: Editing A User

    • Remote Alarm Control: Remotely arming (notify alarm and exception message to the remote client) and controlling the alarm output. • Remote Advanced Operation: Remotely operating HDD (initializing HDD, setting HDD property), upgrading system firmware, clearing I/O alarm output. User List •...
  • Page 38 the NVR. 1) If not, please install the compatible HDD. No image displayed on the monitor after  starting up normally. Note: Please refer to the “Quick Possible Reasons Operation Guide” for the HDD installation steps. No VGA or HDMI connections. 2) If you don’t want to install a HDD, Connection cable is damaged.
  • Page 39 1) Connect the NVR and PC with the RS- Steps 232 cable. Verify the IPC and the NVR versions are compatible. 2) Open the Super Terminal software, and execute the ping command. Input “ping 1) Enter the IPC Management interface IP”...
  • Page 40 And then you connect the device with the The frame rate has not reached the real- monitor via VGA or HDMI interface and time frame rate. reboot the device, there is black screen with Steps: the mouse cursor. Verify the network between NVR and IPC Connect the NVR with the monitor before is connected.
  • Page 41 When image is stuck, connect the RS- the status of the CPU and Memory. 232 ports on PC and the rear panel of If the resource is not enough, please  NVR with the RS-232 cable. end some unnecessary processes. Open the Super Terminal, and execute Check if the fault is solved by the above the command of “ping 192.168.0.0 –l...
  • Page 42 transmission. Reduce the number of local playback channel. b) The motion detection and alarm functions are enabled, and the parameters of Main Select “Menu > Playback”, and uncheck the Stream (Normal) and Main Stream (Event) checkbox of unnecessary channels. are different. So the image looks stuck due Check if the fault is solved by the above to the image changes between different steps.
  • Page 43 www.LaViewUSA.com...
