Appendix
9 . 5 . 6 F
9 . 5 . 6 F
A A U U L L
These codes apply to Analog devices and are added to the history log as well as being displayed in the Fault List
when the fault occurs.
Actual Fault Code
Displayed
No Response FAULT (F01)
Mismatched FAULT (F02)
Hardware Type
Devices At Same FAULT (F03)
Address
Incorrect Response FAULT (F04)
Open Circuit FAULT (F05)
Short Circuit FAULT (F06)
Low Threshold FAULT (F07)
Maintenance Alert FAULT (F08)
Maintenance Urgent FAULT (F09)
Verify Count Over 20 FAULT (F010)
Detector Failed Test FAULT (F011)
Security Tamper FAULT (F012)
Low Temperature FAULT (F013)
Ground Fault FAULT (F014)
Charger Fault FAULT (F015)
Battery Low FAULT (F016)
Battery High FAULT (F017)
General Trouble FAULT (F018)
Missing Address FAULT (F019)
AC Fail FAULT (F020)
Module External FAULT (F021)
Power Loss
Wrong OEM Device FAULT (F022)
Type
RFX Communication FAULT (F023)
Loss
AFP-2800/2802 Manual – P/N DOC-01-011
C
C
T T O O D D E E S S
Possible causes
The device in fault is not communicating with the LCM. This fault can
occur if the device is not physically connected, damaged or set at wrong
address.
The actual device type is different to the programmed type. This fault
would occur if an incorrect device type is used such as a heat detector
instead of a photo optical detector.
Two devices have the same address on the loop.
The device has returned an incorrect response. This fault can occur if
the device is faulty or the loop wiring is substandard. If the resistance of
the entire loop wire exceeds 50 ohms, this fault will be observed
intermittently.
An Analog module does not have the End Of Line resistor connected or
an incorrect value of EOL is used.
There is a short circuit on the output terminals of an Analog relay
module.
A low threshold fault indicates a faulty detector which needs to be
replaced.
Analog detector needs cleaning.
Analog detector needs cleaning urgently. Once the detector is in
maintenance urgent fault it will no longer provide reliable detection of
fire.
Not used on AFP-2800/2802.
LCM performs a test on each detector every 2 – 3 hours. This fault can
occur if the device is faulty or the loop wiring is substandard. If the
resistance of the entire loop wire exceeds 50 ohms, this fault will be
observed intermittently.
Not used on AFP-2800/2802.
Not used on AFP-2800/2802.
Less than 50kohms resistance to ground. The Ground Fault LED on the
affected LCM will be ON (refer to page 117).
Not used on AFP-2800/2802.
Not used on AFP-2800/2802.
Not used on AFP-2800/2802.
General fault code that LCM uses when it can not detect the actual
problem with the device. This fault can occur if the device is faulty or the
loop wiring is substandard. If the resistance of the entire loop wire
exceeds 50 ohms, this fault will be observed intermittently.
Not used on AFP-2800/2802.
Not used on AFP-2800/2802.
24 volt power is not connected to the Analog module. (Conventional
Zone and Control modules).
The device on the loop is using the wrong communication protocol.
Replace the device with a version that has compatible protocol with the
panel.
Not used on AFP-2800/2802.
109
