All installation works have to be carried out by professional experts only.

The manufacturer / dealer can not be sued for direct of indirect damages caused from

unprofessional installtion. Technical changes possible.

kit content

• (1) Inbay Charging Cup - wireless charging station in cup format

including 3 pairs of adjustable spacers and 1 m USB connector cable

• (2) 1 x external USB voltage transformer including connector cable

with fuse holder and 6,3mm blade connectors

• (3) 2x branch connectors 2,5mm² / 2x branch connectors 1 ,5mm²

• (4) spacers providing a perfect fit of your smartphone

• (5) 1 x felt adhesive tape

Installation Manual

Inbay Universal Charging Cup

part-no.: 241178-01-1

For all vehicles equipped with

a cup holder ( diameter Ø 76 - 83 mm )

Suitable for smartphones with a maximum

width of 70 mm (including cover)

Do you have a question about the 241178-01-1 and is the answer not in the manual?

Page 1: Installation Manual
70 mm (including cover) kit content • (1) Inbay Charging Cup - wireless charging station in cup format including 3 pairs of adjustable spacers and 1 m USB connector cable • (2) 1 x external USB voltage transformer including connector cable with fuse holder and 6,3mm blade connectors All installation works have to be carried out by professional experts only.
Page 2 Inbay Universal Charging Cup www.inbay.systems The Inbay Universal Charger Cup is a wireless charging cradle in cup-size format. Charging is done inductive according to Qi-standard and enables charging of all smartphones with Qi-compatible receiver going hand in hand with a stable storing in the vehicle‘s cup-holder =>...
Page 3 Inbay Universal Charging Cup www.inbay.systems => Position the Charging Cup to the desired direction => If the cup holder has a solid bottom you have to drill a hole (diameter of 18 mm) in order to install the USB connector cable...
Page 4 Inbay Universal Charging Cup www.inbay.systems => Disconnect the plug of the on-board socket and When Inserting a Qi compatible smartphone push down a bit the cable insulation charging begins automatically and the LED turns from red to blue => Mount the branch connectors on both cable wires.
