Communications Specialties' Fiberlink® 3353
Fiberlink®
3353 Series
3G/HD/SD-SDI to HDMI Optical Receiver
User's Manual
The Fiberlink 3353 Series converts
broadcast quality 3G/HD/SD-SDI
transmitted over one single mode
or multimode fiber to HDMI with
or without embedded audio.
World Headquarters
55 Cabot Court
Hauppauge, New York 11788 USA
Tel:
(631) 273-0404
Fax: (631) 273-1638
info@commspecial.com
commspecial.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CSI FiberLink 3353 Series
Summary of Contents for CSI FiberLink 3353 Series
- Page 1 User’s Manual Communications Specialties’ Fiberlink® 3353 The Fiberlink 3353 Series converts broadcast quality 3G/HD/SD-SDI transmitted over one single mode or multimode fiber to HDMI with or without embedded audio. Fiberlink® 3353 Series 3G/HD/SD-SDI to HDMI Optical Receiver World Headquarters 55 Cabot Court...
-
Page 2: Table Of Contents
Contents Fiberlink® 3353 Series Contents Welcome ..............3 Features . -
Page 3: Welcome
3353 Series is used to convert 3G/HD/SD-SDI with or without embedded audio transmitted over a single fiber optic core to HDMI. The Fiberlink 3353 Series is compatible with single mode or multimode fiber. The 3353 is also compliant with SMPTE 297-2006 for seamless interoperability with other SMPTE 297-2006 devices. -
Page 4: Technical Specifications
Technical Specifications Fiberlink® 3353 Series Technical Specifications Model Part Number Specification Unit Type Part Number Receiver Box 3353-B7L (LC) 3353-B7S (ST) General Specifications Indicators Power, Alarm, Data Rate Lock (3G, HD, SD) Box Version Dimensions 6.5 W x 1.15 H x 6 L (inches) 165 W x 29 H x 152 L (mm) Weight 16 ounces, 453.5 grams... -
Page 5: Optical Input
Technical Specifications Fiberlink® 3353 Series Technical Specifications Audio Output Optical Input Number of Audio Channels 2 channels, unbalanced, line level 2 channels embedded in HDMI signal Audio Connector RCA Jacks Switches Front panel selection of one of 8 audio channel pairs on SDI signal to output NOTE: Audio on HDMI and line level are available simultaneoulsy and extracted from audio embedded within SDI signal in accordance... -
Page 6: Installation Instructions
Installation Instructions Fiberlink® 3353 Series Installation Instructions The Fiberlink® 3353 Series of fiber optic transmission systems are ready for immediate use and do not require any special tools. However, an Optical Power Meter, such as the Fiberlink® 6615, can be useful in determining optical loss budgets during your systems design and maintenance. -
Page 7: Audio Pair Selection
Audio Pair Selection | LED Indicators Fiberlink® 3353 Series Audio Pair Selection The Fiberlink® 3353 Series has a rotary dial switch that allows you to select which audio pair to output. The chart below describes the operation of the rotary switch positions: Rotary Switch Positions Position Function... -
Page 8: Application Diagrams
Sample Application Diagrams Fiberlink® 3353 Series 3G/HD/SD-SDI Loop-Thru 3G/HD/SD-SDI Fiber Source Cable 1080p Displays 3350 Tx 3353 Rx with HDMI input Fiberlink Matrix 1080p Displays with HDMI input SMPTE 297-2006 using Audio Compatible Channel Pair 1 Switch/Router Multichannel Audio 3353 Rx Fiber 3G/HD/SD-SDI Fiber... -
Page 9: Operating Pointers
Operating Pointers | Troubleshooting Fiberlink® 3353 Series Operating Pointers Remember to check attenuation of the fiber optic cable. The system will only operate properly if these specifications fall within the range of the system’s loss budget. Troubleshooting Multimode fiber optic cable contains an optical fiber with a light carrying “core” that is only .0025 inches (62.5 microns) in diameter. -
Page 10: Maintenance And Repairs
Maintenance and Repairs | Certifications Fiberlink® 3353 Series Maintenance and Repairs The Fiberlink® 3353 Series has been manufactured using the latest semiconductor devices and techniques that electronic technology has to offer. They have been designed for long, reliable and trouble-free service and are not normally field repairable. Should difficulty be encountered, Communications Specialties maintains a complete service facility to render accurate, timely and reliable service of all products. -
Page 11: Warranty
CSI at the expense and risk of the Buyer. CSI’s obligation under this warranty will be limited, at its option, to either the repair or replacement of defective units, including free materials and labor. In no event shall CSI be responsible for any incidental or consequential damages or loss of profits or goodwill. -
Page 12: Accessories And Related Products
Accessories and Related Products Fiberlink® 3353 Series Fiberlink® 6610 Visible Light Source The Fiberlink® Visible Light Source provides a visible 650 nm laser output that can be used for identifying fiber breaks and individual fibers within fiber bundles, allowing for convenient, on-site testing of fiber networks during construction and maintenance procedures. - Page 13 Accessories and Related Products Fiberlink® 3353 Series Fiberlink® 3360 3G/HD/SD-SDI & 4 Pair AES Audio Series The Fiberlink® 3360 Series allows you to transmit 3G, HD or SD-SDI as per SMPTE 424M-2006, 292 and 259 with the ability to embed up to 8 channels (4 pairs) of AES/EBU digital audio.
- Page 14 Fiberlink® 3353 Series Page 14 Fiberlink® 3353 Series User’s Manual...
- Page 15 Fiberlink® 3353 Series Fiberlink® 3353 Series User’s Manual Page 15...
- Page 16 ©2011 Communications Specialties, Inc. All Rights Reserved. Fiberlink and the starburst logo are registered trademarks of Communications Specialties, Inc. CSI and the triangle designs are trademarks of Communications Specialties, Inc. P/N 128871 Rev. E If y ©2005 Spectra Vision Productions, Inc.
