Summary of Contents for ASUPU ASG1
- Page 1 MICRO-NANO BUBBLE GENERATOR ASG1 OPERATING MANUAL ASUPU CO., LTD 1033 Shimotogari, Nagaizumi-cho, Suntou-gun， ， ， ， Shizuoka, JAPAN 411-0943 ＴＥＬ (81)0559897704 ＴＥＬ ＴＥＬ ＴＥＬ ＦＡＸ (81)0559886221 ＦＡＸ ＦＡＸ ＦＡＸ E-MAIL info@asupu.com http://www.asupu.com...
- Page 3 Outlet hose (left) Intake hose (right) The hoses are connected to the right places. The hoses are connected to the right places. The hoses are connected to the right places. The hoses are connected to the right places.
- Page 4 Standard setting position: Water line should be 10-30cm under machine. Install the machine on flat place. Horses should be connected firmly. How to connect horses to the machine. Pull light green cover and connect. See pictures below. Release the light green cover after push to the end. 〇Good ×Bad ●...
- Page 5 Operation 1. Make sure the machine is set on secure place. 2. Make sure the reset button is depressed (warning light is off) and ground wire is connected. 3. Make sure the hoses are connected to the right place. 4. Make sure there is enough prime water in the machine. 5.
-
Page 6: Specifications
●Suction valve(orange one in the picture below on ): It should be always open while operating. It is shut 45 degree or less when the machine is installed under the water line to reduce falling pressure of water. Specifications: MODEL ASG1 CAPACITY L/min. 11-13 WEIGHT ｋｇ ｋｇ ｋｇ...
