- Page 1 HW-H500 User manual Wireless Audio - SoundStand Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register 'This Nanum Gothic Eco font is provided by NAVER'...
-
Page 2: Features
FEATURES FEATURES TV SoundConnect TV SoundConnect lets you listen to audio from your TV on your SoundStand via a Bluetooth connection and lets you control the sound. Surround Sound Expansion The Surround Sound Expansion feature adds depth and spaciousness to your listening experience. Surround Sound Expansion is powered by Sonic Emotion. -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock CAUTION or personal injury. -
Page 4: Precautions
PRECAUTIONS PRECAUTIONS 68.6 mm 99.1mm 99.1mm 99.1mm Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation 7~10 cm. -
Page 5: Table Of Contents
CONTENTS CONTENTS 12 CONNECTIONS FEATURES Connecting an external device using SAFETY INFORMATION OPTICAL (DIGITAL) cable or AUDIO (ANALOG) cable Safety warnings Precautions 13 FUNCTIONS Input mode GETTING STARTED Bluetooth Before reading the user’s manual TV SoundConnect What’s included 17 TROUBLESHOOTING INSTALLATION SoundStand installation 18 APPENDIX... -
Page 6: Getting Started
+ Copyright 2014 Samsung Electronics Co.,Ltd. All rights reserved; no part of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. WHAT’S INCLUDED Check for the supplied accessories shown below. Remote Control /... -
Page 7: Installation
INSTALLATION INSTALLATION SOUNDSTAND INSTALLATION If you want to place your TV on top of the SoundStand, please make sure that your TV satisfies the two conditions below: Maximum TV weight : 26 kg Maximum TV stand dimension : Smaller than 600 mm X 300 mm ... -
Page 8: Descriptions
Turns the power on and off. REMOTE CONTROL SENSOR The remote control can operate SoundStands made by SAMSUNG Displays the current mode. only. ● When you turn on this unit, there will be a 4 to 5 second delay before it produces sound. -
Page 9: Rear Panel
DESCRIPTIONS DESCRIPTIONS REAR PANEL OPTICAL IN AUX IN Connect to the digital (optical) Connect to the Analog output output of an external device. of an external device. Power Supply IN Connect the AC power adaptor to the power supply jack, and then connect the AC power adaptor plug to a wall outlet. -
Page 10: Remote Control
REMOTE CONTROL REMOTE CONTROL REMOTE CONTROL BUTTONS AND FUNCTIONS POWER POWER MUTE Turns the SoundStand on and off. D.IN Press the D.IN button to select Digital in. D.IN WOOFER VOLUME LEVEL Adjusts the volume level of the unit. If you set the volume to Max or Min, all the LEDs turn on. Bluetooth Sound Surr. - Page 11 We recommend that you select a Sound Effect mode based on the source material and your personal taste. ● SoundStand is a Samsung proprietary name. ● Operate the TV using the TV's remote control.
-
Page 12: Connections
CONNECTIONS CONNECTIONS CONNECTING AN EXTERNAL DEVICE USING OPTICAL (DIGITAL) CABLE OR AUDIO (ANALOG) CABLE This unit comes equipped with one optical in digital jack and one audio analog in jack, giving you two ways to connect it to a TV. AUX IN OPTICAL IN OPTICAL... -
Page 13: Functions
FUNCTIONS FUNCTIONS INPUT MODE Press each mode button on the remote control or the ( ) button on the product's top panel to select the mode you want. The unit turns off automatically in the following Input mode Display situations. Optical Digital input D.IN ●... -
Page 14: Bluetooth
• You will see a list of scanned devices. under the following circumstances: - If there is a strong electrical field around 4. Select "[Samsung] SoundStand" from the list. the SoundStand. • If the Bluetooth device is successfully - If several Bluetooth devices are... - Page 15 FUNCTIONS + Bluetooth POWER On (Bluetooth ● In Bluetooth connection mode, the POWER) Bluetooth connection will be lost if the When the Bluetooth Power On function is on and distance between the SoundStand and the SoundStand is turned off, if a previously paired the Bluetooth device exceeds 5m.
-
Page 16: Tv Soundconnect
FUNCTIONS TV SOUNDCONNECT You can enjoy TV sound through your SoundStand when it is connected to a Samsung TV that supports the TV SoundConnect function. + Connecting a TV to the SoundStand Connect 1. Turn on the TV and SoundStand. -
Page 17: Troubleshooting
The TV SoundConnect (TV pairing) failed. TV SoundConnect is supported by some • Does your TV support TV SoundConnect? Samsung TVs released after 2012. Check your TV to see if it supports TV SoundConnect. Update your TV with the latest firmware. -
Page 18: Appendix
DTS, Inc. DTS, Inc. All Rights Reserved. Hereby, Samsung Electronics, declares that this Wireless Audio - SoundStand is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The official Declaration of Conformity may be found at http://www.samsung.com, go to Support >... - Page 19 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care Centre. Contact Centre Contact Centre Web Site Web Site Country Country 0800 - SAMSUNG (0800 - MONTENEGRO 020 405 888 www.samsung.com/support...
