Summary of Contents for Awind WGA510
- Page 1 Wireless Presentation System User's Manual For WGA510 (July 2014) Version: 1...
-
Page 2: Table Of Contents
Table of Contents Overview ......................5 Package Contents ..................6 USB Token Contents ..................6 Physical Details ....................7 What You Might Need ................... 8 Quick Installation ..................9 WPS Start/Standby Page ................10 Quick Guide / User-List ................10 Screen Saver..................... - Page 3 8.10.16 Make WPS Token ................26 8.10.17 Copy Application to desktop ............27 8.10.18 Hot Key ..................... 27 8.10.19 About ....................28 8.10.20 Exit ....................28 DoWiFi for Mac ................... 29 Install the application ................29 Start the application ................30 Quick Connect ..................
- Page 4 10.4.3 Network Setup ..................49 10.4.4 OSD Setup .................... 53 10.4.5 Change Passwords ................54 10.4.6 Reset to Default ................... 55 10.4.7 Firmware Upgrade ................55 10.4.8 WebSlides Setup .................. 57 10.4.9 Reboot System ..................57 10.4.10 Logout ....................58 10.5 WebSlides ....................
-
Page 5: Overview
Overview WPS is professional wireless presentation gateway. By enabling the Revolutionary “interactive” and “wireless” functions, you can throw your presentations wirelessly from a PC, Mac, iPad, iPhone, or Android devices to a projector! And use your pad, tab or phone to control your PC/Mac, or view the presenting slides! WPS Features Highlight: Icon Feature... -
Page 6: Package Contents
Basic Features Wireless screen and audio projection Remote desktop control feature Support Windows Win 8, Win7, Vista, XP Support Mac version 10.7 and above Plug and Show! No installation required … just plug in the accompanied token to a USB port, and hassle free presentation can be started in seconds. (Windows) WiFi-Doc Supportive for iOS/Android mobile devices Up to 30FPS high speed 4-to-1 Split Screen Projection. -
Page 7: Physical Details
SVS Driver (For Mac Virtual Extended Screen) Utility PtG Converter (For MobiShow PtG function) SNMP Manager (For SNMP Management) Physical Details Front Panel Power LED USB Port Description Power LED LED Indicator: System Loading(Red), Ready(Green) USB Port (Front) USB port for USB mouse and keyboard Rear Panel VGA Connector Audio Jack... -
Page 8: What You Might Need
Description Antenna WiFi Antenna USB Port (Rear) USB port for USB IWB device (HID type) RJ-45 10/100M RJ-45 port VGA Connector VGA connector HDMI HDMI Connector Audio Jack Audio Jack (3.5mm) Power Jack Power Jack (5V/2.6A) Bottom Side Screw hole Reset Button (Optional kit for Wall Mount) Description... -
Page 9: Quick Installation
Quick Installation 1) Connect WPS device to Projector/display through VGA/HDMI port and turn on projector/display power. 2) Connect the power adaptor to WPS device and press the power button to turn on WPS device. System will be ready when the LED light turns to green. ♦... -
Page 10: Wps Start/Standby Page
WPS Start/Standby Page 7.1 Quick Guide / User-List 1) Connect WPS device to Projector/Display through VGA/HDMI port and turn on Projector/Display power. 2) It will show the Quick Guide Information, WiFi Network Name, IP Address and Code on standby screen. 3) If there is sender connected to WPS device, it will show the User-List on standby screen, conference moderator can use the USB mouse to select the User and control it remotely. -
Page 11: Dowifi For Windows
DoWiFi for Windows (Do Not Support Windows Phone, Windows RT) 8.1 Install the application 1) Make sure your PC WiFi is enabled already, and connect your PC to WPS box through WiFi. You can find the WiFi name of your WPS box information on the start/standby page. -
Page 12: Start The Application
4) When the download is completed, follow the WPS Setup wizard to execute the software. (Make sure your Wifi have connected to WWPS and your PC’s personal firewall allows WPS software to pass through.) 8.2 Start the application 1) Click WPS icon on desktop to execute the application, or launch the application from USB token directly. -
Page 13: Quick Connect
2) It will start to search WPS receiver automatically. 8.3 Quick Connect 1) WPS will memorize the last successful connection profile and open the quick connect dialog, you can enter the code (you can find the information on the standby screen or start screen) and press the “Connect” button to connect this WPS directly. - Page 14 2) You can press the “Refresh” button to search again or press the “All” button to list all available WiFi Network name. 3) If you don’t like to change the WiFi Network and want to keep the connection to current network, you can press the “Skip” button.
-
Page 15: Connect To Receiver Device
8.5 Connect to Receiver Device 1) WPS application will search and list the WPS receiver Device. You can select the target receiver device and press “OK” button to connect the selected receiver device. 2) You can press the “Refresh” button to search again. 3) If you can’t find the target receiver device from the list, you can press the “Manual”... -
Page 16: Login
8.6 Login 1) When connecting to a “Code” protection enabled WPS receiver, you have to enter the “Code” and press the “Connect” button to login the receiver. (You can find the CODE from the OSD standby screen or right-upper corner of start screen) (Enter the code into the circled area) 2) If you want to connect to another receiver or cancel the login, please press the... -
Page 17: Screen Projection
8.8 Screen Projection 1) Click the “Play” button for full or “1,2,3,4” for split screen projection, you can project the main screen on to the display immediately. Click the “Pause” button, you can freeze you projection screen, and click the “Stop” button to stop projecting your screen. -
Page 18: Login Code
8.9 Login code Press on the login code, you can find the device IP address, SSID name and login code on the right of sidebar. The information will disappear after 30 seconds. When there are other users trying to login to the device, the information will pop up automatically for seconds and disappear again as well. -
Page 19: Show Receiver Information
3) The below items are checked as default setting. You can uncheck them to suit your needs. Item Advanced Screen Capture Send Audio to Display Auto Power Management Auto WiFi Connect 8.10.1 Show Receiver Information 1) Click on “Show Receiver Information”, it will display the Receiver Information, such as WiFi Name, IP Address and code on the upper corners of the projecting screen, and it will close automatically after 30 seconds. - Page 20 SidePad Control for Android/iOS device. Android: Download “SidePad Receiver” from Google Play Store iOS: Download “SidePad Receiver” from Apple Store. Connect your Android/iOS device to WPS device through WiFi and Launch “SidePad Receiver” Click on “Launch SidePad” from the menu. In seconds, you shall see the PC desktop shown on the iOS/Andriod Device.
-
Page 21: Launch Webslides
If there is no Smartphone/Pad device detected after clicking on “Launch SidePad” the below image will show up. 8.10.5 Launch WebSlides Introduction: Webslides is an application to allow the user/presenter to broadcast the projecting screen/slides to allow multiple login users to receive the slides during a presentation and save the slides for note taking later. - Page 22 3) Start to receive the presenter’s slides. The below image can be seen on the audience’s browser. Users can put the mouse/finger on each button to get the “tip window” for the function of each button. Note The WPS logged-in user is not identical to WebSlides user, and they both consume the wireless bandwidth for device connection.
-
Page 23: Select Projection Desktop
8.10.6 Select Projection Desktop 1) Click on “Select Projection Desktop”, you can select to project the main screen or the extended screen. Note: 1. For Windows XP system, you need to install “VDD.exe” driver first, you can find it from USB token. 2. -
Page 24: Resolution Settings
8.10.9 Resolution Settings 1) Click on “Resolution Setting”, choose “Never Change” to keep original desktop resolution, “Always Change” to change resolution automatically according to application’s recommendation, or “Always ask me” to prompt a resolution change message to user. 8.10.10 Projection Aspect Ratio 1) Click on “Projection Aspect Ratio”, choose “Keep aspect ratio”... -
Page 25: Advanced Screen Capture
8.10.12 Advanced Screen Capture 1) Click the “Advanced Screen Capture”, you will be able to see tip windows and other layered windows (include the main UI) on the connected display. However, the mouse cursor may blink from time to time when you are projecting your PC screen! Disable “Advanced Screen Capture”. -
Page 26: Auto Power Manager
Note: For Windows XP system, if you can’t hear the audio, please installs the Audio driver (“VAC.exe”, Virtual Audio Control Driver) on your computer first, you can find the software from USB Token. (Windows Vista, Win7 and Win8 is not necessary to install VAC driver) 8.10.14 Auto Power Manager 1) To make the highest projection performance, application will turn the PC’s windows power scheme from current settings to “highest performance”, however,... -
Page 27: Copy Application To Desktop
8.10.17 Copy Application to desktop 1) Click on “Copy Application to desktop”, it will copy the application to your desktop immediately. 8.10.18 Hot Key 1) Click on “Hot Key” to display the available Hot Key definition. -
Page 28: About
8.10.19 About 1) Click on “About” to show system information. It includes product model name, Application version, IP address and other information. 8.10.20 Exit 1) Click on “Exit” to exit this application. It will stop current playing status and shut down the application immediately. -
Page 29: Dowifi For Mac
DoWiFi for Mac 9.1 Install the application 1) Make sure your PC WiFi is enabled and connect your PC to WPS box through WiFi. 2) Launch your browser and enter the IP address on browser. You can find the IP address and Host Name (SSID) on the projector/display screen. -
Page 30: Start The Application
9.2 Start the application 1) Click on WPS icon from Application folder to execute the application. It will start to search WPS receiver automatically. 9.3 Quick Connect 1) WPS will memorize the last successful connection profile and open the quick connect dialog, you can enter the code (you can find the information on the standby screen) and press the “Connect”... -
Page 31: Connect To Wifi Network
1) If you want to connect to another WPS receiver, please press the “Rescan” button. 9.4 Connect to WiFi Network 1) WPS application will search the available WiFi Network and list the WPS WiFi Device. You can select a network and press the “Connect” button to connect the selected WiFi Device. -
Page 32: Connect To Receiver Device
3) If you don’t like to change the WiFi Network and want to keep the connection to current network, you can press the “Skip” button. 9.5 Connect to Receiver Device 1) WPS application will search and list the WPS receiver Device. You can select the target receiver device and press the “Connect”... -
Page 33: Login
2) You can press the “Refresh” button to search again. 3) If you can’t find the target receiver device from the list, you can press the “Manual” button to enter the receiver IP address manually and connect. 9.6 Login 1) When connecting to a “Code” protection enabled WPS receiver, you have to enter the “Code”... -
Page 34: Main User Interface
9.7 Main User Interface Login Code Menu Status Indicator Minimize the window Close the window Control Area for Screen Projection Feature 9.8 Screen Projection 1) Click the “Play” button for full or “1,2,3,4” for split screen projection, you can project the main screen on to the display immediately. Click the “Pause” button, you can freeze you projection screen, and click the “Stop”... -
Page 35: Login Code
Project to Split #3(No audio projection) Project to Split #4(No audio projection) Stop projecting Pause projecting Enable the Magnifier function Note: When projecting in full screen projection, if another user is clicking on the play button, the new user’s screen will replace the previous user’s screen for projection. -
Page 36: Show Receiver Information
2) You can click on the below function for extending menu to choose one to suit your needs. Function Select Projection Desktop Projection Quality Projection Mode Resolution Setting Projection Aspect Ratio 3) The below items are checked as default setting. You can uncheck them to suit your needs. -
Page 37: Web Admin
9.10.2 Web Admin 1) Click on “Web Admin”, it will open the browser and connect to the receiver web admin page automatically. (You can find more details of web admin page in Chapter 10-web Management.) 9.10.3 Search Receiver Device 1) Click on “Search Receiver Device”, it will disconnect from current receiver and search the receiver again. - Page 38 Click on “Launch SidePad” from the menu. In seconds, you shall see the PC desktop shown on the iOS/Andriod Device. Now you can control the projecting PC from your iOS/Android device. 3) If there is no Smartphone/Pad device detected after clicking on “Launch SidePad” the below image will show up.
-
Page 39: Launch Webslides
9.10.5 Launch WebSlides Introduction: Webslides is an application to allow the user/presenter to broadcast the projecting screen/slides to allow multiple login users to receive the slides during a presentation and save the slides for note taking later. Note: Webslides is not available when Quad view is in use. 1) Presenter: Make sure your PC/Mac is connected to WPS box and click on “Launch Webslides”, when the function is on, the item will be checked on the main menu. -
Page 40: Select Projection Desktop
audience’s browser. Users can put the mouse/finger on each button to get the “tip window” for the function of each button. Note The WPS logged-in user is not identical to WebSlides user, and they both consume the wireless bandwidth for device connection. If there are more than 10 users logged into WPS, it is recommended to connect WPS to company network through Ethernet or bridge WPS to a router due to wireless bandwidth concern. -
Page 41: Projection Quality
9.10.7 Projection Quality 1) Click on the “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best” for clear screen image quality but slower projection speed. 9.10.8 Select Projection Mode 1) Click on the “Select Projection Mode”, choose the Presentation mode for shortest latency or the Video mode for auto-latency control to have better video performance. -
Page 42: Projection Aspect Ratio
9.10.10 Projection Aspect Ratio 1) Click on the “Projection Aspect Ratio”, choose “Keep aspect ratio” to keep the original aspect ratio if the desktop resolution is different from WPS output resolution, or choose “Fit full screen” to project the screen to full screen.. 9.10.11 Send Audio to Display 1) Click on “Send Audio to Display”... -
Page 43: About
9.10.14 About 1) Click on “About” to show system information. It includes product model name, Application version, IP address and other information. 9.10.15 Exit 1) Click on “Exit” to exit this application. It will stop current playing status and shut down the application immediate. Web Management 10.1 Home Page... -
Page 44: Download
10.2 Download 1) Select “Download” function. 2) Please select the “Win 8/ Win 7 / Windows Vista / XP” or “Mac Utility” and execute the installation program. Note: Please disable the “Smart Screen Filter” on IE browser; otherwise you might not able to download the file. -
Page 45: Conference Control
10.3 Conference Control 1) Select “Conference Control” function, you can find the current connected user list on this page. 2) Enter password and then press [Login]. (default password: moderator) 3) After login, you can see a User List on the screen which indicates all of users connected to WPS box. -
Page 46: Admin
5) There are three columns, “User Name”, “Play Control” and “IP Address”. a. Play Control: There are six buttons, including Play(Full) , Screen #1 Screen#2 ,Screen #3 , Screen#4 and Stop b. Moderator can click on the “play” button to allow the projecting. c. -
Page 47: System Status
10.4.1 System Status 1) Click on “System Status” option, it will show current system status. Model Name: Product model name Versions: Firmware version no.: Product firmware version number. Network Status: IP address：IP address of WPS device. Subnet Mask：subnet mask Default Gateway：default gateway Wireless MAC address：wireless MAC address Wire MAC address：wire MAC address Connection Status:... -
Page 48: Device Setup
10.4.2 Device Setup 1) Click on “Device Setup” option, it will show the device setting items, ♦ Choose <VGA> or <HDMI> output option ♦ <Resolution>: VGA: UXGA(1600*1500), WXGA+(1440*900), WXGA(1360*768, 1280x768, 1280x800), XGA(1024*768), and SVGA(800*600). The default value is XGA(1024*768). HDMI: 720p, 1080i, 1080p ♦... -
Page 49: Network Setup
10.4.3 Network Setup 1) Click on “Network Setup” option, it will show the network setting items, < IP Setup> ♦ You can select “obtain IP address automatically” or “Use the following IP address” to enter the IP address. The default setting is as following: ♦... - Page 50 Start IP: 192.168.100.11 End IP: 192.168.100.254 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.100.10 DNS Server: 192.168.100.10 < Wireless Setup> ♦ Wireless LAN: The default setting is “Enable” ♦ SSID: You can change the default SSID and the maximum Length is 32 bytes. ♦...
- Page 51 ♦ “Internet Only” can block Guest Users (through wireless) from office network (LAN) but still reserve internet connection capability. <SNMP> You can select “Enable” or ”Disable” option to set up the SNMP function. And the SNMP community password is the same as the web Admin password. <Apply >: Press “Apply”...
-
Page 53: Osd Setup
10.4.4 OSD Setup 1) Click on “OSD Setup” option, you can: Change Standby Image ♦ Change Standby Image: Replace the whole standby image ♦ <Reset to default>: Restore to default Logo image. ♦ <Image File Upload>: Enter or browse the file name and upload the customized Logo Image. -
Page 54: Change Passwords
10.4.5 Change Passwords 1) Click on “Change Password” option, you can change the password setting for “conference control” and “Admin”. (Length: up to 8 characters) ♦ <Enter New Password> ♦ <Confirm New Password> ♦ <Apply>: Confirm and Save modifications. -
Page 55: Reset To Default
10.4.6 Reset to Default 1) Click on “Reset to Default” option to restore factory default settings. <Apply>: Confirm and take action. *** You can also restore factory default setting from WPS box reset button. You can find the reset button underneath the box. Please follow below procedures. 1. - Page 56 C. Click <Upgrade> to start. D. A warning message shown and countdown counter on the screen. E. After a few minutes, a complete message shown on the screen. F. Restart WPS box to take effect. Warning: Don’t power off WPS while firmware upgrade in progress, otherwise you will damage your box and have to return device to your vendor for fixing.
-
Page 57: Webslides Setup
10.4.8 WebSlides Setup 1) Click on “WebSlides Setup” option, you can: Adjust Auto Refresh Interval, or activate “Access Password Control” Please pay attention on the note for information. <Apply >: Press “Apply” button after configuration, and follow the reboot instruction when applicable. -
Page 58: Logout
10.4.10 Logout 1) Click on “logout” on the up right corner, you can logout the administration webpage and return back to the web management front page. -
Page 59: Webslides
10.5 WebSlides 1) Press the “WebSlides” button to enter the WebSlides page. 2) Please refer to 8.10.5 Launch Webslides for more information.
