SPECIFICATIONS
• Input: High Speed USB 2.0 connection - type B receptacle
• Output: switch selected, coaxial SPDIF - BNC, 75 or balanced AES type - XLR, 110
• Supported sampling rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• Supported word lengths: up to 24 bit
• Supported operating systems: Apple Macintosh, Microsoft Windows and Linux
• Enclosure dimensions: 2.3"H X 10.5"W x 5"D, 2.55"H including feet
• Mains power: 100 or 120 or 240 VAC, 50/60 Hz, IEC power input connector
• Power consumption: 3 Watts line, 1.5 Watts USB, designed for continuous operation
For further information on the Alpha USB, please contact Berkeley Audio Design, LLC at:
info@berkeleyaudiodesign.com or call 1-510-277-0512
© 2015 Berkeley Audio Design, LLC
