Birko USB 2.5 Operating Instructions

Operating & Cleaning Instructions
Birko DownUnder Under-Sink Boiling Water
Under-sink instant boiling water the simple way.

Key Features

Key Specifications

Please Read These Warnings First

Install - This way up

Positioning

Filtered boiling water always on tap - just push the button and out it flows.
Fashionable goose-neck tap for a smooth steady water flow - no spattering.
Stainless steel water tank and polished stainless steel under-sink cabinet.
Supplied complete with 5-micron inline filter, cupboard air vents and safe tray.
Model
Boiling water delivery (cups)
Boiling water capacity (litres)
Boiling water recovery (cup/hour) 120
Boiling water element (amps)
Supply voltage (volts)
Miniumum water pressure (bar)
Maximum water pressure (bar)
Cabinet height (mm)
Cabinet width (mm)
Cabinet depth (mm)
Safety tray height (mm)
Safety tray width (mm)
Safety tray depth (mm)
Read all installation instructions and precautions before installing any system.
Never attempt to install any system without reading all of the instructions.
All plumbing connections must be made in accordance with AS3500.
Do not install where water is microbiologically unsafe or of unknown quality.
The under-sink unit must be installed on a clear level surface.
Inline filter, safety tray and cupboard air vents supplied must be installed before operation.
The system is not intended for use by young children or infirm people without supervision.
This appliance is not intended for use by persons (Including Children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure they do not play with the appliance
If the power supply cord is damaged it must be replaced by a Birko Service Provider or
qualified technician.
Do not remove the cover of the under-sink unit under any circumstances without first
isolating the heater from the power supply.
Do not store detergents or other chemicals in the same cupboard as the under-sink unit.
Select a position for the tap where it will drain into a sink.
Preferred position is to the rear and left of the sink bowl.
Select a position for the under-sink unit as close as possible to immediately beneath the tap.
Under-sink unit must be on a level surface <1000 mm below top of tap.
The under-sink unit must be installed the correct way up so that all fittings are located at
the top.
USB 2.5 USB 5 USB 10
15 30 60
2.5 5 10
120 120
10 10 10
220-240 220-240 220-240
2 2 2
8 8 8
295 295 385
360 380 380
360 425 425
30 30 30
395 415 415
395 465 465
