- Page 1 CS-1X2HDMSPL HDMI 1.4 Splitter 1 x 2 User manual...
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. I. Introduction 1×2 HDMI Splitter distributes 1 HDMI source to 2 HDMI displays simultaneously.
- Page 3 II. Features 1. 1 HDMI input signal split to 2 HDMI sink devices. 2. HDCP 1.4 protocol compliant. 3. 3D HDMI 1.4a video format support. 4. 3D video support including frame packing for all 3D formats up to a 297MHz TMDS clock. 5.
- Page 4 III. Package 1. HDMI Splitter 1*2 --------------------------------- 1PCS 2. 5V1A DC Power Supply adapter ----------------- 1PCS 3. Operation Manual ---------------------------------- 1PCS IV. Specifications 1. Frequency Bandwidth 2.97Gbps 2. Input 1 x HDMI Female 3. Output 2 x HDMI Female 4. Power Supply DC 5V 1A 5.
- Page 5 6. Dimensions (mm) 60(W) X 70 (D) X 20 (H) 7. Weight 125g 8. Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F 9. Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F 10. Relative Humidity 20 ~ 90% RH (Non-condensing) 11.
- Page 6 connect the adapter to AC wall outlet. 3. HDMI Input: This slot is where you connect the HDMI source output from DVD, PS3 4. Input LED: This red LED illuminate when the HDMI signal plug in.
- Page 7 Rear Panel 1. Output 1: This slot is where you connect the HDTV or monitor with HDMI cable. 2. Output 1 LED: This red LED illuminate when the TV plug in HDMI output Port 1. 3. Output 2 LED: This red LED illuminate when the TV plug...
- Page 8 in HDMI output Port 2. 4.Output 2: This slot is where you connect the HDTV or monitor with HDMI cable. VI. Application Example 866-839-9187 460 Walker Street, Holly Hill, FL 32117...
