LG 55LF5700 Quick Setup Manual

1
INCLUDED ACCESSORIES
Remote control and two AAA batteries
+ +
A Carefully place your TV face-down on a
cushioned, clean surface.
A
TV stands
M5 screws (4 pcs.)
FEATURES
Power cord
Remote control sensor
WHAT YOU NEED
(not included)
Phillips screw driver
Wireless router*
Internet connection*
(needed for streaming)
(needed for streaming)
* Subscription or other payment
may be required to access
certain content.
FIND YOUR USER GUIDE ONLINE!
Go to http://www.lg.com/us .
Enter the TV model number in the
Search By Product field, then press
ENTER.
STOP
Do not plug your power cord in until all
other devices have been connected.
START HERE
How do I attach the stands to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver.
B Align the the TV stands with the screw holes on the bottom of the TV, then secure
the stands to the TV with the four provided screws.
M5 screws
Power indicator
RESET
MUTE
USB IN
HDMI 3
IN
3
OPTICAL
DIGITAL
AUDIO
OUT
HDMI1 (ARC) HDMI 2
VIDEO LEFT RIGHT
ANTENNA / CABLE
AV IN
HDMI IN
Before using your new product, please read these
instructions to prevent any damage.
B
R
L
M5 screws
MAKING CONNECTIONS
2
How do I watch TV (cable, satellite, or antenna) or connect a device such as a DVD or Blu-ray disc player, game console, or tablet?
WHICH CABLES
DO YOU HAVE? HDMI 3
IN
HDMI (BEST)
Best video quality
HDMI1 (ARC) HDMI 2
HDMI IN
AV
(GOOD)
COAXIAL
(GOOD)
CONNECTING AUDIO DEVICES
How do I connect my TV to external speakers?
3
USING DIGITAL AUDIO
OPTICAL
DIGITAL
AUDIO
OUT
Note: See the instructions that came with your speakers for more information.
WALL MOUNT
How do I prepare my TV for wall mounting?
You'll need: Soft surface and Phillips screwdriver.
A Carefully place your TV face-down on a cushioned, clean surface.
B See the instructions that came with your wall mount for more information about how to correctly mount your TV.
OR
A
B
Your TV has four VESA mounting holes on
the back. If you attach a wall-mount bracket
to the back of your TV, the bracket must be
securely attached, using all four holes.
If you do not use all four mounting holes,
your TV may fall and cause property damage
or personal injury. See the documentation
that came with your wall mount for complete
mounting instructions.
Multi-purpose jacks: You can plug any device that uses HDMI into any HDMI jack. However,
certain devices must be connected to the ARC jack. See the instructions that came with your
ARC-enabled device for more information.
HDMI1 (ARC) HDMI 2
LEFT RIGHT
VIDEO
ANTENNA / CABLE
HDMI IN AV IN
ANTENNA / CABLE
OPTICAL
INPUT
Quick Setup Guide
| 55LF5700
55" 1080p, 60Hz, LED TV
(not for use with a TV stand)
VESA Mounting Pattern
X4
VESA mount (mm): 400 × 200 -
M6 Type screws (not included)
AUDIO/VIDEO OUT
CABLE
SOUNDBAR
