Remote Keypad

You can connect up to four Safe House Remote Keypads to

your Burglar/Fire Alarm Control Center (RadioShack Cat. No.

49-485) so you can arm, disarm, and program your system from

four locations. Each remote keypad uses digital signals to com-

municate with the control center. This makes the system reli-

able and secure. Refer to the alarm center's instructions to

operate the keypad.

Choosing a Location

for the Remote Keypad

Follow these guidelines when you choose a location for the re-

mote keypad:

• Select a location that all family members can reach.

• Select a location that is near a main entrance.

• The remote keypad is not weatherproof. Do not install it

where it is exposed to excessive moisture.

• Select a location where the remote keypad is not exposed

to temperatures outside the range of 32° to 122°F.

RadioShack is a trademark used by Tandy Corporation.

Cat. No. 49-484

Table of Contents

Need help?

Do you have a question about the 49-484 and is the answer not in the manual?

Page 1 49-484.fm Page 1 Thursday, August 19, 1999 8:42 AM Cat. No. 49-484 Remote Keypad You can connect up to four Safe House Remote Keypads to your Burglar/Fire Alarm Control Center (RadioShack Cat. No. 49-485) so you can arm, disarm, and program your system from four locations.
Page 2 49-484.fm Page 2 Thursday, August 19, 1999 8:42 AM Connecting the Remote Keypad to the Control Center 1. Disconnect the control center’s AC power adapter and backup batteries. 2. Connect a separate wire to each terminal on the control center’s back. (For the easiest installation, use a different color wire for each terminal.)
Page 3 49-484.fm Page 3 Thursday, August 19, 1999 8:42 AM 4. If you want the keypad to sound tones when a day mode zone is violated and the system is disarmed, set Switch 3 . Otherwise, set it to 5. If you want the remote keypad to sound a tone during the...
Page 4 49-484.fm Page 4 Thursday, August 19, 1999 8:42 AM RadioShack Limited Warranty This security product is warranted against manufacturing defects in material and workmanship for ninety (90) days from the date of pur- chase from RadioShack company owned stores and authorized RadioShack franchisees and dealers.
