LEX Lighting LexLense 469 User Manual

DMX Controller Channel Modes
DMX Channels(slider)
Channel 1 0 - 4
5 - 255
Channel 2 0 - 255
Channel 3 0 - 4
5 - 255
0 - 35
Channel 4,5,6,7,8,9,10 & 11
36 - 49
(Note: Channel 1 must be 0 for these
channels to have effect)
50 - 255
Channel 12 0 - 49
(Note: when channel 12 is greater
50 - 91
than 50, other channels will have no
92 - 133
effect)
134 - 175
176 - 255
Lex Lighting Safety Instructions
1. Please keep this User Manual for future reference and be sure to pass this manual on to
anyone using the fixture.
2. Always make sure that you are connecting to the proper voltage as stated on the decal or rear
panel of the fixture.
3. This product is intended for indoor use only! To prevent risk of fire or shock, do not expose
fixture to rain or moisture.
4. Make sure there are no flammable materials close to the unit while operating.
5. The unit must be installed in a location with adequate ventilation, atleast 20inches (50 cm)
from adjacent surfaces. Be sure that no ventilation slots are blocked.
6. Always disconnect from power source before servicing or replacing fuse and be sure to
replace with same fuse rating.
7. Secure fixture to fastening device using a safety chain.
8. Maximum ambient temperature (Ta) is 104° F (40° C). Do not operate fixture at temperatures
higher than this.
9. In the event of a serious operating problem, stop using the unit immediately. Never try to
repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or
malfunction and will void your warranty. Please contact the nearest authorized technical
assistance center.
10. Never connect the device to a dimmer pack.
11. Make sure the power cord is never crimped or damaged.
12. Never disconnect the power cord by pulling or tugging on the cord.
13. Never carry the fixture directly from the cord. Always use the hanging/mounting bracket.
14. Avoid direct eye exposure to the light source while it is on.
Value Function
No Effect
Selects Pattern Modes
Speed of Chases
No Effect
Strobe Fast - Slow
No Effect
Spread Effect
Static Effect
No Effect
Red LED's
Green LED's
Blue LED's
All LED's
