Sony Ericsson Xperia Play Startup Manual

Welcome
Digital User guide for the
environment
As a step toward a more environment-friendly
approach we have focused on what you need to get
started in this Startup guide, and added a full digital
User Guide, one of our GreenHeart™ innovations, in
the phone and on our support web. We hope you
enjoy our efforts!
Important information
Please read the Important information leaflet
before you use your mobile phone.
Assembly
To remove the battery cover
You may need to press quite firmly when you're
removing the cover.
To insert the SIM card and the battery
PLAY
To attach the battery cover
Startup guide
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonyericsson.com
1237-1153.2
January 28, 2011 04:16:15 January 28, 2011 11:21:20
Phone basics
Phone overview
1
2
3
4
5
6
7
8
9
20
10
19
18
11
17
16
14 15
12 13
1. Light sensor/Proximity 11. Start key
sensor 12. Button
2. Ear speaker 13. Button
3. Front camera 14. Button
4. Directional buttons 15. Button
5. Headset connector 16. Back key
6. Game menu 17. Home key
7. Joystick 18. Menu key
8. Touch pad 19. Search key
9. Connector for charger/USB 20. Touch screen
cable
10. Select key
Turning on the phone
To turn on the phone
January 28, 2011 04:16:16 January 28, 2011 04:16:16
To enter your SIM card PIN code To scroll
• Tap the numbers on the screen to enter the
personal identification number (PIN) for your SIM
card.
To correct a mistake made while entering your
PIN, press .
Waking up the screen
To activate the screen
• Press or press briefly.
To unlock the screen
• Drag your finger in the direction you want to scroll
on the screen.
To scroll more quickly, flick your finger in the
• Drag the icon to the right across the screen.
direction you want to go on the screen.
Using the keys
To zoom with two fingers
Back • Go back to the previous screen
• Close the on-screen keypad, a
dialog box, an options menu, or
the Notification panel
• Place two fingers on the screen at once and pinch
Home • Go to the Home screen from any
application or screen them together (to zoom out) or spread them apart
• Open a window showing your (to zoom in).
most recently used applications
Use the zoom function when viewing photos
and maps, or when browsing the web.
Menu • Open a list of options available in
the current screen or application
Typing text
Search • Shortcut to Google™ Search
To display the keyboard to enter text
Using the touch screen
• Tap a text entry field.
Using the keyboard
To open or highlight an item
• Tap the item.
Q W E R
A S D F
Z X C
,
1
2 3
January 28, 2011 04:16:16
1 Change the character case and turn on the caps
lock. For some languages, this key is used to
access extra characters in the language
2 Close the keyboard view
3 Display numbers and symbols. Touch and hold
to display smileys
4 Enter a space
5 Open the input settings menu to change, for
example, the Writing languages or Quick text
settings
6 Enter a carriage return or confirm text input
7 Delete a character before the cursor
To change writing language
1 When you enter text, tap , or touch and hold
if you have already selected more than one
input language.
2 Tap Writing languages and select the languages
you want to use for writing.
If you have selected more than one input
language, tap to switch between the
selected writing languages.
To change quick text settings
1 When you enter text, tap , or touch and hold
.
2 Tap Quick text settings.
3 Select the desired settings.
Gaming
To launch the PlayStation® Pocket
• From your Home screen, tap , then find and tap
PlayStation® Pocket.
• From your Home screen, slide out the gaming
keypad. The PlayStation® Pocket starts
automatically.
If you don't want the PlayStation® Pocket to
start when you slide out gaming keypad, you
can disable this option in the PlayStation®
Pocket menu.
3G 12:45
T Y U I O P
G H J K L
V B N M
.
7
4 5 6
January 28, 2011 04:16:17 January 28, 2011 04:16:17
Set up your phone
The first time you start your phone, a setup guide
explains basic phone functions and helps you enter
essential settings. You can also access the setup
guide later.
To access the setup guide
1 From the Home screen, tap .
2 Tap Setup guide.
Android™ – what and why?
An Android™ phone is based on an open source
platform, and is pre-loaded with Google™ services.
To make the best out of any provided Google™
services, you should create a Google™ account and
sign in to it when you first start your phone. With the
account, you can extend the functionality of the
phone by downloading applications and games
from a constantly growing collection at Android
Market™. You need to have Internet access for
many of the features in Android.
Accounts and services
Use online services in your phone. Sign in with your
existing account or sign up and create an account.
Google™ account
Use Gmail™ to send emails, Google Talk™ to chat
with friends, and Android Market™ to download
applications.
Sony Ericsson account
Store your phone contacts on a secure Sony
Ericsson server, and you'll always have a backup
online. You can also store your phone calendar and
Internet bookmarks in your Sony Ericsson account.
Exchange Active Sync account
Synchronize your phone with your corporate
Exchange Active Sync account. This way, you keep
your work email, contacts and calendar events with
you at all times.
To add an account
1 From your Home screen, tap .
2 Tap Settings > Accounts & sync > Add
account.
3 Tap the account type you want to add and then
follow the registration wizard.
January 28, 2011 04:16:17
