With the purchase of this SUREFIRE flashlight,
you have invested in one of the world's best
"illumination tools."
We believe it to be a prime example of our
philosophy that design decisions should always
be made in the interest of the product being the
very best it can be.
Frequently, this means deciding to use a
more costly process or a more expensive
material than would normally be called for. We
have, however, learned that in order to produce
the best, one must do it right.
We thank you for supporting this decision
and electing to confirm our belief in "no
compromise" in a product that, by its
performance and reliability, may some day be
called upon to save your life.
There is no other choice.
MILLENNIUM
DEVASTATOR
Lithium Powered
225/350 Lumens
John Matthews
President, SUREFIRE
M4
TM
Advertisement
Table of Contents
Related Manuals for Superfire m4
Summary of Contents for Superfire m4
- Page 1 MILLENNIUM DEVASTATOR Lithium Powered 225/350 Lumens With the purchase of this SUREFIRE flashlight, you have invested in one of the world’s best “illumination tools.” We believe it to be a prime example of our philosophy that design decisions should always be made in the interest of the product being the very best it can be.
- Page 3 THE M4 DEVASTATOR The M4 Devastator can drive an intense, concentrated light beam deep into the night, revealing objects at over 100 yards. The M4 Devastator utilizes the exclusive SureFire beam that combines a brilliant prefocused spotlight center with a...
- Page 4 M4 DEVASTATOR There are two ways to activate the light from the M4. The Tail Cap switch of the Flashlight can be activated by rotating the Tail Cap in a clockwise direction for a constant “ON” setting or by pressing on the Push Button for temporary light.
-
Page 5: Specifications
SPECIFICATIONS Power Output MN60 - 225 Lumens MN61 - 350 Lumens Run Time MN60 - 60 Minutes MN61 - 35 Minutes Battery Type Lithium - DL123A Number Required Four (4) Supplied Length 8.9 inches Weight 11.3 ounces Diameter Body - 1.0 inch Bezel - 2.5 inch Lamp Assembly Xenon/Halogen... -
Page 6: Parts Replacement
PARTS REPLACEMENT Component Part No. Lithium Battery SF123A Bezel Assembly 13849-1 Flashlight Body 13690-1 225 lumen Lamp Assembly MN60 350 lumen Lamp Assembly MN61 Lanyard 12452-31 Lanyard Ring 12455-11 Rear O-Ring Seal (front) 19-01-040 Rear O-Ring Seal (end) 19-01-077 Front O-Ring Seal 19-01-028 Lock Out Tail Cap Assembly 12708-11... - Page 7 M4 DEVASTATOR BEZEL ASSEMBLY MN61 LAMP MN60 LAMP O-RING (front) BODY BATTERY (4) REAR O-RINGS TAIL CAP PUSH BUTTON...
-
Page 8: Changing The Lamp
CHANGING THE LAMP 1. Remove the Flashlight Bezel from the Flashlight Body by holding the Body and ro- tating the Head counterclockwise (as viewed from the front of the Flashlight) until it is free of the Body. 2. Remove the Lamp and replace with the desired Lamp. -
Page 9: Installing The Battery
3. Install the Flashlight Tail Cap back on to the Flashlight Body by turning it until the light comes on. Then back off 1/2 to 1 turn until the light goes off. 4. The M4 is now ready for use. TAIL CAP BATTERY BODY... -
Page 10: Customer Service
CUSTOMER SERVICE REPAIRS AND REPLACEMENTS To obtain repair or replacement contact Customer Service at 800-828-8809 (toll free) or 714-545-9444 and obtain a Return Authorization number (RA#). Then package the unit carefully and return (no COD’s please) SUREFIRE LLC Repairs Department, RA# ___ 18300 Mt. - Page 11 ACCESSORIES BeamFilters FM25 Red FM26 Blue FM23 Infrared Tip-Off Cover FM27 Polymer Holster Leather Holsters V16 Plain V17 Basketweave V18 Clorino Tail Cap Lanyard Ring Tail Cap Lanyard Kit Lanyard, Black Spares Carrier Hurricane™ Emergency Battery Pack Light (includes 12 each DL123A)
