Reverend Goblin Amplifier Owner's Manual
CAUTION!
Do not open amp chassis - risk of fatal electrical shock.
No user serviceable parts inside amp.
Never operate in damp or wet conditions.
Tube and chassis surfaces very hot.
High volume use can cause permanent hearing damage - always use ear protection.
SET-UP PROCEDURE
INSTALL POWER TUBES - To prevent damage, power tubes are shipped in boxes inside
cabinet.
• Lay amp face down on non-damaging surface. Be sure amp is unplugged.
• Unscrew and remove back panel.
• Install power tubes. Alignment pin protruding from center of tube MUST align with hole in
tube socket - pin has ridge that MUST align with groove in socket hole. Push tubes in firmly.
• Re-mount back panel.
POWER UP AMP - Plug in amp. Turn VOL all the way down. Make sure speaker is
connected to speaker jack. Turn amp on. Amp is now ready to use.
READ ENTIRE OWNER'S MANUAL BEFORE OPERATING! - Please read manual carefully
to achieve maximum performance and maintain safe operation of your amp.
FRONT CONTROL PANEL
POWER - Powers amp. WARNING: Always have a speaker connected to the amp before
turning on, otherwise serious damage could occur to amp! VOL should be turned all the way
down before turning amp on or off. Leave amp on during short break periods, simply turn off
the volume on your guitar or amp.
SCHIZO - Can be switched while amp is on.
US - Transparent midrange with strong bass and treble for classic American clean
and light overdrive.
LO-FI - Softer treble and stronger midrange, for a bluesy grind reminiscent of
vintage off-brand American amps.
UK - Even more gain with a distinctly British upper-mid peak for classic blues-rock
and hard-rock crunch.
GAIN - Controls the amount of overdrive. Higher settings produce more distortion, lower
settings produce a cleaner sound. GAIN will affect the volume level, but this can be adjusted
with the VOL control.
VOL - Controls the overall volume. For the cleanest possible sound set VOL to maximum and
use the GAIN control as your volume control.
TREB - Controls treble frequencies. TREB control is more responsive when the MID control
is at lower settings.
