BUILD IN APPLIANCES
FOR USE WITH LIQUIFIED PETROLEUM GAS
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
MODELS
OH90000 (LPG)
OH91000 (DUAL FUEL)
USER AND INSTALLATION INSTRUCTIONS
FOR USE IN: - GB, IE, FR, NL, BE, LU, ES, IT, NO, DE, DK, SE
•
Read the instructions before use
•
Only use appliance in a well ventilated area
•
Install the appliance in accordance with the regulations in force
SPINFLO LIMITED, 19 Oakham Drive, Parkwood Industrial Estate
Rutland Road, Sheffield S3 9QY, ENGLAND.
TEL: + 44 (0) 114 273 8157
N
L E I S U R E
WARNING
FAX: + 44 (0) 114 275 3094
Advertisement
Summary of Contents for spinflo OH90000
- Page 1 Only use appliance in a well ventilated area • Install the appliance in accordance with the regulations in force SPINFLO LIMITED, 19 Oakham Drive, Parkwood Industrial Estate Rutland Road, Sheffield S3 9QY, ENGLAND. TEL: + 44 (0) 114 273 8157...
- Page 4 ………………………………………………… Installation Instructions ………………………………………………… Maintenance & Servicing ………………………………………………… SPECIFICATION TRIPLEX TRIPLEX Model OH90000 OH91000 External Dimensions, mm 468 x 456 x 500mm 468 x 456 x 500mm (HxWxD) Oven Capacity, litres Grill 2, Oven 4 Grill 2, Oven 4 No. of tray positions...
- Page 5 INTRODUCTION This appliance must be installed in accordance with the local, national and European regulations in force. Particular attention shall be given to the requirements regarding ventilation. Read the instructions before installing or using the appliance The appliance is designed for either high or low level installations. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.
- Page 6 OPERATION WARNING • Accessible parts may be hot when the grill is used, young children should be kept away. • When cooking always ensure young children are kept away. Ensure the gas cylinder is turned on. In the event of a gas smell, turn off at the cylinder and contact supplier. The burners on this appliance have fixed aeration and no adjustment is required.
- Page 7 OPERATION WARNING • Glass lids may shatter when heated. Turn off the hotplate and allow it to cool before closing the glass lid. • Remove all spillage from the surface of the glass lid before opening. Using the Electric Hotplate Ensure the electricity is switched on.
- Page 8 OPERATION 3. For models fitted with Spark Ignition the procedure is similar except that the burner can be ignited by depressing the ignition button, which is located on the fascia. Ignition must be carried out with the door open, and if the burner has not lit within 15 seconds the control knob should be released and the grill left for at least 1 minute before a further attempt to ignite the burner.
- Page 9 OPERATION 4. Place the oven shelf in the required position and close the door. Set control knob to approximately gas mark 5 and heat the oven for about 30 minutes to eliminate any residual factory lubricants that might impart unpleasant smells to the meals being cooked.
- Page 10 OPERATION Do's And Don'ts read the user instructions carefully before using the appliance for the first time. allow the oven to heat before using for the first time, in order to expel any smells before the introduction of food. clean the appliance regularly. remove spills as soon as they occur.
- Page 11 INSTALLATION Regulations and Standards In your own interest of safety, it is law that all gas appliances are installed and serviced by competent persons. CORGI (Confederation for the Registration of Gas Installers) and N.I.C.E.I.C. (National Inspection Council for Electrical Installation Contracting) registered installers undertake to work to safe and satisfactory standards.
- Page 12 Fixing screw positions are located as follows. Appliance Front Fixed Appliance Side Fixed Appliance 2 front fix holes each side of 2 side fix holes each side of OH90000 & Oven opening Oven opening OH91000 2 fix holes each hotplate side trim...
- Page 13 MAINTENANCE & SERVICING This appliance needs little maintenance other than cleaning. All parts should be cleaned using warm soapy water. Do not use abrasive cleaners, steel wool or cleansing powders. When cleaning the burner ring it is essential to ensure that the holes do not become blocked.
- Page 14 MAINTENANCE AND SERVICING 6. Spark Ignition (where fitted) Disconnect from gas supply (1). Remove appliance from housing (2). Grill burner – At rear of appliance remove the screw from the bracket and spark ignition probe. Trace the electrode wire back to the generator and pull off the connector.
