Shift Line OLYMPIC mkII Owner's Manual

7
8
Shift Line Olympic mkII
sound quality and wide commutation possibilities. This device has proved itself on a stage as good as at home
and studio usage.

MAIN FEATURES:

• 12AX7 Tung-Sol tube stage and high-voltage circuit with specially designed transformer.
• Series effects loop
• XLR balanced (DI) output for recording or sending to mixer console (with switchable ground lift).
• PHONES output and AUX input are ideal for silent training
Great tone, incredibly low noise level, wide commutation options and XLR output in housing of usual stomp pedal.

CONTROLS:

1. IN — 1/4" TS jack input for signal source. Preampli-
fier could be used with active or passive electric bass
guitar and acoustic instruments with piezo pickup.
2. SEND —1/4" TS jack output to external effects
(modulation, delay, reverb, etc.). Could be used as
additional -20 dBu output.
3. RETURN — 1/4" TS jack input from external effects.
SEND/RETURN jacks forms post-EQ series effects
loop.
4. AUX — 1/8" TRS auxiliary input jack for drum
machine, metronome, MP3 player or other signal.
Shift Line OLYMPIC mkII
6 5 4
11
13
is a compact studio-grade tube bass guitar preamplifier which combines perfect
tube bass preamplifier
Owner's Manual
3 2
12
5. PHONES — 1/8" TRS jack for headphones. Output
level is set by MASTER knob.
6. OUT — 1/4" TS jack output with high-level signal
(+20 dBu). Designed to be connected directly to power
amplifier, POWER AMP IN or loop RETURN jack of
bass head or combo amplifier.
7. BALANCED OUT — XLR balanced (DI)
output (+10 dBu) for recording applications. Balanced
output level is preset and is not affected by MASTER
knob. XLR signal is post-EQ.
8. POWER IN — Connect 12 V AC 750 mA power
adapter here (use original adapter included or adapters
recommended by Shift Line)
1
10
9
