STAINLESS STEEL
GAS-FIRED LOW-INTENSITY INFRA-RED
FOR EITHER INDOOR OR OUTDOOR INSTALLATION
SSTG (Straight Tube)
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
Read the installation, operating, and maintenance instructions thoroughly before installing or servicing this
equipment.
FOR YOUR SAFETY
•
If you smell gas: open windows; don't touch electrical switches, extinguish any open flames; evacuate the
structure; call your gas supplier immediately.
WARNING – NOT FOR RESIDENTIAL USE
•
Failure to comply with instructions could result in unsafe operation, property damage, personal injury, and/or
death. A gas-fired appliance could expose you to substances in fuel or from fuel combustion, which have
been determined by the State of California to cause cancer, birth defects or other reproductive harm. For
industrial or commercial use only.
•
Retain these instructions for future reference. Contact factory for further information.
IMPORTANT
•
Have a qualified electrician check the electrical supply circuit and wall receptacle are properly grounded and
the electrical supply polarity is correct. The heater control is polarity sensitive and will not operate properly if
the electrical supply is not wired correctly.
HAZARD INTENSITY LEVELS
•
DANGER: Failure to comply will result in severe personal injury or death and property damage.
•
WARNING: Failure to comply could result in severe personal injury or death and/or property damage.
•
CAUTION: Failure to comply could result in minor personal injury and/or property damage.
RADIANT TUBE HEATERS
INSTALLATION, OPERATION, &
MAINTENANCE INSTRUCTIONS
! WARNING !
Form SST-IOM-14
STAINLESS
SSTG/U
SSTU (U-Tube)
900040
Advertisement
Table of Contents
Related Manuals for Solaronics SSTG
Summary of Contents for Solaronics SSTG
- Page 1 RADIANT TUBE HEATERS FOR EITHER INDOOR OR OUTDOOR INSTALLATION INSTALLATION, OPERATION, & MAINTENANCE INSTRUCTIONS SSTG (Straight Tube) SSTU (U-Tube) ! WARNING ! Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating, and maintenance instructions thoroughly before installing or servicing this equipment.
-
Page 2: Fire Or Explosion Hazard
WARNINGS • Protect yourself and others by observing all safety information. WARNING CAUTION FIRE OR EXPLOSION HAZARD MECHANICAL HAZARD • Can cause property damage, severe injury or DO NOT use high pressure to test the gas death. pipes with the burner still attached. This will •... - Page 3 TABLE OF CONTENTS • This instruction manual may not cover all details or variations in this equipment, or cover every possible situation to be met in connection with installation, operation, or maintenance. Should problems arise that are not covered sufficiently in these instructions, the purchaser is advised to contact the factory’s engineering department for further information.
- Page 4 GENERAL INFORMATION AND INSTALLATION CODES AIRCRAFT HANGARS ATTENTION These overhead heaters are suitable for use in aircraft hangars when installed in accordance with the Standard on Mount a copy of these instructions adjacent to heater Aircraft Hangars, ANSI / NFPA 409-latest edition, and are and retain a copy for future reference.
-
Page 5: Installation Codes
CANADIAN CODES • The information on this page applies specifically to installations in Canada. INSTALLATION CODES • These infrared heaters are CSA International Design Certified and manufactured for either indoor or outdoor installation in compliance with the Standard for Gas-Fired Low-Intensity Infrared Heaters CSA 2.34-latest edition. If you have any questions call factory before attempting installation. -
Page 6: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES* 0° MOUNTING 1°-30° MOUNTING 31°-45° MOUNTING CLEARANCES FOR ALL HEATERS* inches (cm) FRONT FRONT FRONT TOP OF REFLECTOR 12 (31) REAR REAR REAR BELOW BELOW BELOW END OF BURNER 12 (31) • Reflector width = 15.75” (40cm) •... -
Page 7: Mounting Considerations
MOUNTING CONSIDERATIONS • Clearance to combustible materials must be maintained. • Mounting heights lower than the recommended Minimum Height may be used if personnel are not kept directly under heater. • The Distance From Wall measurement provides the most effective heat dispersion balance between the floors and walls. - Page 8 OVERVIEW DRAWINGS (1 OF 2) ROOF VENTING CAP MUST BE 6" (15CM) HIGHER THAN SNOW DEPTH. "B" VENT PIPE ADAPTOR ROOF FLASHING (NOT SUPPLIED) ALL HANGING CHAINS MUST BE PLUMB AND VERTICAL IN ALL DIRECTIONS WHEN INITIALLY INSTALLED USE A SAFETY CHAIN WITH ENOUGH SLACK AS INDICATED. SAFETY CHAIN [MUST BE 1/0 TENSO AND HAVE A MINIMUM WORKING LOAD RATING OF 200 LBS.
- Page 9 OVERVIEW DRAWINGS (2 OF 2) MAINTAIN 18 INCH (46 CM) MINIMUM CLEARANCE TO COMBUSTIBLES FOR ENTIRE LENGTH OF PIPING DO NOT PINCH THE HANGER BETWEEN THE FLANGES! FOR ALL INDOOR JOINTS, USE RTV SEALANT TO PREVENT HOT FLUE GAS LEAKAGE INTO THE BUILDING (USE A SHEET METAL HOOK OF HANGER PIPE AND CRIMPER FOR JOINING IDENTICAL SIZE SHEET METAL PIPES) MUST BE CLOSED...
-
Page 10: Combustion Air Supply
COMBUSTION AIR SUPPLY GENERAL NOTES MAXIMUM LENGTH OF AIR SUPPLY PIPE • Uncontaminated atmospheric 40 to 125 MBTUH (12 – 37 kW) 35 linear ft. (10.7 m)* combustion may come from either outdoors or 130 to 200 MBTUH (38 – 59 kW) 40 linear ft. -
Page 11: Exhaust Venting
EXHAUST VENTING OUTDOOR EXHAUST VENTING MAXIMUM LENGTH OF EXHAUST VENT PIPE 40 to 125 MBTUH (12 – 37 kW) 35 linear ft. (10.7 m)* • 130 to 200 MBTUH (38 – 59 kW) 40 linear ft. (12.2 m)* A heater operating with positive vent static pressure and a vent gas temperature that avoids excessive condensate production in the vent is *Each 90 degree elbow inserted in the venting system... - Page 12 ELECTRICAL SUPPLY AND THERMOSTATIC CONTROL ELECTRICAL SUPPLY 120 VAC THERMOSTATIC CONTROL • Voltage: 120 VAC – 1 phase – 60 Hz. DUAL SYSTEM ONLY GREEN (GROUND) • Maximum Amps: 3.0 (1.33 actual full load BURNER amps). • Flame safety: Electronic. WHITE (NEUTRAL) •...
-
Page 13: Operation And Shutdown
OPERATION AND SHUTDOWN SEQUENCE OF OPERATION WIRING CONNECTION DIAGRAM • If any of the original wire as supplied with the appliance must be replaced, it must be replaced with Thermostat calls for heat. wiring material having a temperature rating of at least 302°F (150°C) and shall have a minimum •... - Page 14 GAS SUPPLY AND GAS PRESSURE GAS SUPPLY PIPING INLET GAS PRESSURE • • Gas piping must be installed in accordance with local codes Inlet gas pressure must be measured on the inlet side of the and/or the National Fuel Gas Code, ANSI Z223.1 / NFPA 54- valve at the inlet test point (IP).
- Page 15 STARTUP STARTUP PROCEDURES SPARK IGNITOR • CAUTION: Verify electrical supply is shut off before removing burner cover. Verify gas supply is shut off before removing gas pipe plugs and connecting manometers to measure gas pressures. • IMPORTANT: Check serial plate for requirements and factory settings. Check and, if necessary, adjust the inlet gas pressure BEFORE checking the manifold gas pressure.
-
Page 16: Maintenance
MAINTENANCE • FOR SAFETY REASONS, BEFORE PERFORMING ANY MAINTENANCE, DISCONNECT AND LOCKOUT THE ELECTRICAL SUPPLY, INCLUDING THE THERMOSTAT, BY POSITIVE MEANS. • All maintenance and/or repair MUST be performed by someone trained and qualified to work on gas and electrical equipment. -
Page 17: Troubleshooting
TROUBLESHOOTING • Check for symptoms and possible causes in the order presented from the top of this chart to the bottom. • The symptoms and possible causes are in a logical progressive order as in a flow chart. SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION New installation. -
Page 18: Replacement Parts
REPLACEMENT PARTS ! WARNING ! Any substitutions of factory-installed parts without prior written permission may result in unsafe operation, property damage, personal injury, death, voids CSA design certification, and manufacturer’s warranty. Gas valve 12. Safety chain bracket with nuts Gas manifold assembly with flare nuts 13. -
Page 19: U' Tube Configuration
WINDY CONDITION NOTES REFLECTOR 12'' 12'' (30 CM) (30 CM) MIN. MIN. BRACKET REFLECTOR BRACKET SCREW BRACKET END VIEW BURNER NEAR LOADING DOCK, AIRPLANE HANGAR DOORS, SECOND CHAIN OR OTHER WINDY AREAS FASTEN THE REFLECTORS CONFIGURATION TO THE REFLECTOR SUPPORT BRACKETS WITH TEK SCREWS OR OTHER POSITIVE MEANS. -
Page 20: U-Tube Installation
U-TUBE INSTALLATION • A heater may be installed as a U-Tube with its radiant tubes horizontal or with the heat exchanger angled above the combustion chamber as illustrated by the drawing below. • When radiant tubes are horizontal, reflectors may be individually rotated from 0 to 30 degrees or from 0 to 45 degrees depending on the model installed. -
Page 21: Configuration Diagrams
HEATER CONFIGURATIONS • Tube heaters can be arranged in many configurations; some common ones are illustrated below. It is important to limit the number of bends since each bend slows the movement of air inside the tube, resulting in decreased efficiency. •... - Page 22 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 23: Basic System Configurations
BASIC SYSTEM CONFIGURATIONS • Stainless steel tube and reflector components are designated with a “SR” suffix, i.e. “C9SR”. • A metal turbulator is always in the LAST 10-foot (3.0m) long tube section. • These are the recommended configurations for your heater. Contact the factory with any questions. •... - Page 24 COMBUSTION CHAMBERS 40 MBTUH (10 and 15 ft. units only) 40 thru 60 MBTUH (20 ft. units only) [12 kW (3 and 4.6 m only)] [12-18 kW (6.1 m only)] 65 thru 85 MBTUH (20 and 25 ft. MB units only) [19-25 kW (6.1 and 7.6 m MB only)] C9SR C2SR...
-
Page 25: Heat Exchangers
HEAT EXCHANGERS 65 thru 200 MBTUH (30 thru 70 ft. units except 40 MBTUH (ONLY 15 ft. end tube) H2SR H6SR MC units) [19-59 kW (9.1-21.3 m except MC)] [12 kW (ONLY 4.6 m end tube)] 65 thru 200 MBTUH (25 thru 70 ft. units) (MIDDLE) (MIDDLE) [19-59 kW (7.6-21.3 m)]... - Page 26 INSTALLATION (1 OF 2) CAUTION • DO NOT use gas piping or electrical conduit to provide any type of support for the heater’s suspension. • Means of suspension MUST BE able to support twice the weight of the heater, securely fastened to the building’s structure, and allow for expansion during its operation.
-
Page 27: Basic System
INSTALLATION (2 OF 2) STEP SAFETY CHAIN Lift the burner into place and suspend it by inserting the S- BLOWER hook of the safety chain into the center hole of the safety MOTOR ENCLOSURE chain bracket, and then crimp the hook closed. Insert the burner tube into the tube clamp at the burner end of the SAFETY combustion chamber. - Page 28 Copyright © 2008, Solaronics, Inc. 704 Woodward Ave., Rochester, Michigan MI 48307 USA Toll Free: 1-800-223-5335 Phone: 1-248-651-5333 Fax: 1-248-651-0357 E-mail: sales@solaronicsusa.com...
