Supero X7SBT User Manual

Hide thumbs Also See for X7SBT:
Table of Contents

Advertisement

Quick Links

Download this manual
X7SBT
X7SBT-10G
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X7SBT and is the answer not in the manual?

Questions and answers

Related Manuals for Supero X7SBT

Summary of Contents for Supero X7SBT

  • Page 1 X7SBT X7SBT-10G USER’S MANUAL Revision 1.0a...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    Memory supports Non-ECC unbuffered 1600 MHz up to 4GB in 2 DIMMs or DDR3 1333/1066/800 MHz up to 8GB in 4 DIMMs With a Core™ 2 processor built-in, the X7SBT/X7SBT-10Gb support Wide Dynamic Execution, FSB Dynamic Bus Inver- sion (DBI), and Advanced Digital Media Boost, Smart Memory Access, and Thermal Management 2 (TM2).

  • Page 4: Table Of Contents

    Chapter 1: Introduction 1-1 Overview ......................1-1 Checklist ....................1-1 Contacting Supermicro ................1-2 X7SBT/X7SBT-10G Image ............1-3 X7SBT/X7SBT-10G Motherboard Layout ........1-4 X7SBT/X7SBT-10G Quick Reference ........1-5 Motherboard Features ................1-6 Block Diagram ..................1-8 1-2 Chipset Overview ....................1-9 1-3 Special Features ....................
  • Page 5 Table of Contents Universal Serial Bus (USB) ..............2-17 Fan Headers ..................2-18 Chassis Intrusion..................2-18 Serial Ports ....................2-19 Power Supply I C Connector..............2-19 GLAN 1/2 (Ethernet) Ports ............... 2-20 10Gb_LAN Port ..................2-20 SMB ......................2-21 VGA Connector ..................
  • Page 6 X7SBT/X7SBT-10G User's Manual 4-5 Security Settings ....................4-21 4-6 Boot Setup ......................4-22 4-7 Exit ........................4-23 Appendices: Appendix A: BIOS POST Beep Codes ..............A-1 Appendix B: Installing the Windows OS ..............B-1 Appendix C: Installing Other Software Programs and Drivers........C-1...

  • Page 7: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.

  • Page 8: Contacting Supermicro

    X7SBT/X7SBT-10G User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.
  • Page 9 Note: The drawings and pictures shown in this manual were based on the latest PCB Revision available at the time of publishing of the manual. The motherboard you’ve received may or may not look exactly the same as the graphics shown in the manual. There is a diffrent image for X7SBT-10G...
  • Page 10 • " " indicates the location of Pin 1. • The 10G CX4 connector is only available on the X7SBT-10G. • You cannot use both 20-pin power connecors located at JWR1 (right side con- nector), and JWR2 (left side connector) as input power supply connectors at the same time.

  • Page 11: X7Sbt/X7Sbt-10G Quick Reference

    JUSB4, JVGA1 Video Graphics Connector JWR1/JWR2 Primary 20-pin ATX Power Connector LAN1/LAN2 Ethernet RJ45 (Gigabit LAN) Connectors LAN3/10GbE 10Gb Ethernet Connector (For X7SBT-10G only) SATA 0-3 SATA Ports SIMSO SIMSO IPMI Socket SKPR1 Internal Buzzer T-SGPIO 1 Serial General Purpose Input Output Header...

  • Page 12: Motherboard Features

    1600 MHz up to 4GB in 2 DIMMs or DDR3 1333/1066/800 MHz up to 8GB in 4 DIMMs Note: X7SBT supports DDR3 up to 1600 MHz. You can only install up to two 1600 MHz modules with one module in DIMM1B slot or DIMM2B slot or with...
  • Page 13 Chapter 1: Introduction • Slow blinking LED for suspend state indicator • BIOS support for USB keyboard • Main switch override mechanism ACPI Features • Slow blinking LED for suspend state indicator • Main switch override mechanism • BIOS support for USB keyboard •...

  • Page 14: Block Diagram

    X7SBT/X7SBT-10G User's Manual LGA 775 1600/1333/1066 MT/S GEN2 PCI-EXP X16 PORT B 1600/1333/1066 North Bridge 10G port 10G Port 10.0 Gb/S GEN2 PCI-EXP X8 JLAN0 CTRL PORT A 1600/1333/1066 (for 10G only) for 10G only Intel PCI-EXP X1 JLAN2 LAN1...

  • Page 15: Chipset And Processor Features Overview

    775 Land Array Package, is comprised of two primary components: the Memory Controller Hub (North Bridge) and the I/O Controller Hub (South Bridge). The X7SBT/X7SBT - 10G provides the performance and feature-set required for the mainstream server market. Memory Controller Hub (X48/North Bridge) The function of the MCH is to manage the data fl...

  • Page 16: Special Features

    Control setting in the Advanced BIOS Setup section to change this setting. The default setting is Last State. PC Health Monitoring This section describes the PC health monitoring features of the X7SBT/X7SBT- 10G. All have an onboard System Hardware Monitor chip that supports PC health monitoring.

  • Page 17: Acpi Features

    You can also confi gure Supero Doctor to provide you with warnings when the system temperature goes beyond a pre-defi...

  • Page 18: Power Supply

    Power Supply As with all computer products, a stable power source is necessary for proper and reliable operation. It is even more important for processors that have high CPU clock rates. The X7SBT/X7SBT-10G can only accommodate Supermicro proprietary power supplies. 1-12...

  • Page 19: Chapter 2: Installation

    Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system board, it is important to handle it very carefully. The following measures are generally suffi cient to protect your equipment from ESD. Precautions •...

  • Page 20: Motherboard Installation

    X7SBT/X7SBT-10G User's Manual Motherboard Installation Note: Be sure to mount the motherboard into the chassis before you install the CPU onto the motherboard. All motherboards have standard mounting holes to fi t different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match.
  • Page 21 Chapter 2: Installation Installing the LGA 775 Processor Load Lever PnP Cap on top of the Load Plate 1. Press the load lever to release the load plate, which covers the CPU socket, from its locking position. 2. Gently lift the load lever to open the load plate.
  • Page 22 X7SBT/X7SBT-10G User's Manual 4. Align CPU Pin1 (the CPU corner marked with a triangle) against the socket corner that is marked with a Socket Key triangle cutout. (Socket Notch) 5. Align the CPU key that is the CPU Key (semi-...
  • Page 23 Chapter 2: Installation Installing the Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die, the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism.
  • Page 24 X7SBT/X7SBT-10G User's Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow these instruc- tions below to prevent damage to the CPU or the CPU socket.

  • Page 25: Installing Dimms

    Both Unbuffered ECC and Non-ECC memory modules will boot up. How- ever, ECC functionality is not supported on this board. The X7SBT/X7SBT-10G supports DDR3 up to 1600 MHz. You can only install up to two 1600 MHz modules with one module in DIMM1B slot or...
  • Page 26 X7SBT/X7SBT-10G User's Manual Possible System Memory Allocation & Availability System Device Size Physical Memory Remaining (-Available) (4 GB Total System Memory) Firmware Hub fl ash memory (System 1 MB 3.99 BIOS) Local APIC 4 KB 3.99 Area Reserved for the chipset 2 MB 3.99...

  • Page 27: Control Panel Connectors And Io Ports

    Chapter 2: Installation Control Panel Connectors /IO Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See the graphics below for the colors and locations of the various I/O ports. Back Panel Connectors/IO Ports SIMSO DIMM1A DIMM1...

  • Page 28: Front Control Panel

    X7SBT/X7SBT-10G User's Manual Front Control Panel JF1 contains header pins for various buttons and indicators that are normally lo- cated on a control panel at the front of the chassis. These connectors are designed specifi cally for use with Supermicro server chassis. See the fi gure below for the descriptions of the various control panel buttons and LED indicators.

  • Page 29: Front Control Panel Pin Defi Nitions

    Chapter 2: Installation Front Control Panel Pin Defi nitions NMI Button NMI Button Pin Defi nitions (JF1) The non-maskable interrupt button Pin# Defi nition header is located on pins 19 and 20 NMI Control of JF1. Refer to the table on the right for pin defi...

  • Page 30: Hdd Led

    X7SBT/X7SBT-10G User's Manual HDD LED The HDD LED connection is located HDD/UID LED on pins 13 and 14 of JF1. Attach a Pin Defi nitions (JF1) hard drive LED cable here to display Pin# Defi nition disk activity. See the table on the right 3.3 Vcc...

  • Page 31: Overheat/Fan Fail Led

    Chapter 2: Installation Overheat/Fan Fail LED (OH) OH/Fan Fail LED Pin Defi nitions (JF1) Connect an LED to the OH/Fan Fail Pin# Defi nition connection on pins 7 and 8 of JF1 to 3.3 Vcc provide advanced warnings of chassis OH/Fan Fail LED Indicator overheating or fan failure.

  • Page 32: Reset Button

    X7SBT/X7SBT-10G User's Manual Reset Button Reset Button The Reset Button connection is located Pin Defi nitions (JF1) on pins 3 and 4 of JF1. Attach it to the Pin# Defi nition hardware reset switch on the computer Reset Signal case. Refer to the table on the right for Ground pin defi...

  • Page 33: Connecting Cables

    Chapter 2: Installation Connecting Cables 20-pin Proprietary Power 20-pin Main Power Connector Pin Defi nitions Connectors Pin# Defi nition Pin # Defi nition There are two 20-pin main power supply PS On Ground connectors (JWR1, JWR2) and a 4-pin 5VSB Ground auxiliary power connector (JP1) on the Ground...

  • Page 34: 4-Pin Auxiliary Power Connector

    X7SBT/X7SBT-10G User's Manual 4-pin Auxiliary Power Connector In addition to two 20-pin power connec- tors, a 4-pin 12V PWR supply is located 4-Pin Power at JP1 on the motherboard. This power Pin Defi nitions connector is used to provide power sup- ply to hard drive disks.

  • Page 35: Universal Serial Bus (Usb)

    Chapter 2: Installation Universal Serial Bus (USB) Back Panel USB There are eight USB 2.0 (Universal Serial (JUSB1) Bus) ports/headers on the motherboard. Pin# Defi nitions Two of them are Back Panel USB ports: USB 0/1 (JPUSB1). Two are Front Acces- sible USB ports USB4, USB6 (JUSB5, JUSB6 resp).

  • Page 36: Fan Headers

    X7SBT/X7SBT-10G User's Manual Fan Headers The X7SBT/X7SBT-10G has three sys- tem fan headers (Fans 1 to Fan 3) that 4-pin Fan Header support 4-pin fans. See the table on the Pin Defi nitions right for pin defi nitions. Pin# Defi nition...

  • Page 37: Serial Ports

    Chapter 2: Installation Serial Port Serial Port Pin Defi nitions COM1 (U15) is located at the IO Pin # Defi nition Pin # Defi nition backpanel and COM2 is a header located at U16. See the table on the right for pin defi ntions Ground (Pin 10 is available on COM2 only.

  • Page 38: 10Gb_Lan Port

    LAN1/LAN2 on the I/O backplane. These ports accept RJ45 type cables. GLAN1 GLAN2 10Gb_LAN Port (For X7SBT-10G Only) In addition to the two GLAN ports men- tioned above, a 10_ Gigabit LAN w/CX4 interface is located at LAN3 on the I/O backplane.

  • Page 39: Smb

    Chapter 2: Installation SMB Header Pin Defi nitions A System Management Bus header Pin# Defi nition is located at JSMB1. Connect the Data appropriate cable to utilize SMB on Ground your system clock No Connection VGA Connector A VGA connector (JVGA1) is located next to the COM1 port on the IO backplane.

  • Page 40: Jumper Settings

    X7SBT/X7SBT-10G User's Manual Jumper Settings Explanation of Jumpers Connector To modify the operation of the mother- Pins board, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to Jumper change the function of the connector.

  • Page 41: 10Gb_Lan Enable/Disable

    Chapter 2: Installation 10Gb_LAN Enable/Disable (For 10Gb_LAN Enable X7SBT-10G Only) Jumper Settings Pin# Defi nition JPL3 enables or disables the 10 Giga- Enabled (default) bit_LAN Port (LAN3) on the mother- Disabled board. See the table on the right for jumper settings. The default setting is Enabled.

  • Page 42: Watch Dog

    X7SBT/X7SBT-10G User's Manual Watch Dog Enable/Disable Watch Dog Jumper Settings Watch Dog is a system monitor that can Jumper Setting Defi nition reboot the system when a software ap- Pins 1-2 Reset plication hangs. Close pins 1-2 of Jumper (default)

  • Page 43: Pci/Pci-E Slots To Smb Speed

    Chapter 2: Installation PCI/PCI-E Slots to SMB Speeds SMBus to PCI-X/PCI-Exp Slots Jumper Settings Jumpers JI 2 C1/JI 2 C2 allow you to con- Jumper Setting Defi nition nect PCI/PCI-Exp. Slots to the System Closed Enabled Management Bus. The default setting is Open Disabled (Default) open to disable the connection.

  • Page 44: Onboard Indicators

    X7SBT/X7SBT-10G User's Manual L i n k Activity Onboard Indicators GLAN LEDs Rear View There are two GLAN ports on the (when viewing from the back of the chassis.) motherboard. Each Gigabit Ethernet LAN port has two LEDs. The yellow...

  • Page 45: Onboard Power Led

    Chapter 2: Installation Onboard Power LED Onboard PWR LED Indicator LED Settings An Onboard Power LED is located at LED Color Defi nition LED2 on the motherboard. When this LED System Off (*PWR cable Indicator is on, the system is on. Be sure not connected) to unplug the power cable before remov- Green...

  • Page 46: Simso Ipmi Connection

    X7SBT/X7SBT-10G User's Manual SIMSO IPMI Connection SIMSO IPMI Slot There is a SIMSO IPMI Slot on the motherboard. Refer to the layout be- low for the IPMI Slot location. A. SIMSO IPMI slot SIMSO DIMM1A DIMM1 DIMM1B DIMM2 DIMM2A DIMM3...

  • Page 47: Chapter 3: Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any hardware components.

  • Page 48: No Video

    X7SBT/X7SBT-10G User's Manual The battery on your motherboard may be old. Check to verify that it still sup- plies ~3VDC. If it does not, replace it with a new one. No Video If the power is on, but you have no video--in this case, you will need to re- move all the add-on cards and cables fi...

  • Page 49: Losing The System's Setup Confi Guration

    Chapter 3: Troubleshooting Losing the System’s Setup Confi guration Make sure that you are using a high quality power supply. A poor quality power supply may cause the system to lose the CMOS setup information. Refer to Section 1-6 for details on recommended power supplies. The battery on your motherboard may be old.

  • Page 50: Frequently Asked Questions

    1600 MHz up to 4GB in 2 DIMMs or DDR3 1333/1066/800 MHz up to 8GB in 4 DIMMs. Please note that X7SBT supports DDR3 up to 1600 MHz. You can only install up to two 1600 MHz modules with one module in DIMM1B slot or DIMM2B...
  • Page 51 Chapter 3: Troubleshooting For faster service, RMA authorizations may be requested online (http://www.super- micro.com/support/rma/). This warranty only covers normal consumer use and does not cover damages in- curred in shipping or from failure due to the alteration, misuse, abuse or improper maintenance of products.
  • Page 52 X7SBT/X7SBT-10G User's Manual Notes...

  • Page 53: Chapter 4: Bios

    Chapter 4 BIOS Introduction This chapter describes the Phoenix BIOS™ Setup utility for the X7SBT. The Phoe- nix ROM BIOS is stored in a fl ash chip and can be easily upgraded using a fl oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 54: Running Setup

    X7SBT/X7SBT-10G User's Manual Running Setup Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choosing the ap- propriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see the next page).
  • Page 55 Chapter 4: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate fi elds. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year fi...
  • Page 56 X7SBT/X7SBT-10G User's Manual Native Mode Operation Select the native mode of operation for the installed ATA device(s). The options are: Auto, and Serial. Note: Auto may cause Linux to recognize SATA hard drives as IDE drives SATA RAID Enable This setting allows you to enable or disable the SATA RAID functionality. The op- tions are Disabled and Enabled.

  • Page 57: 4-4 Advanced Setup

    Chapter 4: BIOS LBA Mode Control This item determines whether the Phoenix BIOS will access the IDE Primary Master Device via the LBA mode. 32 Bit I/O This option allows the user to enable or disable the function of 32-bit data transfer.

  • Page 58: Boot Features

    X7SBT/X7SBT-10G User's Manual Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the above display. The items with a triangle beside them have sub- menus that can be accessed by highlighting the item and pressing <Enter>.

  • Page 59: Advanced Processor Options

    Chapter 4: BIOS ACPI Mode Use the setting to determine whether you want to use the ACPI (Advanced Con- fi guration and Power Interface) power management on your system. The options are Yes and No. Power Button Behavior If set to Instant-Off, the system will power on or power off immediately as soon as you hit the power button.
  • Page 60 X7SBT/X7SBT-10G User's Manual Frequency Ratio (Available when supported by the CPU) The feature allows you to set the internal frequency multiplier for the CPU. The feature depends on the CPU fl exibility. The options are: Default, x6, x7, x8, x9, x10 and x11.
  • Page 61 Chapter 4: BIOS No Execute Mode Memory Protection (Available when supported by the CPU and the OS) Set to Enabled to enable Execute Disable Bit and allow the processor to classify areas in memory where an application code can execute and where it cannot, and thus preventing a worm or a virus from inserting and creating a fl...

  • Page 62: Advanced Chipset Control

    X7SBT/X7SBT-10G User's Manual ® Intel Virtualization Technology (Available when supported by the CPU) Select Enabled to use the feature of Virtualization Technology to allow one plat- form to run multiple operating systems and applications in independent partitions, creating multiple virtual systems in one computer. The options are Enabled and Disabled.
  • Page 63 Chapter 4: BIOS USB Host Controller This feature enables or disables the USB Controller in Dev 29 Function 0,1,2,3,7. The options are Enabled and Disabled. Memory Cache Cache System BIOS Area This setting allows you to designate a reserve area in the system memory to be used as a System BIOS buffer and allow BIOS to write (cache) data into this reserved memory area.
  • Page 64 X7SBT/X7SBT-10G User's Manual 512K-640K. Select Write Back to allow the CPU to write data back directly from the buffer without writing data to the System Memory for fast CPU data process- ing and operation. The options are Unchached, Write Through, Write Protect, and Write Back.
  • Page 65 Chapter 4: BIOS Enable Master This setting allows you to enable the selected device as the PCI bus master. The options are Enabled and Disabled. Latency Timer This setting allows you to set the clock rate for Bus Master. A high-priority, high- throughout device may benefi...

  • Page 66: Console Redirection

    X7SBT/X7SBT-10G User's Manual Base I/O Address This setting allows you to select the base I/O address for Serial Port B. The options are 3F8, 2F8, 3E8 and 2E8. Interrupt This setting allows you to select the IRQ (interrupt request) for Serial Port B. The options are IRQ3 and IRQ4.
  • Page 67 Chapter 4: BIOS Console Type This setting will enable you to set the console redirection type. The options are VT100, VT100 (8bit), PC ANSI (7bit), PC ANSI, VT100+, VT-UTF8 and ASCII. Flow Control This setting enables you to select the fl ow control option for the console. The op- tions are: None, XON/XOFF, and CTS/RTS.
  • Page 68 X7SBT/X7SBT-10G User's Manual CPU Temperature This item displays the level of CPU temperature (High, Medium, Low) as detected by the BIOS. The information shown in the screen is for your reference only. (See the notes below for more information on DTS and PECI) Low –...
  • Page 69 The following items will be monitored and displayed: Vcore A, 12V, Vdimm, 5V, 3.3V, 1.25V, 3.3Vsb, Vbat Note: In the Windows OS environment, the Supero Doctor III settings take pre- cedence over the BIOS settings. When fi rst installed, Supero Doctor III adopts the temperature threshold settings previously set in the BIOS.
  • Page 70 X7SBT/X7SBT-10G User's Manual IPMI (The option is available only when an IPMI card is installed in the system.) Firmware Version: This item displays the current Firmware Version. System Event Logging Select Enabled to enable IPMI Event Logging. When this function is set to Disabled, the system will continue to log events received via system interface.
  • Page 71 Chapter 4: BIOS BIOS POST Errors Enabling this function to log POST errors. The options are Enabled and Dis- abled. OS Boot Watch Dog Set to Enabled to enable OS Boot Watch Dog. The options are Enabled and Disabled. Timer for Loading OS (Minutes) This feature allows the user to set the time value (in minutes) for the previous item: OS Boot Watch Dog by keying-in a desired number in the blank.
  • Page 72 X7SBT/X7SBT-10G User's Manual ID, SEL Record Type, Time Stamp, Generator ID, SEL Message Revision, Sensor Type, Sensor Number, SEL Event Type, Event Description, and SEL Event Data. Realtime Sensor Data This feature display information from motherboard sensors, such as temperatures, fan speeds and voltages of various components.

  • Page 73: Security Settings

    Chapter 4: BIOS Security Settings Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Security setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section.

  • Page 74: Boot Settings

    X7SBT/X7SBT-10G User's Manual Set User Password When the item Set User Password is highlighted, hit the <Enter> key. When prompted, type the user's password in the dialogue box to set or to change the user's password, which allows access to the system at boot-up.

  • Page 75: Exit

    Chapter 4: BIOS an USB device, either fi xed or removable. You can select one item from the boot list and hit the <x> key to remove it from the list of bootable devices (to make its resource available for other bootable devices). Subsequently, you can select an item from the candidate list and hit the <x>...
  • Page 76 X7SBT/X7SBT-10G User's Manual Load Setup Defaults Highlight this item and hit <Enter> to load the default settings for all items in the BIOS Setup. These are the safest settings to use. Discard Changes Highlight this item and hit <Enter> to discard (cancel) any changes you made. You will remain in the Setup utility.

  • Page 77: Recoverable Post Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS POST Error Beep Codes This section lists POST (Power On Self Test) error beep codes for the Phoenix BIOS. POST error beep codes are divided into two categories: recoverable and terminal. This section lists Beep Codes for recoverable POST errors.
  • Page 78 X7SBT/X7SBT-10G User’s Manual Notes...

  • Page 79: Appendix B: Installing The Windows Os

    Appendix B: Installing the Windows OS Appendix B Installing the Windows OS After all hardware components have been installed, you must fi rst confi gure Intel South Bridge RAID Settings before you install the Windows OS and other software drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides posted on our website at www.supermicro.com/support/manuals.
  • Page 80 X7SBT/X7SBT-10G User's Manual Installing the Windows XP/2000/2003 OS for Systems without RAID Functions Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the system will start booting up from CD. Continue with the OS installation. The Windows OS Setup screen will display.

  • Page 81: Appendix C: Installing Other Software Programs And Drivers

    Appendix C: Installing Other Software Programs and Drivers Appendix C Installing Other Software Programs and Drivers C-1 Installing Drivers other than the Adaptec Embedded Serial ATA RAID Controller Driver After you've installed the Windows Operating System, a screen as shown below will appear.
  • Page 82 The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 83 Supero Doctor III Interface Display Screen-II (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our website at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/ SDIII/UserGuide.pdf. For Linux, we will still recommend that you use Supero Doctor II.
  • Page 84 X7SBT/X7SBT-10G User's Manual Notes...
  • Page 85 The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
