OPERATING INSTRUCTIONS
FREE STANDING FRYERS
MODELS: AF822 Twin Tank
Version 1 units
Special Features:
Swing Up Ultra-Durable Stainless Steel Elements
Easy Clean Tank with Lockable 1" Drain
Adjustable Legs & Rear Castors
Digital LED Temperature Displays
Fish Plate & Fish Plate Lifter
Stainless Steel Baskets
Strainer
These instructions cover the models of High Performance Free Standing Deep
Fryers listed above. Although there are slight variances between models, the
installation, operation, care and maintenance procedure is the same for all.
Advertisement
Table of Contents
Summary of Contents for AUSTHEAT AF822 Twin Tank
-
Page 1: Operating Instructions
OPERATING INSTRUCTIONS FREE STANDING FRYERS MODELS: AF822 Twin Tank Version 1 units Special Features: Swing Up Ultra-Durable Stainless Steel Elements Easy Clean Tank with Lockable 1” Drain Adjustable Legs & Rear Castors Digital LED Temperature Displays Fish Plate & Fish Plate Lifter... - Page 2 Facsimile: 61 – 2 – 9971 7211 ® © Copyright 2013 – Austheat All rights reserved. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical, including photocopying or posting to a website, without the written permission of the publisher.
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ..................5 GENERAL PRECAUTIONS ..............5 PACKAGING .................... 6 COMPLIANCE ..................6 C-Tick: ........................6 ACSS (Advance Control Safety System): ..............6 INSTALLATION ..................7 Before Connection to Power Supply ................7 Electrical Connection ....................7 Electrical Requirements .................... 8 GENERAL ARRANGEMENT .............. - Page 4 Liquid Vegetable Oils ....................15 Hardened/Creamed Vegetable Oils................. 15 Saving Costs, Improving Oil Life and Increasing Efficiency ..... 15 TIPS ON DEEP FRYING ................ 16 GENERAL SAFETY ................18 SAFETY FEATURES ................18 GENERAL FIRE SAFETY ..............18 COOKING SAFETY................18 CLEANING, CARE &...
-
Page 5: Introduction
INTRODUCTION Congratulations on your purchase of this quality AUSTHEAT ® product. With proper care and management your new purchase will give you years of trouble free service. By reading these instructions carefully you can ensure that this machine is used and maintained properly, helping your new investment to perform well for you now, and to continue performing in the many years to come. -
Page 6: Packaging
PACKAGING ® All care is taken when packing and Austheat ensures that every unit is functional and undamaged at the time of packaging. The Package of these Fryers should include: One AF822 Fryer 2 Tank Lids 2 Fryer Baskets This manual... -
Page 7: Installation
INSTALLATION Before Connection to Power Supply Remove all the packaging materials and tape, as well as any protective plastic from the machine. Clean off any glue residue left over from the protective plastic using methylated spirit. Place the free standing fryer on a firm, level floor in the required position. The legs can be adjusted for slightly uneven floors. -
Page 8: Electrical Requirements
Electrical Requirements The following table shows the electrical requirements for your fryer. Model Total Power Amps/Phase Supply AF812 15 kW 20.8 A 400-415 V AC, 3 Phase + N + E AF812R 18 kW 25 A 400-415 V AC, 3 Phase + N + E AF813 18 kW 25 A... -
Page 9: Control Panel Layout
The unit can be moved by lifting from underneath the front, just above the door, and pulling it along on the rear castors. CONTROL PANEL LAYOUT Take a moment to familiarise yourself with the general arrangement of the fryer before going any further. The controls are located behind the door on the front of the fryer. -
Page 10: Thermostats
Thermostats These fryers have 4 thermostats 2 primary and 2 secondary. There is one primary and one secondary thermostat per tank. Only one thermostat per tank is in use at a time. The thermostat selector switch on the front display panel is used to select which thermostat is used to control the fryer. -
Page 11: What To Do If The Thermal Cut-Out Trips A Second Time
again, continue to step 4. If no cut-out occurs within an hour, continue to use the machine and monitor the temperature of the oil. 4. If the unit has activated the Thermal cut-out switch twice in a short time, set the thermostat selector switch to the SECONDARY/IDLE position. -
Page 12: Temperature Display
Temperature Display The temperature displays can be seen on the display panel, located on the front of the fryer above door. It displays the current temperature of the oil in each tank. OPERATION Oil Level A raised form on the inner left hand side of the left tank and the inner right hand side of the right tank indicates the oil level range. -
Page 13: Filling With Solid Oil And Using The Melt Cycle
Filling with Solid Oil and using the Melt Cycle If solid oil or shortening is preferred this may be melted after filling by using the melt switch and the following procedure. • Ensure all controls are OFF, the drain valves are closed and the elements are cold. -
Page 14: Tips For Healthy Frying
Once the fryer has reached the set temperature, it is ready for cooking to commence. The set temperature will be displayed on the temperature display panel. Note: the temperature displayed will fluctuate and will not display a static value equal to the set temperature of the thermostat. Lower the filled baskets into the oil carefully and do not over fill them. -
Page 15: Liquid Vegetable Oils
Liquid Vegetable Oils While most vegetable oils are recommended for cooking, many of them are not suitable for deep-frying. Higher temperatures break down the oil faster and by-products often have an unpleasant flavour and may also have an association with increased risk of heart disease. Hardened/Creamed Vegetable Oils These products may have a longer fry life than their liquid oil equivalents, but the components added during the hardening process increase the risk... -
Page 16: Tips On Deep Frying
TIPS ON DEEP FRYING 1. Use thick, straight cut chips (greater than 13mm) or wedges • Thin chips and crinkle chips absorb more oil and therefore use up more oil from the fryer • If the chips are frozen, don’t thaw. Water from thawed chips damages the oil 2. - Page 17 6. Drain food well • Vigorously shake the basket of cooked food twice and hang it for at least 20 seconds over the hot fryer. This returns some oil to the fryer 7. Look for signs of oil degradation • If the oil is damaged (eg dark colour, smoking) discard it all. 8.
-
Page 18: General Safety
GENERAL SAFETY ® This machine contains no user-serviceable parts. Austheat Australia, one of our agents, or a similarly qualified person(s) should carry out all repairs. Any repair person(s) should be instructed to read the Safety warnings within this manual before commencing work on these units. -
Page 19: Cleaning, Care & Maintenance
WARNING: Ensure that oil is changed or filtered regularly. Old or dirty oil has a lower flash point and is more prone to surge boiling. WARNING: Always be careful when cooking frozen or over-wet food products as these items are more prone to surge-boiling and are more likely to result in the “spitting”... -
Page 20: Troubleshooting
should be carried out by a suitable person conversant with the latest Standard updates. TROUBLESHOOTING If the fryer does not function check the following points before calling for service. The power is switched “on”, both on the unit and at any other point that supplies power to the machine (eg an isolating switch on the wall). -
Page 21: Circuit Diagram
CIRCUIT DIAGRAM Models: AF822 Note: These circuit diagrams have been provided for reference and to assist qualified service and repair agents only. Under no circumstances should a person not suitably qualified attempt repairs to any electrical equipment. Page 21... -
Page 22: Specifications
SPECIFICATIONS Constant Research & Development may necessitate machine changes at any time Page 22... -
Page 23: Exploded Diagrams
EXPLODED DIAGRAMS AF822 Page 23... -
Page 24: Control Panel Complete
CONTROL PANEL COMPLETE Page 24... -
Page 25: Element Box
ELEMENT BOX Page 25... -
Page 26: Electrical Box Assembly
ELECTRICAL BOX ASSEMBLY Page 26... -
Page 27: Notes
Notes Page 27... -
Page 28: Warranty Terms
® Under no circumstances shall Austheat Australia Pty Ltd or any subsidiary company or Agent be liable for loss of profit or damage to other equipment and property.
