OPERATION and MAINTENANCE
INSTRUCTION MANUAL
AA-98 AirPac II Compressor 220V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AA-98 AirPac II and is the answer not in the manual?

Questions and answers

Related Manuals for Aseptico AA-98 AirPac II

Summary of Contents for Aseptico AA-98 AirPac II

  • Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL AA-98 AirPac II Compressor 220V...

  • Page 2: Table Of Contents

    Set Up & Operation ....3 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com Maintenance ....4 220V Specifications .

  • Page 3: Introduction

    Performance in tandem with portability make the Aseptico AA-98 AirPac II oilless 3/4 horsepower compressor perfect for the professional. The compressor is secured in its own pull or carrying case and includes an air storage tank, a cooling fan, and an automatic pressure switch control.

  • Page 4: Set Up & Operation

    SET-UP & OPERATION 1. Unpack the compressor and locate the remote power cord. 2. Plug the power cord into the receptacle on the outside of the unit and then into a grounded power outlet. 3. To activate the AA-98 compressor, flip the power switch to the on (I) position.

  • Page 5: Maintenance

    MAINTENANCE: AIR STORAGE TANK - To avoid the risk of moisture in the air lines or tank failure, drain the tank after each use or every four hours of operation. This will DRAIN FITTING prevent condensation build-up and corrosion inside the tanks. To drain the tank, allow the compressor to fully pressurize and then turn the power switch to the off (O) position.
  • Page 6 ELECTRICAL - The motor of this compressor has a thermal overload protector. If the motor should overheat, the overload protector will shut off the motor. If this should occur, turn the compressor off immediately and allow the motor to cool. Check the circuit breakers, they may need to be reset.

  • Page 7: Aa-98 220V Specifications

    AA-98 220V SPECIFICATIONS: Single cylinder, 3/4 hp., Oilless compressor-100 PSI Displacement- 4.1 CFM (116 LM) Electrical- 220 volt AC, 50 Hz Air Delivery- 1.20 CFM at 100 PSI (60 LM at 689 KPa) 1.85 CFM at 50 PSI (74.2 LM at 345 KPa) Circuit Breakers- 10 Amps, Quantity 2 Amps at Working Pressure- 5.1 Amps Maximum pressure- 100 PSI...

  • Page 8: Warranty

    Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
