Specification
Model
NGSV-AVS60S50
Pick up Element
1/3" SONY CCD
Effective Picture Elements
PAL:500(H)×582(V) NTSC:510(H)×492(V)
(H×V)
Horizontal Resolution
500TV Line
Minimum Illumination
0.0005Lux
S/N Ratio
More than 48dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
IR Distance
60 Meters (with ￠42X2PCS Infrared LED)
IR Status
Under 10Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
DC12V (+/-10%)/1000mA
Lens
CS Lens 8mm/F2.0
Dimension (mm)
225(W)x175(H)x95(D)mm
Weight (g)
1800
Storage Temperature
-20~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
Packing List
No
Name
1.
Weatherproof IR Color Camera
NGSV-AVS60S50
2.
User Guide
NGSV-AVS60S50
Manufacturer：
Model
Number
1
Website: www.ngsvision.com.ve
Email: producto@ngs.com.ve
1
NGSV-AVS60S50 Color Camera
Weatherproof IR Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Advertisement
Summary of Contents for NGS NGSV-AVS60S50
- Page 1 Specification Model NGSV-AVS60S50 NGSV-AVS60S50 Color Camera Pick up Element 1/3" SONY CCD Effective Picture Elements PAL:500(H)×582(V) NTSC:510(H)×492(V) (H×V) Horizontal Resolution 500TV Line Minimum Illumination 0.0005Lux S/N Ratio More than 48dB Scanning System 2:1 interface Weatherproof IR Color Camera Synchronous System Internal, Negative sync.
- Page 2 INTRODUCTION CONNECTING Congratulations on your purchase of this product. * Sensor (CCD) This User Guide suits NGSV-AVS60S50 series product. We adopt the latest SONY technical of sensor and driver. Adopt 1/3" SONY CCD Sensor. Video The most attractive characteristics are small and easy hidden, suits the elevator and corridor.
