FP91E
LCD Color Monitor
19.0" LCD Panel Size
User's Manual
Welcome

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP91E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BenQ FP91E

Summary of Contents for BenQ FP91E

  • Page 1 FP91E LCD Color Monitor 19.0" LCD Panel Size User’s Manual Welcome...

  • Page 2: Power Safety

    Copyright Copyright © 2004 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

  • Page 3: Table Of Contents

    Table of Contents Getting started ........................5 Getting to know your Monitor .................... 7 Front View ........................7 Back View (1) .......................7 Back View (2): Locations of plugs & sockets ..............8 How to install your monitor hardware ................9 Adjusting the viewing angle ..................10 How to install your monitor’s software ................
  • Page 4 Table of Contents...

  • Page 5: Getting Started

    Getting started When unpacking please check you have the following items. If they are missing or are damaged, please immediately contact the dealer at which you purchased the goods. BenQ LCD Monitor Quick Start Guide CD-ROM Disk Power Cord Signal Cable: D-Sub...
  • Page 6 Signal Cable: DVI-D Audio Cable Getting started...

  • Page 7: Getting To Know Your Monitor

    Getting to know your Monitor Front View Back View (1) Getting to know your Monitor...

  • Page 8: Back View (2): Locations Of Plugs & Sockets

    Back View (2): Locations of plugs & sockets 1. Audio Connector 2. Power AC Input Jack 3. DVI-D Connector 4. D-Sub Connector Getting to know your Monitor...

  • Page 9: How To Install Your Monitor Hardware

    How to install your monitor hardware Make sure that the computer and monitor's power are both turned off. Please go along with the following steps to install your LCD monitor. 1. Unpack the monitor and place it on a stable surface. 2.

  • Page 10: Adjusting The Viewing Angle

    4. Connect an earphone into the earphone jack located on the underside of the control panel as shown. 5. Press the Power button on the front panel of the monitor. The power indicator will light up. Adjusting the viewing angle Your LCD monitor is designed with a tilt feature that allows you to achieve your optimal viewing angle.

  • Page 11: How To Install Your Monitor's Software

    8. By pressing “OK” again in the next window you will be given a list of compatible devices. Select “FP91E” from the list and press “Next” again. 9. An “Insert Disk” dialogue box appears. Click “OK”, and then click “Skip File”.
  • Page 12 10. Scroll down and select your CD ROM Driver, then click “Next” . 11. In the list of folders within the CD-ROM, select “Drivers” folder then click “Open” twice, then click “OK”. Select your LCD Model (FP91E) from the list in the next window then click “Next” twice.
  • Page 13 8. Click “Have disk” and then click “Browse...”. 9. Insert “BenQ LCD Monitor’s CD” into your CD-ROM and type d:\ (change the driver letter to match your CD-ROM driver if it is not drive D). Enter “Drivers” folder to select the model from the list left.
  • Page 14 5. In the next window, click “Have Disk…”, an “Install From Disk” window will pop up. Click “Browse”. The “Locate File” window will pop up. 6. Select “FP91E”. and then click “Next”. 7. The new drivers are now installed to your computer. Click “Finish” to exit installation.

  • Page 15: Choosing The Best Picture Resolution

    Due to the nature of LCD display technology, the picture resolution is always fixed. The best picture possible for your FP91E is achieved with a resolution of 1280x1024. This is called “Native Resolution” or maximal resolution - that is, the clearest picture. Lower resolutions are displayed on a full screen through an interpolation circuit.
  • Page 16 3. Select a resolution of 1280x1024. Then click “Apply”. 4. In the subsequent windows, press “OK” and “Yes” 5. You can now close “Display Properties”. Choosing the best picture resolution...

  • Page 17: How To Choose The Right Refresh Rate

    How to choose the right Refresh Rate You don't have to choose the highest possible refresh rate on an LCD display, because it is not technically possible for an LCD display to flicker. The best results are obtained by using the factory modes already set in your computer.
  • Page 18 2. From the “Display Properties” window, select the “Settings” tab. Click the “Advanced...” button in the bottom right corner. How to choose the right Refresh Rate...
  • Page 19 3. Select the “Adapter” tab. The refresh rate selection field is located in the center at the bottom of the window. 4. Choose a refresh rate from the table with the factory modes, which can be found in the user’s guide, and select this in the settings field.

  • Page 20: How To Set The Picture Optimization

    How to set the Picture Optimization ikey ikey The easiest way to obtain an optimal display is to use the function. Press the “ ” on the control panel and the monitor will adjust automatically. If you are still not satisfied with the result, you can still adjust the image manually. 1.

  • Page 21: How To Adjust Your Monitor

    How to adjust your Monitor A Look at the Control Panel iKey There are 7 keys for user’s control including “Enter”, “ ” , “ ”, “Exit” , “Mode” , “ ” and a power switch. The following descriptions are the introduction of these keys & switch. iKey 1.

  • Page 22: Main Menu Mode

    Press to enter Contrast menu, press to adjust the degree of Contrast and press “Exit” to leave the OSD. Volume hot key Press “Exit” to enter Volume menu. Press key to adjust the degree of volume and press “Exit” to exit the OSD. Mode hot key Select your desired mode from these four options: Standard, Movie 1, Movie 2, and...
  • Page 23 Luminance sub menu Press key to adjust the degree of Brightness, press “Exit” to return to the previous menu. Press key to adjust the degree of Contrast, press “Exit” to return to the previous menu. Geometry sub menu How to adjust your Monitor...
  • Page 24 Press key to adjust the Horizontal Position, press “Exit” to return to previous menu. Press key to adjust the Vertical Position, press “Exit” key to return to previous menu. Press key to adjust the value of the Pixel Clock, press “Exit” to return to previous menu.
  • Page 25 Color sub menu User Preset: User may set the color balance of Red, Green and Blue. How to adjust your Monitor...
  • Page 26 OSD sub menu Press key to adjust the Horizontal Position of the OSD, press “Exit” to return to previous menu. Press key to adjust the Vertical Position of the OSD, press “Exit” to return to previous menu. Press key to adjust the display time of the OSD, press “Exit”...
  • Page 27 Language sub menu Recall sub menu Press key to confirm Mode Recall. When you choose "Yes", it will recall the current mode to default settings. Press “Exit” will return to previous menu. Press key to confirm Color Recall. When you choose "Yes", it will recall the current color settings to default settings.
  • Page 28 Press key to confirm Recall All. When you choose "Yes", it will recall all the current settings to default settings. Press “Exit” will return to previous menu. Miscellaneous sub menu Mode: Select your desired mode from these four options: Standard, Movie 1, Movie 2, and Photo.
  • Page 29 Mode Demo: Mode Demo allows you to preview the effects of the selected Mode from Mode menu. When you choose "On" and press "Enter" to activate Mode Demo, the display will be divided into two windows; the left window demonstrates images of Standard mode, while the right window presents the images under the specified mode.
  • Page 30 Audio sub menu Volume: Press key to adjust the degree of Volume. Mute: Press key to select “ON” or “OFF” for Mute. How to adjust your Monitor...

  • Page 31: Troubleshooting

    Troubleshooting Frequently Asked Questions (FAQ) The image is blurred: Read the Installation/Application section, and then select the correct resolution, refresh rate and make adjustments based on these instructions. How do you use a VGA extension cable? Remove the extension cable for the test. Is the image now in focus? If not, optimize the image by working through the instructions in the Installation/Adjustment section.

  • Page 32: Need More Help

    Read the Installation//section and then select the correct resolution, refresh rate and make adjustments based on these instructions. Need More Help? If your problems remain after checking this manual, please contact your place of purchase or e-mail us at: Support@BenQ.com Troubleshooting...

  • Page 33: Supported Operating Modes

    Supported operating modes Incoming display mode (Input timing) Resolution Horizontal Vertical Pixel Comment Frequency (KHz) Frequency (Hz) Frequency (MHz) 640x350 31.47(P) 70.08(N) 25.17 720x400 31.47(N) 70.08(P) 28.32 640x480 31.47(N) 60.00(N) 25.18 640x480 37.86(N) 72.80(N) 31.50 VESA 640x480 37.50(N) 75.00(N) 31.50 VESA 800x600 35.16(P)

  • Page 34: Specifications

    Specifications Model FP91E Display type 19.0" , active, TFT Viewable diagonal 48.26 cm Native (maximum) resolution 1280x1024 Colors 16.7 million Contrast / Brightness 1000:1 / 250 cd/m Response time 25 ms (8 ms GTG) Viewing angle (left/right, 170/170 (CR=10) up/down)
  • Page 35 Certifications TCO 99/03, TÜV/Ergonomics, TÜV/ GS, FCC Class B, ISO 13406-2, VCCI, CSA, CB Report, CE, C-Tick, BSMI, Fimko, GOST Operating voltage Automatic switched mode power supply, 90-264 V, 47-63Hz Dimensions (W x H x D) 419.3 x 410.8 x 215.4 mm Weight 6.0 kg Specifications...
