Page 1: Operating Instructions
PROART DUAL AM/FM TUNER WITH RS232 www.altronics.com.au OPERATING INSTRUCTIONS VIDEO DOOR INTERCOM S 9402A Base Station & Camera System S 9403A Additional Base Station S 9404A Additional Camera Unit Manufactured in China for Altronic Distributors Pty Ltd... - Page 2 If multiple base units are installed they may be used as an internal home intercom system. S 9402A system includes 1 x LCD base unit, 1 x door camera unit. For installations requiring 2 indoor or 2 outdoor stations, the additional part numbers of S 9403A and S 9404A must be ordered as they contain junction boxes for correct operation.
- Page 3 VIDEO DOOR INTERCOM SYSTEM Page 7...
-
Page 4: Troubleshooting
VIDEO DOOR INTERCOM SYSTEM Fig 6. Optional door lock interface connection. To Video Door Intercom To Video Camera Unit Door Intercom Red + Black - Plugpack for door strike Doorstrike Optional Door Lock Interface Box Troubleshooting Problem Cause No power (Power LED off) Insert power cord into power outlet. - Page 5 VIDEO DOOR INTERCOM SYSTEM Fig 1. Base Station. Fig 2. Outdoor Camera Unit 1. Camera 2. Microphone 3. Infra-Red LEDs 4. Speaker 5. Call button 1. Screen 2. Speaker 3. Microphone 4. Power LED 5. Intercom LED 6. Monitor button 7.
- Page 6 VIDEO DOOR INTERCOM SYSTEM Fig 3. Basic wiring for single camera, single base station configuration. Base Station Camera Optional door lock interface See Fig. 6 Jumper Installation With Two Outdoor Cameras This requires the use of the expansion junction box included with the S 9404A additional camera unit. The junction box allows for a maximum of two indoor base stations and two outdoor camera units.
- Page 7 VIDEO DOOR INTERCOM SYSTEM Fig 4. Wiring for two indoor base stations to a single outdoor camera unit. Base Station 2 Base Station 1 Camera Optional door lock interface See Fig. 6 Jumper Jumper Fig 5. Wiring for two indoor base stations and two outdoor Camera 1 camera units.
- Page 8 VIDEO DOOR INTERCOM SYSTEM For repair or service please contact your place of purchase. Note: Under no circumstances should you attempt to repair the product yourself or via a non-authorised Altronics service centre as this will invalidate the warranty! During the warranty period, we undertake to repair or replace your product at no charge if found to be defective due to a manufacturing fault.
