Summary of Contents for Supoin S10 Series
- Page 1 User Manual Supoin S10 Series Products Shenzhen Supoin Technology Corp. Addr ：Room2401-2408,Block A, World Trade Square, No.9 Fuhong Rd, Futian District, Shenzhen, China ：+0086-755-25828560 82178516 ：+0086-0755-82281509 www.supoin.net...
-
Page 2: Table Of Contents
................... 3.2.15 Restore Factory Chapter 3 Use Instructions 4.1.1 To ensure that the Supoin S10 does not fail, follow the following ............precautions during use of the Supoin S10: ....... 4.1.2 Pay attention to the following during use of the battery. -
Page 3: Chapter 1 Introduction
Scan Depth of Field 3.81 cm - 60.98 cm Scan Angle 47°± 3° (Standard) S10 series products are industrial grade handheld terminals independently researched, developed, designed and produced according to the characteristics Scan Speed 114 ± 10 scans/sec. of each industr y, and feature ergonomic design, compact size, anti-shock and Communication Transmission Wi-Fi 802.11b/g... -
Page 4: Battery Life (Hours)
Dormancy and standby (WI-FI On) About 100 Power key Scan key Battery cover Delete key Enter key Return key User-defined function keys Arrow key special function keys special function keys USB & Charging Port Figure 1-1 View of Supoin S10 Page 04 Page 05... -
Page 5: Functions Of Keys
2.2 Functions of Keys 2.3 TF Card Slot and SIM Card Slot Power key: Long press the ON/OFF button to power the terminal on or off. If you Installing a TF Card: want to leave your terminal unused but powered on for a long time, tap the red Open the batter y cover and remove the batter y, and insert the TF card into the ON/OFF button in the upper left corner of the display area. -
Page 6: Chapter 3 Use Instructions
Chapter 3 Use Instructions 3.2 Use Instructions for PDA Tools Then we will introduce the software function of S10 series devices in detail, mainly on the use of PDA configuration tool. 3.1 PDA Desktop The terminal will be turned on by pressing the power button for 3 to 5 seconds after putting in the batter y;... -
Page 7: Wi-Fi Setting
3.2.2 Wi-Fi Setting 3.2.3 Bluetooth Setting(Optional) Turn on/off the Wi-Fi module: Set whether the Wi-Fi module runs on startup of the terminal. Turning On/Off Bluetooth A) An icon will appear in the taskbar after Wi-Fi access is enabled. A) Open or close the window of Bluetooth Manager B) If "Run on Startup"... -
Page 8: Barcode 1D Setting
3.2.4 Barcode 1D Setting 3.2.5 USB Setting Open/close and various parameter setting of barcode 1D auto scanning Set data synchronization or USB disc loading (note: this item is only existed in tools 2416 plan device, remember not to connect with the USB line before setting, or the A) “Open scan head”: open the autoscan function, input barcode in the focal... -
Page 9: Serial Port Setting
3.2.6 Serial Port Setting 3.2.7 Screen Setting Set the brightness and calibration of the screen. Set the application mode of the serial, and it will come into force after restarting.(note: the devices of PXA310 plan has no this function) A) Adjust the brightness through shift the scroll bar. -
Page 10: Sound Setting
3.2.8 Sound Setting 3.2.9 Dormancy Setting Set dormancy and wake up parameter of the system Set the volume and sounds A) Adjust the volume through shift the scroll bar. A)“Auto close screen” time: the screen will close automatically when the system is in idle status, and the time inter val reaches. -
Page 11: Lock Setting
3.2.10 Lock Setting 3.2.11 On and off Setting of the Modular Set on or off of each hardware modular in PDA Set relevant parameter when locking the screen A)“Lock screen”: if the choice is selected, the screen will be locked... -
Page 12: Autorun Setting
3.2.12 Autorun Setting 3.2.13 Input Method Setting Set ”#” to change the input method Set the operating programs and shortcuts of autorun. A)”Desktop shortcut”: set up shortcut in the desktop. A) “Soft keyboard”: allow”#” key to activate the input panel of soft keyboard B)Start menu shortcut”: set up shortcut in the start menu. -
Page 13: Setting Information
Do not try to disassemble the Supoin S10. Otherwise, the Supoin S10 may be damaged. Do not touch the screen surface of the Supoin S10 by using a pen, a pencil or other sharp articles in case the screen may be scratched. -
Page 14: Pay Attention To The Following During Use Of The Battery
4.2 Troubleshooting Fault Cause Solution The area where the Supoin S10 is charged must keep away from scraps, inflammables or chemical substances. The battery volume is too low Charge the Supoin S10 or When you charge the battery of a mobile device, the temperature on the battery and or the battery is not charged. - Page 15 The scan application is not Load iScan in the Supoin S10. loaded. Check that the barcode is Reading a barcode fails. defective. The Supoin S10 does not decode barcodes. If the scanner stops sending out laser beam after you turn The battery volume is low.
