Acura Embedded AcuHawk-EX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AcuHawk-EX
Network Zoom Camera
User Manual
Acura Embedded Systems Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AcuHawk-EX and is the answer not in the manual?

Questions and answers

Related Manuals for Acura Embedded AcuHawk-EX

Summary of Contents for Acura Embedded AcuHawk-EX

  • Page 1 AcuHawk-EX Network Zoom Camera User Manual Acura Embedded Systems Inc.

  • Page 2: Table Of Contents

    User Manual of Network Zoom camera Table of Contents Chapter 1 Introduction ....................System Requirement ..................... Features ......................Overview ......................Chapter 3 Network Connection ................... Setting the Network Zoom Camera over the LAN ............3.1.1 Wiring over the LAN ..................3.1.2 Detecting and Changing the IP Address ..............
  • Page 3 User Manual of Network Zoom camera 6.3.8 Configuring FTP Settings ....................44 6.3.9 Configuring ....................UPnP™Settings 45 6.3.10 Configuring NAT (Network Address Translation) Settings ..........46 6.3.11 Configuring Email Settings ..................... 46 Configuring Video and Audio Settings ................... 48 6.4.1 Configuring Video Settings ....................48 6.4.2 Configuring Audio Settings ....................

  • Page 4: Chapter 1 Introduction

    User Manual of Network Zoom camera Chapter 1 Introduction 1.1 System Requirement System requirement of web browser accessing is as follows: Operating System: Microsoft Windows XP SP1 and above version / Win7 / Win8 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher...
  • Page 5 Table 1-1 Physical Description No. Items Description Lens Auto-focus lens There are screw holes for mounting to the Mounting Base bracket. 1A, 1B Alarm output interfaces. IN, G Alarm input interfaces. RS-485 interfaces. Used to control an D+,D- external PTZ. VIDEO, GND Analog video output interface POWER...

  • Page 6: Chapter 3 Network Connection

    User Manual of Network Zoom camera Chapter 3 Network Connection Before you start:  If you want to set the network zoom camera via a LAN (Local Area Network), please   refer to Section 3.1 Setting the Network Zoom camera over the LAN. ...

  • Page 7: Detecting And Changing The Ip Address

    User Manual of Network Zoom camera 3.1.2 Detecting and Changing the IP Address You need the IP address to visit the network zoom camera. Steps: 1. To get the IP address, you can choose either of the following methods: Use SADP, a software tool which can automatically detect the online ...

  • Page 8: Setting The Network Zoom Camera Over The Wan

    User Manual of Network Zoom camera 3.2 Setting the Network Zoom Camera over the WAN Purpose: This section explains how to connect the network zoom camera to the WAN with a static IP or a dynamic IP. 3.2.1 Static IP Connection Before you start: Please apply a static IP from an ISP (Internet Service Provider).

  • Page 9: Dynamic Ip Connection

    User Manual of Network Zoom camera 3.2.2 Dynamic IP Connection Before you start: Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network zoom camera to a modem or a router. Connecting the network zoom camera via a router ...
  • Page 10 User Manual of Network Zoom camera Normal Domain Name Resolution  Figure 3-7 Normal Domain Name Resolution Steps: 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network zoom camera.

  • Page 11: Accessing By Web Browsers

    User Manual of Network Zoom camera Chapter 4 Access to the Network Zoom Camera 4.1 Accessing by Web Browsers Steps: 1. Open the web browser. 2. In the address field, input the IP address of the network zoom camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface.
  • Page 12 User Manual of Network Zoom camera Figure 4-2 Download and Install Plug-in Figure 4-3 Install Plug-in (1) Figure 4-4 Install Plug-in (2)

  • Page 13: Accessing By Client Software

    User Manual of Network Zoom camera Figure 4-5 Install Plug-in (3) Note: You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in. 4.2 Accessing by Client Software The product CD contains the client software.
  • Page 14 User Manual of Network Zoom camera iVMS-4200 Figure 4-7 Live View Interface Notes:  If you use third party VMS software, please contact technical support of our branch for   camera firmware. For detailed information about client software of our company, please refer to ...

  • Page 15: Chapter 5 Live View

    User Manual of Network Zoom camera Chapter 5 Live View 5.1 Live View Page Purpose: The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network zoom camera to enter the live view page, or you can click on the menu bar of the main page to enter the live view page.

  • Page 16: Starting Live View

    User Manual of Network Zoom camera Configure the image size and stream type of the live video. 5.2 Starting Live View In the live view window as shown in Figure 5-2, click on the toolbar to start the live view of the zoom camera. Figure 5-2 Start Live View Table 5-1 Descriptions of the Toolbar Icon...

  • Page 17: Recording And Capturing Pictures Manually

    User Manual of Network Zoom camera  Setting the image quality of the live video in Section 6.1 Configuring Local Parameters  and Section 6.4.1 Configuring Video Settings.   Setting the OSD text on live video in Section 6.5.1 Configuring OSD Settings. 5.3 Recording and Capturing Pictures Manually In the live view interface, click on the toolbar to capture the live pictures or...

  • Page 18: Setting / Calling A Preset

    User Manual of Network Zoom camera Button Description Focus near/far Adjust speed of pan/tilt movements 5.4.2 Setting / Calling a Preset Purpose: A preset is a predefined image position. For the defined preset, you can click the calling button to quickly view the image of the desired position. Setting a Preset: ...

  • Page 19: Setting / Calling A Patrol

    User Manual of Network Zoom camera Figure 5-5 Calling a Preset 5.4.3 Setting / Calling a Patrol Purpose: A patrol is a memorized series of preset function. It can be configured and called on the patrol settings interface. There are up to 8 patrols for customizing. A patrol can be configured with 32 presets.
  • Page 20 User Manual of Network Zoom camera 4. Configure the preset number, patrol time and patrol speed. Name Description Patrol Time It is the duration staying on one patrol point. The speed dome moves to another patrol point after the patrol time. Patrol Speed It is the speed of moving from one preset to another.

  • Page 21: Setting / Calling A Pattern

    User Manual of Network Zoom camera 5.4.4 Setting / Calling a Pattern Purpose: A pattern is a memorized series of pan, tilt, zoom functions. There is 1 pattern for customizing. You can use the RS485 or RS232 interface to trigger this function. For detailed configuration, please contact our technical support or refer to technical manual.

  • Page 22: Configuring Live View Parameters

    User Manual of Network Zoom camera 2. Check the checkbox of Enable Park Action. 3. Set the Park Time as the inactivity time of the dome before it starts the park actions. 4. Choose Action Type the from the drop-down list. Auto scan, patrol and preset are available.

  • Page 23: Chapter 6 Camera Configuration

    User Manual of Network Zoom camera Chapter 6 Camera Configuration 6.1 Configuring Local Parameters Note: The local configuration refers to the parameters of the live view and other operations using the web browser. Steps: 1. Enter the Local Configuration interface: Configuration >...

  • Page 24: Configuring Time Settings

    User Manual of Network Zoom camera refer to Section 6.3.1 Configuring TCP/IP Settings.  Live View Performance: Set the live view performance to Least Delay,  Balanced or Best Fluency.   Record File Settings: Set the saving path of the video files. ...
  • Page 25 User Manual of Network Zoom camera Figure 6-2 Time Settings Configuring Time Synchronization by NTP Server  (1) Check the checkbox to enable the NTP function. (2) Configure the following settings: Server Address: IP address of NTP server. NTP Port: Port of NTP server. Interval: The time interval between the two synchronizing actions by NTP server.
  • Page 26 User Manual of Network Zoom camera (2) Click to set the system time from the pop-up calendar. (3) Click to save the settings. Note: You can also check the Sync with local time checkbox to synchronize the time of the zoom camera with the time of your computer. Figure 6-4 Time Sync Manually ...

  • Page 27: Configuring Network Settings

    User Manual of Network Zoom camera Figure 6-6 DST Settings 6.3 Configuring Network Settings 6.3.1 Configuring TCP/IP Settings Purpose: TCP/IP settings must be properly configured before you operate the zoom camera over network. Steps: 1. Enter TCP/IP Settings interface: Configuration > Basic Configuration > Network > TCP/IP Or Configuration >...

  • Page 28: Configuring Port Settings

    User Manual of Network Zoom camera 2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and IPv4(IPv6) Default Gateway. 3. Click to save the above settings Notes:  If the DHCP server is available, you can check to automatically obtain an ...

  • Page 29: Configuring Pppoe Settings

    User Manual of Network Zoom camera 3. Click to save the settings. 6.3.3 Configuring PPPoE Settings Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. Steps: 1. Enter the PPPoE Settings interface: Configuration >Advanced Configuration >...
  • Page 30 User Manual of Network Zoom camera Figure 6-10 DDNS Settings 2. Check the Enable DDNS checkbox to enable this feature. 3. Select DDNS Type. Four DDNS types are selectable: IPServer, DynDNS, HiDDNS and NO-IP.  DynDNS: Steps: (1) Enter Server Address of DynDNS (e.g. members.dyndns.org). (2) In the Domain text field, enter the domain name obtained from the DynDNS website.

  • Page 31: Configuring Snmp Settings

    User Manual of Network Zoom camera Figure 6-12 IPServer Settings HiDDNS:  Steps: (1) Enter the Server Address: www.hiddns.com.com. (2) Enter the Domain name of the camera. The domain is the same with the device alias in the HiDDNS server. (3) Click to save the settings.
  • Page 32 User Manual of Network Zoom camera camera can send the alarm event and exception messages to the surveillance center. Note: The SNMP version you select should be the same as that of the SNMP software. Steps: 1. Enter the SNMP Settings interface: Configuration >...
  • Page 33 User Manual of Network Zoom camera 4. Click to save and finish the settings. 6.3.6 Configuring 802.1X Settings Purpose: The zoom camera supports IEEE 802.1X standard. IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN.

  • Page 34: Configuring Qos Settings

    User Manual of Network Zoom camera 1. Connect the network camera to your PC directly with a network cable. 2. Enter the 802.1X Settings interface: Configuration > Advanced Configuration > Network > 802.1X Figure 6-16 802.1X Settings 3. Check the Enable IEEE 802.1X checkbox to enable it. 4.

  • Page 35: Configuring Ftp Settings

    User Manual of Network Zoom camera The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher. 3. Click to save the settings. Notes:  Make sure that you enable the QoS function of your network device (such as a ...
  • Page 36 User Manual of Network Zoom camera Figure 6-19 Parent Directory Child directory: It is a sub-folder which can be created in the parent  directory. The files will be saved in a sub-folder in FTP server. The name  of folder can be defined as shown in following Figure 6-20. Figure 6-20 Child Directory Upload type: To enable uploading the captured picture to the FTP server.

  • Page 37: Configuring Nat (Network Address Translation) Settings

    User Manual of Network Zoom camera 6.3.10 Configuring NAT (Network Address Translation) Settings Steps: 1. Set the port mapping mode: To port mapping with the default port numbers: Choose To port mapping with the customized port numbers: Choose And you can customize the value of the port number by yourself. 2.
  • Page 38 User Manual of Network Zoom camera Figure 6-22 Email Settings Configure the following settings: Sender: The name of the email sender. Sender’sAddress: The email address of the sender. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com). SMTP Port: The SMTP port.

  • Page 39: Configuring Video And Audio Settings

    User Manual of Network Zoom camera pictures. Authentication (optional): If your email server requires authentication, check this checkbox to use authentication to log in to this server and enter the login user name and password. Receiver: Select the receiver to which the email is sent. Up to 2 receivers can be configured.

  • Page 40: Configuring Audio Settings

    User Manual of Network Zoom camera Refer to the Section 6.1 Configuring Local Parameters for switching the main stream and sub-stream for live viewing. 3. You can customize the following parameters for the selected main stream or sub- stream: Video Type: Select the stream type to video stream, or video &...

  • Page 41: Configuring Roi

    User Manual of Network Zoom camera Figure 6-24 Audio Settings 2. Configure the following settings. Audio Encoding: G.722.1, G.711ulaw, G.711alaw, MP2L2 and G.726 selectable. Audio Input: When an intercom is connected to the speed dome, you need to set this option to LineIn. When a microphone is connected to the speed dome, you need to set this option to MicIn.

  • Page 42: Configuring Image Settings

    User Manual of Network Zoom camera Figure 6-25 Region of Interest 6.5 Configuring Image Settings 6.5.1 Configuring Display Settings Purpose: You can set the image quality of the network camera, including brightness, contrast, saturation, sharpness, etc. Note: The parameters in Display Settings interface vary depending on the models of network zoom camera.

  • Page 43: Image Adjustment

    User Manual of Network Zoom camera Figure 6-26 Display Settings Image Adjustment Brightness  This feature is used to adjust brightness of the image. The value ranges from 0 to 100.  Contrast This feature enhances the difference in color and light between parts of an image. The value ranges from 0 to 100.
  • Page 44 User Manual of Network Zoom camera The iris, shutter and gain values will be adjusted automatically according to the brightness of the environment. Iris Priority:  The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment.
  • Page 45 User Manual of Network Zoom camera This function is used to limit the minimum focus distance. The value can be set to 10cm, 30cm, 1m, 1.5m, 3m, 6m and INFINITE. Note: The minimum focus value varies depending on the models of camera. Day/Night Switch The Day/Night Switch mode can be set to Auto, Day and ...

  • Page 46: White Balance

    User Manual of Network Zoom camera HLC (High Light Compensation) makes the camera identify and suppress the strong light sources that usually flare across a scene. This makes it possible to see the detail of the image that would normally be hidden. White Balance The White Balance mode can be set to Auto, MWB, Outdoor, Indoor, Fluorescent Lamp, Sodium Lamp and Auto-Track.

  • Page 47: Configuring Osd Settings

    User Manual of Network Zoom camera Figure 6-33 3D Digital Noise Reduction Note: This function varies depending on the models of zoom camera.  De-fog Mode When there is fog in the image, you can enable this function to get clear image. Note: This function varies depending on the models of zoom camera.
  • Page 48 User Manual of Network Zoom camera Figure 6-34 OSD Settings 2. Check the corresponding checkbox to select the display of zoom camera name, date or week if required. 3. Edit the zoom camera name in the text field of Camera Name. 4.

  • Page 49: Configuring Text Overlay Settings

    User Manual of Network Zoom camera 6.5.3 Configuring Text Overlay Settings Purpose: You can customize the text overlay. Steps: 1. Enter the Text Overlay Settings interface: Configuration > Advanced Configuration > Image > Text Overlay 2. Check the checkbox in front of textbox to enable the on-screen display. 3.

  • Page 50: Configuring And Handling Alarms

    User Manual of Network Zoom camera 3. Click Figure 6-37 Privacy Mask Settings 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to 4 areas on the same image. 5.
  • Page 51 User Manual of Network Zoom camera 1. Set the Motion Detection Area. Steps: (1) Enter the motion detection settings interface Configuration > Advanced Configuration> Events > Motion Detection (2) Check the checkbox of Enable Motion Detection. Figure 6-38 Enable Motion Detection (3) Click .
  • Page 52 User Manual of Network Zoom camera Figure 6-39 Arming Schedule (2) Choose the day you want to set the arming schedule as shown in Figure 6-40. (3) Click to set the time period for the arming schedule. (4) After you set the arming schedule, you can click to copy the schedule to other days (Optional).
  • Page 53 User Manual of Network Zoom camera Figure 6-40 Arming Time Schedule 3. Set the Alarm Actions for Motion Detection. Purpose: You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. Figure 6-41 Linkage Method Check the checkbox to select the linkage method.

  • Page 54: Configuring Tamper-Proof Alarm

    User Manual of Network Zoom camera 6.6.7 Configuring Email Settings to set the Email parameters.   Upload to FTP Capture the image when an alarm is triggered and upload the picture to a FTP server. Note: You need a FTP server and set FTP parameters first. Refer to Section 6.3.5 Configuring FTP Settings for setting FTP parameters.

  • Page 55: Configuring External Alarm Input

    User Manual of Network Zoom camera 2. Check Enable Tamper-proof checkbox to enable the tamper-proof detection. 3. Set the tamper-proof area. Refer to Step 1 Set the Motion Detection Area in Section 6.6.1 Configuring Motion Detection. 4. Click to edit the arming schedule for tamper-proof. The arming schedule configuration is the same as the setting of the arming schedule for motion detection.
  • Page 56 User Manual of Network Zoom camera Figure 6-43 Alarm Input Settings to set the arming schedule for the alarm input. Refer to Step 2 4. Click Set the Arming Schedule for Motion Detection in Section 6.6.1 Configuring Motion Detection. 5. Check the checkbox to select the linkage method taken for the alarm input. Refer to Step 3 Set the Alarm Actions for Motion Detection in Section 6.6.1 Configuring Motion Detection.

  • Page 57: Configuring Alarm Output

    User Manual of Network Zoom camera Figure 6-44 Linkage Method 6.6.4 Configuring Alarm Output Steps: 1. Enter the Alarm Output Settings interface: Configuration>Advanced Configuration> Events > Alarm Output 2. Select one alarm output channel in the Alarm Output drop-down list. 3.

  • Page 58: Handling Exception

    User Manual of Network Zoom camera Figure 6-45 Alarm Output Settings 6.6.5 Handling Exception The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the zoom cameras. Steps: 1. Enter the Exception Settings interface: Configuration >...

  • Page 59: Chapter 7 Record Settings

    User Manual of Network Zoom camera Chapter 7 Record Settings Before you start: To configure record settings, please make sure that you have the network storage device within the network or the SD card installed in your zoom camera. 7.1 Configuring NAS Settings Before you start: The network disk should be available within the network and properly configured to store the recorded files, log files, etc.

  • Page 60: Configuring Recording Schedule

    User Manual of Network Zoom camera (1) Enter the HDD Settings interface (Advanced Configuration > Storage > Storage Management), in which you can view the capacity, free space, status, type and property of the disk. (2) If the status of the disk is Uninitialized as shown in Figure 7-3, check the corresponding checkbox to select the disk and click to start initializing the disk.
  • Page 61 User Manual of Network Zoom camera Configuration > Advanced Configuration> Storage > Record Schedule Figure 7-6 Recording Schedule Interface 2. Check the checkbox of Enable Record Schedule to enable scheduled recording. 3. Set the record parameters of the zoom camera. Figure 7-7 Record Parameters ...
  • Page 62 User Manual of Network Zoom camera zoom camera model.  Overwrite: If you enable his function and the HDD is full, the new record files   overwrite the oldest record files automatically.   Recording Stream: You can set the recording stream as Main Stream or Sub Steam. ...
  • Page 63 User Manual of Network Zoom camera Besides configuring the recording schedule, you have to set the motion detection area and check the checkbox of Trigger Channel in the Linkage Method of Motion Detection Settings interface. For detailed information, please refer to the Step 1 Set the Motion Detection Area in the Section 6.6.1 Configuring Motion Detection.

  • Page 64: Configuring Snapshot Settings

    User Manual of Network Zoom camera (3) Check the checkbox and click to copy settings of this day to the whole week. You can also check any of the checkboxes before the date and click (4) Click to save the settings and exit the Edit Record Schedule interface.
  • Page 65 User Manual of Network Zoom camera details to configure FTP parameters. 2) Check checkbox in Motion Detection Settings or Alarm Input interface. Please refer to Step 3 Set the Alarm Actions Taken for Motion Detection in Section 6.6.1 Configuring Motion Detection, or Step 4 Configuring External Alarm Input in Section 6.6.1 Configuring Motion Detection.

  • Page 66: Chapter 8 Playback

    User Manual of Network Zoom camera Chapter 8 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or SD cards. Task 1: To play back the video files Steps: 1. Click on the menu bar to enter playback interface.

  • Page 67: Chapter 8 Playback

    User Manual of Network Zoom camera 3. Click to play the video files found on this date. The toolbar on the bottom of Playback interface can be used to control playing process. Figure 8-3 Playback Toolbar Table 8-1 Description of the buttons Button Operation Button...
  • Page 68 User Manual of Network Zoom camera types as shown in Figure 8-6. Figure 8-6 Video Types Task 2: To download the video files Steps: 1. Click on the playback interface. The pop-up menu is shown in Figure 8-7. All the video files are listed. Figure 8-7 Video Downloading interface 2.
  • Page 69 User Manual of Network Zoom camera  The video files are not all listed on one page. You can click  to turn pages. Task 3: To download the captured pictures Steps: 1. Click on the playback interface. The pop-up menu is shown in Figure 8-8. 2.

  • Page 70: Chapter 9 Log Searching

    User Manual of Network Zoom camera Chapter 9 Log Searching Purpose: The operation, alarm, exception and information of the zoom camera can be stored in log files. You can also export the log files on your demand. Before you start: Please configure network storage for the zoom camera or install a SD card in the zoom camera.
  • Page 71 User Manual of Network Zoom camera 4. To export the log files, click to save the log files in your computer.

  • Page 72: Chapter 10 Others

    User Manual of Network Zoom camera Chapter 10 Others 10.1 Managing User Accounts Enter the User Management interface: Configuration >Basic Configuration> Security > User Or Configuration > Advanced Configuration> Security > User The admin user has access to create, modify or delete other accounts. Up to 31 user accounts can be created.
  • Page 73 User Manual of Network Zoom camera Figure 10-2 Add a User  Modify a User Steps: 1. Left-click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions.
  • Page 74 User Manual of Network Zoom camera Figure 10-3 Modify a User  Delete a User Steps: 1. Left-click the user name you want to delete and click 2. Click on the pop-up dialogue box to delete the user. Figure 10-4 Delete a User...

  • Page 75: Configuring Rtsp

    User Manual of Network Zoom camera 10.2 Configuring RTSP Authentication Purpose: You can specifically secure the stream data of live view. Steps: 1. Enter the RTSP Authentication interface: Configuration> Advanced Configuration> Security > RTSP Authentication Figure 10-5 RTSP Authentication 2. Select the Authentication type basic or disable in the drop-down list to enable or disable the RTSP authentication.

  • Page 76: Configuring Ip

    User Manual of Network Zoom camera 10.4 Configuring IP Address Filter With this function on, the camera allows certain IP addresses whether to log in or not. Filter Type Description Forbid the IP addresses added in the IP Address Filter interface to Forbidden log in.

  • Page 77: Maintenance

    User Manual of Network Zoom camera Figure 10-9 Device Information 10.6 Maintenance 10.6.1 Rebooting the Zoom Camera Steps: 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance: 2. Click to reboot the network zoom camera.

  • Page 78: Importing/Exporting

    User Manual of Network Zoom camera Note: Clicking restores all the parameters to default settings including the IP address and user information. Please use this button with caution. Figure 10-11 Restore Default Settings 10.6.3 Importing/Exporting Configuration File Steps: 1. Enter the Maintenance interface: Configuration >...

  • Page 79: Enabling/Disabling

    User Manual of Network Zoom camera computer to upgrade the device.  Firmware Directory: You need to find the directory where the firmware locates. The device can find the firmware in the directory automatically. 3. Click to select the local upgrade file and then click to start remote upgrade.

  • Page 80: Rs-485 Settings

    User Manual of Network Zoom camera Figure 10-15 RS-232 Settings Note: If you want to connect the camera by the RS-232 port, the parameters of the RS-232 should be exactly the same with the parameters you configured here. 2. Click to save the settings.

  • Page 81: Appendix

    User Manual of Network Zoom camera Appendix Appendix 1 SADP Software Introduction  Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices.
  • Page 82 User Manual of Network Zoom camera information; you can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.  Modify network parameters Steps: 1. Select the device to be modified in the device list and the network parameters of the device will be displayed in the Modify Network Parameters panel on the right side.

  • Page 83: Appendix 2 Port Mapping

    User Manual of Network Zoom camera Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-R410). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2.
  • Page 84 User Manual of Network Zoom camera Example: When the zoom cameras are connected to the same router, you can forward the ports of a zoom camera as 80, 8000, 8200~8210 and 554 with IP address 192.168.1.23, and the ports of another zoom camera as 81, 8001, 8201~8211 and 555 with IP 192.168.1.24.
