Rocom ECII User Manual

Gsm gateway
Hide thumbs Also See for ECII:

Advertisement

Quick Links

Table of contents

1.
Content of delivery ...............................................................................................................................2
2.
PIN-code................................................................................................................................................2
3.
Installation .............................................................................................................................................2
4.
Front panel connectors and indications ............................................................................................3
5.
Back panel connectors and indications.............................................................................................3
6.
Battery....................................................................................................................................................4
6.1
Low battery voltage indication.................................................................................................4
6.2
Battery fault alarm.....................................................................................................................5
7.
SMS functionality..................................................................................................................................5
7.1
Battery alarm .............................................................................................................................5
7.2
Dial tone 2 ..................................................................................................................................8
8.
Upgrade Tool ......................................................................................................................................10
8.1
Firmware upgrade...................................................................................................................10
8.2
Setup ......................................................................................................11
8.2.1
LED control on signal strength................................................................................11
8.2.2
Battery control ...........................................................................................................12
8.2.3
Gain control................................................................................................................12
8.2.4
POTS1 power saving ...............................................................................................12
8.2.5
Tone generation ........................................................................................................12
8.2.6
Dial tone 2; battery failure........................................................................................12
9.
Technical Data....................................................................................................................................13
10.
Contact Information............................................................................................................................13
GSM Gateway
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECII and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rocom ECII

  • Page 1: Table Of Contents

    GSM Gateway User Manual Table of contents Content of delivery ..........................2 PIN-code..............................2 Installation .............................2 Front panel connectors and indications ....................3 Back panel connectors and indications.....................3 Battery..............................4 Low battery voltage indication....................4 Battery fault alarm........................5 SMS functionality..........................5 Battery alarm ..........................5 Dial tone 2 ..........................8 Upgrade Tool ............................10 Firmware upgrade........................10 Setup ………………………………………………………………………………………...11...
  • Page 2: Content Of Delivery

    1. Content of delivery GSM Gateway Antenna GSM Gateway Manual (this document) Power adapter 230VAC/12 VDC 2. PIN-code Note: The GSM gateway must always be switched off before inserting or removing the SIM-card. The SIM-card does not need to have a PIN-code activated. If the SIM-card has a PIN-code activated it must be set to “1234”.
  • Page 3: Front Panel Connectors And Indications

    4. Front panel connectors and indications PHONE USB 2.0 Mini connector to be used for connection with a PC. The USB can be used for updating the software of the GSM Gateway and also for adjusting parameters, such as battery tripping limits. LED Indicators Status Indicates...
  • Page 4: Battery

    Indicates Faulty GSM unit 800 ms ON / 800 ms OFF No service, No connection with GSM or SIM-card missing. 100 ms ON / 1500 s OFF Connection with the GSM network OK, Backup power in use Normal status. Connection with the GSM network OK , AC-powered S1 and S2 Indications for GSM signal strength (Green LED): Signal strength Good ( default 15 = -83 dBm)
  • Page 5: Battery Fault Alarm

    Battery fault alarm A “battery fault alarm” is indicated the same way as “low battery voltage indication” (6.1) but can also be sent by SMS. Please view SMS functionality for information on settings or how to use the USB connector and 1258 Manager software. The first battery test is made after 48 hours and the following every 24 hour.
  • Page 6 The GSM will acknowledge a correct programming by returning a SMS as above. In the example below the battery alarm level is changed to 4.0 V (4000 mV). Balarm:On=4 Balarm:On=4 000↵ 070321213 070321213↵ Battery Battery alarm from alarm from Lift 452 Lift 452 SMS to GSM Gateway SMS from GSM Gateway...
  • Page 7 Bares:On Bares:On↵ Battery OK Battery OK from Lift from Lift SMS to GSM Gateway SMS from GSM Gateway The GSM Gateway will acknowledge a correct programming by returning a SMS as above. In this example when the battery is changed it will generate the following SMS from the GSM Gateway: Battery OK from Lift...
  • Page 8: Dial Tone2

    The SMS is acknowledged with a SMS from the GSM Gateway. The Battery replaced SMS (Bares) function described above can be switched off separately by sending the following SMS to the GSM Gateway: Bares:off Balarm:ON Bares:OFF SMS to GSM Gateway SMS from GSM Gateway The SMS is acknowledged with an SMS from the GSM Gateway.
  • Page 9 Dial tone2: Dial Tone2: SMS to GSM Gateway SMS from GSM Gateway Page 9 of 13...
  • Page 10: Upgrade Tool

    The USB interface is used to configure user specific parameters and to upgrade the GSM Gateway firmware. The upgrade requires the Windows program “1258 Manager” and is available from Rocom GmbH or your local distributor. Use a standard USB – miniUSB cable to connect the GSM Gateway to the PC.
  • Page 11: Setup

    Brows to find and select the new FW file supplied by Rocom GmbH or your local distributor. Note: The FW file always has the file extension bin (e.g. gatewayFW.bin). Click on “Update”. During the update you can follow the progress in the status bar.
  • Page 12: Battery Control

    There are two LED’s showing the strength of the GSM signal; S1 and S2. You can set the limits when to light these LED’s. 8.2.2 Battery control For information on the battery control please see the section 6 Battery. Fill out the “GSM Battery alarm nr”; where to receive battery alarm SMS. Fill out the “GSM Battery alarm text”;...
  • Page 13: Technical Data

    USB: USB 2.0 Mini 10. Contact Information Support: Tel:+ 49 6106 66000 E-mail: info@rocom-gmbh.de Rocom Energie- und Kommunikationssysteme GmbH Lessingstr. 20 63110 Rodgau, Germany Phone: + 49 6106 66000 Fax: + 49 6106 660066 Homepage: www.rocom-gmbh.com Page 13 of 13...
