- Page 1 LBI-39007 Mobile Communications Monogram Series DUAL RATE CHARGER MHCH3V Operator's Manual...
-
Page 2: Important Safety Instructions
(1) the battery charger, (2) the battery and (3) the product using the battery. CAUTION - To reduce the risk of injury, charge only Ericsson GE battery packs. Charging any other battery pack or batteries may cause the battery to burst and cause personal injury or damage. - Page 3 IMPORTANT SAFETY INFORMATION (CONT.) To reduce risk of damage to electric plug and cord, pull by the plug rather than the cord when disconnecting the charger. Make sure the cord is located so that it will not be stepped on, tripped over or otherwise subjected to damage or stress.
- Page 4 IMPORTANT SAFETY INFORMATION (CONT.) TABLE 1 - RECOMMENDED MINIMUM SIZE FOR EXTENSION CORDS FOR BATTERY CHARGERS LENGTH OF CORD (FT.) AWG SIZE OF CORD Do not operate charger with damaged cord or plug - replace them immediately. 10. Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way;...
- Page 5 IMPORTANT SAFETY INFORMATION (CONT.) 13. GROUNDING AND AC POWER CORD CONNECTION - To reduce the risk of electrical shock, use only a properly grounded outlet. The charger is equipped with an electric cord having an equipment- grounding conductor and a grounding plug.
- Page 6 IMPORTANT SAFETY INFORMATION (CONT.) FIGURE 1 - GROUNDING METHODS 16. DANGER - Before using an adapter as illustrated, be certain the center screw of the outlet plate is grounded. The green- color rigid ear of lug extending from the adapter must be connected to a properly grounded outlet--make certain...
- Page 7 IMPORTANT SAFETY INFORMATION (CONT.) 17. Care should be taken when placing the charger in service to ensure proper top and bottom ventilation. A minimum of ¼" is required between the bottom of the charger and the surface on which it sits. FEATURES...
- Page 8 (1) Battery Charging Slot: This slot is provided so that a battery may be charged independently. Dual positive contacts are wired so that positioning of the battery is not relevent. (2) Slow LED Light: will be illuminated as long as a battery is positioned in the Battery Charging Slot.
-
Page 9: Operation
CAUTION Never insert a radio into the charger without a battery. The higher voltage of the charger can damage the circuitry of the radio. OPERATION RADIO WITH BATTERY With a battery inside the radio, insert the radio into the Radio Charge Slot. The Radio Fast LED will illuminate and the battery will commence charging at a rapid rate for approximately 3 hours. -
Page 10: Circuit Diagram
downward. Dual positive contacts are provided so that battery polarity will be correct regardless of battery orientation. After approximately 14 hours the battery will be fully charged. The Battery Slow LED will remain illuminated as long as the battery remains in the charger slot. Prolong charging in this mode will not cause battery damage. - Page 12 Ericsson GE Mobile Communications Inc. Mountain View Road • Lynchburg, Virginia 24502 Printed in U.S.A.
