Ace Door User Manual

Ace hardware door user manual
Hide thumbs

Advertisement

Table of Contents

®
Hardwired
Electronic
Chime
© 2005
598-1224-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Door and is the answer not in the manual?

Questions and answers

Summary of Contents for Ace Door

  • Page 1 ® Hardwired Electronic Chime © 2005 598-1224-00...
  • Page 2 CHIME REPLACEMENT INSTALLATION IMPORTANT: Proper installation requires a diode on the front door push button. See Diode Installation Instructions (page 5) after completing steps 1 through 10 below. Note: Electrical work must be in accordance with national and local electrical codes. If in doubt, consult a qualified electrician.
  • Page 3 “R” to screw terminal marked “REAR”* (See Figure 2). 11. Install chime cover (see page 4). 12. Connect diode to front push button (see page 5). *Note: Some installations may not include rear door push button. Existing Chime Wires Replacement...
  • Page 4 INSTALL CHIME COVER Place chime cover securely over base. • For hanging type cover: Remove, turn over, and reinstall the cover pin (see Figure 3). Hang cover on cover pin. • For snap-on type cover: Apply pressure to the cover until it snaps into place (see Figure 4).
  • Page 5 A small electrical component called a “diode” is required for this chime to play the entire eight-note tune.This diode must be installed on the terminal screws of the front door push button (see Figure 5). If not already installed on push button, attach supplied diode as shown below.

  • Page 6: Troubleshooting

    Chime does not sound: • Check Chime: Disconnect wire from terminal marked “TRANS”. Have someone operate push button at front door while you mo- mentarily touch the “TRANS” wire to terminal marked “FRONT”. You will see a small spark if push button, wiring, and transformer are operating properly.
  • Page 7 TECHNICAL SERVICE Please call 1-800-858-8501 for assistance before returning product to store. If you experience a problem, follow this guide. You may also want to visit our Web site at: www.desatech.com. If the problem persists, call* for assistance at 1-800-858-8501, 7:30 AM to 4:30 PM CST (M-F). You may also write* to: DESA Specialty Products™...
  • Page 8 Front Door Push Button With Diode Transformer Rear Door Push Button (If Applicable) Chime System Wiring Diagram Chime 598-1224-00...
