Quick Reference Guide CLK-4
Legal Notices
This manual and any examples contained herein are provided "as is". JNC makes no warranty of any kind with regard to this manual,
including, but not limited to, the implied warranties of merchantability, non-infringement and fitness for a particular purpose. JNC shall
not be liable for any errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this
manual or the examples contained herein.
Reproduction, adaptation or translation of this manual is prohibited without prior written permission of JNC Service B.V.
CAUTION: This Quick Reference Guide may be revised or withdrawn at any time without prior notice.
This document provides basic usage instructions and information on setting up your DOKKi docking station.
UNPACKING
Do NOT use a knife to open the package or contents as this may result in damage to the product(s)
Open the outer box on the top-side. Take the CLK-4 from it's box and remove the bubble-foil.
BOX CONTENTS
CLK-4 docking station
•
Power Supply
•
USB cable
•
Promotional items aren't listed here.
The CLK-4 will fit Opticon scanner models OPH-3000 and CLK-3000 (also known as 'Opticon SMART').
The insertion area is as tight as possible to ensure stability for the scanner. This also means that the scanner won't fit
when used in combination with any available sleeve or case (rubber, leather, etc.).
By removing the USB cover from the scanner dust and/or moist can penetrate the connector and opening(s) behind
the USB cover more easily. It is possible that the products' IP rating has been altered too.
Removing any original part from the scanner could void warranty. Doing so is at your own risk!
Before inserting any scanner in the dock be sure to remove the USB cover
(see the above note).
Save the USB cover in case it's needed at a later stage.
DOKKi.eu is a trademark of JNC Service B.V. ('JNC'). Copyright JNC Service B.V. All rights reserved.
DOKKi
DOKKi CLK-4
.eu
CLK-4_QRG-001 / August 2014
Advertisement
Table of Contents
Summary of Contents for Dokki CLK-4
- Page 1 UNPACKING Do NOT use a knife to open the package or contents as this may result in damage to the product(s) Open the outer box on the top-side. Take the CLK-4 from it's box and remove the bubble-foil. BOX CONTENTS CLK-4 docking station •...
- Page 2 DOKKi Quick Reference Guide CLK-4 POSITIONING The CLK-4 has rubber feet on the bottom and can be used on a flat surface. Please make sure the CLK-4 is positioned on a flat surface which is level. POWER AND CONNECTION Plug the power adapter cable into the wall outlet and the other end of the connector in the back power connection of the CLK-4.
- Page 3 TROUBLESHOOTING If you are experiencing any problem with the CLK-4 the first thing to check is if the scanner operates correctly when connected directly to the PC with an USB cable. Do so by plugging the USB cable that came with your scanner into your scanner and make sure the other end of the USB cable goes directly into the PC (bypassing any present HUB).
