Finex FX100 Instruction Manual

Gravity feed and hvlp air spray guns
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Gravity Feed and HVLP Air Spray Guns
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Part
Model
No.
FX100
248752
Mini-HVLP
248753
FX200
248754
Conventional
248755
248756
FX300
HVLP
248757
248758
*Maximum HVLP Compliant Pressure
Setup
1.
Install an air pressure regulator on gun air supply line to
control air pressure.
2.
Install a shutoff valve downstream of the air regulator to shut
off gun air.
3.
Connect a clean, dry, filtered air supply.
4.
Connect air supply line to gun air inlet (21). F
other end to shutoff valve.
5.
Install fluid filter (29) into fluid inlet (6). Refer to page 6.
6.
Screw on gravity cup (30).
7.
Remove gravity cup cover (A) and fill cup with solvent to flush
if this is first time using equipment.

Flush Spray Gun

WARNING
Read warnings, page 2.
Needle/
Maximum
Nozzle
Working Air
Size
Pressure
100 psi
1.0
(0.7 MPa, 7 bar)
1.4
100 psi
(0.7 MPa, 7 bar)
1.8
1.3
1.4
100 psi
(0.7 MPa, 7 bar)
1.5
1.8
. 1. Connect
IG
SHARPE: P.O. Box 1441 Minneapolis, MN 55440-1441
1-800-742-7731, www.sharpe1.com
310746 4/2004, Rev. F 5/2007
FOR PRODUCT INFORMATION CALL:
II 2 G
Recommended
Maximum Inbound
Air Pressure
29 psi
(0.20 MPa, 2.0 bar)*
60 psi
(0.41 MPa, 4.1 bar)
29 psi
(0.20 MPa, 2.0 bar)*
Flush spray gun before using it. Use solvent that is compatible
with gun wetted parts and fluid that will be sprayed. Use lowest
possible pressure, and spray into grounded metal waste
container.
After flushing, follow Pressure Relief Procedure.
Pressure Relief Procedure
WARNING
Follow Pressure Relief Procedure when you stop spraying
and before cleaning, checking, or servicing equipment. Read
warnings, page 2.
1.
Turn off gun air supply.
2.
Trigger gun into grounded metal waste container.
THE SPRAY GUN PEOPLE
1-800-742-7731
A
6
F
. 1
IG
30
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Finex FX100

  • Page 1: Flush Spray Gun

    Save these instructions. Needle/ Maximum Recommended Part Nozzle Working Air Maximum Inbound Model Size Pressure Air Pressure FX100 100 psi 29 psi 248752 (0.7 MPa, 7 bar) (0.20 MPa, 2.0 bar)* Mini-HVLP 248753 FX200 100 psi 60 psi 248754 (0.7 MPa, 7 bar) (0.41 MPa, 4.1 bar)

  • Page 2: Year Limited Warranty

    WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: • Use equipment only in well ventilated area. • Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop cloths (potential static arc).

  • Page 3: Adjust Spray Pattern

    Use smooth, even strokes, with about 50% overlap. • FX100 and FX300 HVLP Guns: Use a slightly slower hand movement and make fewer passes than you would with a conventional air spray gun. Take care to avoid runs or sags.

  • Page 4: Troubleshooting

    FINEX HVLP AND CONVENTIONAL SPRAY GUNS Troubleshooting WARNING Follow Pressure Relief Procedure, page 1, before troubleshooting or servicing. Read warnings, page 2. Problem Cause Solution One side of air cap (1) dirty or clogged Clean air cap orifices. See page 3. Blow air through orifices until clean.

  • Page 5: Air Cap, Nozzle, And Needle

    Sound Power 82.88 dB(A) 3. Remove air valve shaft (8). Air Consumption 4. Remove fitting (17) with Allen wrench (FX100: 8 mm, FX100 4.9 cfm at 29 psi (200 kPa, 2 bar) FX200 11.9 cfm at 41 psi (283 kPa, 2.8 bar) FX200/300: 9 mm).
  • Page 6 FINEX HVLP AND CONVENTIONAL SPRAY GUNS Parts Lid Kits (include 5 lid gaskets) FX100 - Part No. 248752 Gun Model Lid Gasket Ref. No. Part No. Description Qty. FX100 15F402 253418 15E392 Air Cap FX200/300 15F403 253417 15E393 Fluid Nozzle, 1.0...

  • Page 7: Installation

    II 2 G Réfé- Diamètre Pression d’arrivée rence pointeau/ Pression d’air de d’air maximale Modèle buse service maximum conseillée FX100 100 psi 29 psi 248752 (0,7 MPa, 7 bars) (0,20 MPa, 2,0 bars)* Mini-HVLP 248753 FX200 100 psi 60 psi 248754...
  • Page 8 MISE EN GARDE DANGERS D’INCENDIE ET D’EXPLOSION Les vapeurs inflammables, vapeurs de solvant et de peinture par exemple, sur le lieu de travail peuvent s’enflammer ou exploser. Pour prévenir un incendie ou une explosion: • N’utiliser l’équipement que dans des locaux bien ventilés. •...

  • Page 9: Réglage Du Jet

    Effectuer des passes lisses et égales se recouvrant d’env. 50 %. • Pistolets FX100 et FX300 HVLP : adopter un mouvement de la main légèrement plus lent et faire moins de passes qu’avec un pistolet à air classique. Éviter les coulures.

  • Page 10: Guide De Dépannage

    PISTOLETS FINEX HVLP ET CLASSIQUES FINEX HVLP AND CONVENTIONAL SPRAY GUNS Guide de dépannage MISE EN GARDE Suivre la Procédure de décompression, page 7, avant tout dépannage ou entretien. Lire les mises en garde, page 8. Problème Cause Solution Un côté du chapeau d’air (1) est sale ou bouché...

  • Page 11: Entretien

    FX200 Pression sonore 79,01 dB(A) Enlever l’axe (8) de la vanne d’air. Puissance sonore 88,91 dB(A) Démonter le raccord (17) avec une clé Allen (FX100 : 8 mm, FX300 Pression sonore 72,98 dB(A) FX200/300 : 9 mm). Puissance sonore 82,88 dB(A) Consommation d’air...
  • Page 12 PISTOLETS FINEX HVLP ET CLASSIQUES FINEX HVLP AND CONVENTIONAL SPRAY GUNS Pièces FX100 - Réf. 248752 Kits pour couvercle (avec 5 joints de couvercle) Ref. No. Part No. Description Qty. Modèle de Cou- Joint de 15E392 Air Cap pistolet vercle...

  • Page 13: Puesta En Marcha

    Presión máxima Presión máxima Ref. aguja/ de funciona- de entrada de aire Modelo pieza boquilla miento del aire recomendada FX100 100 psi 29 psi 248752 (0,7 MPa, 7 bar) (0,20 MPa, 2,0 bar)* Mini-HVLP 248753 FX200 100 psi 60 psi...

  • Page 14: Garantía Limitada De 1 Año

    ADVERTENCIA PELIGRO DE INCENDIOS Y EXPLOSIONES Vapores inflamables, como los vapores de disolvente o de pintura en la zona de trabajo pueden incendiarse o explotar. Para evitar un incendio o explosión: • Utilice el equipo únicamente en áreas bien ventiladas. •...

  • Page 15: Ajuste Del Chorro De Pulverización

    Utilice pasadas uniformes y suaves, con una superposición aproximada del 50%. • Pistolas HVLP FX100 y FX300: Utilice un movimiento de las manos ligeramente más lento y dé menos pasadas para cubrir la pieza que cuando utilice una pistola de pulverización convencional.

  • Page 16: Localización De Averías

    PISTOLAS DE PULVERIZACIÓN FINEX HVLP Y CONVENCIONALES FINEX HVLP AND CONVENTIONAL SPRAY GUNS Localización de averías ADVERTENCIA Siga Procedimiento de descompresión, página 13, antes de realizar la localización de averías o revisar el equipo. Lea las advertencias, página 14. Problema Causa Solución...

  • Page 17: Características Técnicas

    Potencia de sonido 88,91 dB(A) Retire el eje de la válvula de aire (8). FX300 Presión de sonido 72,98 dB(A) Retire el racor (17) con la llave Allen (FX100: 8 mm, Potencia de sonido 82,88 dB(A) FX200/300: 9 mm). Consumo de aire Retire las juntas tóricas (13, 10) y el soporte (9) del...
  • Page 18 PISTOLAS DE PULVERIZACIÓN FINEX HVLP Y CONVENCIONALES FINEX HVLP AND CONVENTIONAL SPRAY GUNS Piezas Kits de tapa FX100 – Ref. pieza 248752 (incluye 5 juntas para la tapa) Ref. No. Part No. Description Qty. Modelo de Junta 15E392 Air Cap...

This manual is also suitable for:

Fx300Fx200
