Instruction Manual for the
Start - Stop
PEDAL POWER
PC PEDAL CONTROL SYSTEM
VERSION 2.2 -With Pedal Release Actions
HTH Engineering, Inc. 825 Cypress Trail Dr. Tarpon Springs, FL 34688
TEL: (727) 939 8853 FAX: (810) 821-6940
http://www.startstop.com
Perform foot-pedal activation of any keystroke, keystroke
sequence, or mouse click action using any PC (laptop
portable or desktop) running Windows
95/98/NT/ME/2000/XP equipped with a serial port. Use
your feet to activate up to 3 separate pedals and their
corresponding keystroke functions
Copyright 2003 All Rights Reserved, HTH Engineering, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pedal Power and is the answer not in the manual?

Questions and answers

Summary of Contents for Start-Stop Pedal Power

  • Page 1 Instruction Manual for the Start - Stop PEDAL POWER PC PEDAL CONTROL SYSTEM VERSION 2.2 -With Pedal Release Actions HTH Engineering, Inc. 825 Cypress Trail Dr. Tarpon Springs, FL 34688 TEL: (727) 939 8853 FAX: (810) 821-6940 http://www.startstop.com Perform foot-pedal activation of any keystroke, keystroke...

  • Page 2: Features Include

    CONGRATULATIONS! Thank you for purchasing the Start Stop PEDAL POWER (SSPP) System. FEATURES INCLUDE: Perform foot-pedal activation of any keystroke, keystroke sequence, or mouse click action using any PC (laptop portable or desktop) running Windows ™ and equipped with a serial port.
  • Page 3 -A PC (laptop, portable or desktop) running Windows 95 ™ -An unused, standard DB-9 serial port on your PC: WHAT IS INCLUDED WITH YOUR SSPP : Description Start Stop PEDAL POWER pedal Start Stop Pedal Power Software Package, on CD-ROM Instruction Manual (this manual)

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS 1) Make sure your PC has a working serial port 2) Insert Setup Disk into your CD-ROM drive (normally drive “D:”, but this may depend on your computer. 3) From the Windows START button, select RUN 4) Type “d:\setup.exe”in the white box, and select “OK” 5) Follow the instructions on the screen when the program requests it 6) The SSPP Software will be launched whenever you double-click on its desktop icon...
  • Page 5 pedal to animate (move) in sync with your foot. If no pedals move, then try COM2: from the Configure COM Port menu. Once you have found the port, the SSPP will “remember” that port forever, until you change it again. 10) Select Configure from the menu, then Pedal Functions.
  • Page 6 11) The Pedal Function menu allows you to assign a pedal to any keystroke or mouse action. . You can also enter any keystroke sequence in the top "keystroke action" boxes. For instance, pressing Pedal #1 could cause your computer to print "Hello how are you?"...
  • Page 7 APPENDIX “A” Programming Combination or Multiple Keystrokes Pedal Function Progra mming Guidelines -------------------------------------------------- To program your own pedal functions use the following programming guidelines. The foot pedals can be used to emulate keyboard characters being pressed in an application, including shortcut key sequences, etc. To emulate keyboard character sequences follow the programming instructions below.
  • Page 8 parentheses. For example, to specify to hold down SHIFT while E and C are pressed, use "+(EC)". To specify to hold down SHIFT while E is pressed, followed by C without SHIFT, use "+EC". Remember that most shortcut keys are lower case. To specify characters that aren't displayed when you press a key (such as ENTER or TAB) and keys that represent actions rather than characters, use the codes shown below:...
  • Page 9 {F10} {F11} {F12} {F13} {F14} {F15} {F16} To specify repeating keys, use the form {key number}. You must put a space between key and number. For example, {LEFT 42} means press the LEFT ARROW key 42 times; {h 10} means press h 10 times. Note: The SSPP is designed to work with Windows applications only - it will not work with non-windows (DOS) applications.

  • Page 10: Fcc Notice

    FCC NOTICE This device is subject to the FCC Type 15 Class B radio frequency standards for computing devices. This device has been fully tested to meet FCC Type 15 requirements by an approved independent testing laboratory, but has not been officially certified by the FCC. TECH SUPPORT: Please visit http://www.startstop.com/techsupport.asp And click on Email Tech Support.
  • Page 11 The unit will be repaired or replaced, at seller’s discretion. No other warranties are expressed or implied. Seller accepts no liability for fitness for use in intended application. Liability is limited strictly to the purchase price of the unit. NOTES - Specifications subject to change without notice.
