Trieste ED-BF115L Instruction Manual

1.Name of parts 1.Name of parts
Bar Fridge
ED-BF115L ED-BF115L
INSTRUCTION MANUAL INSTRUCTION MANUAL
CK-A01
2.Correct positioning 2.Correct positioning
Clearance space required for ventilation
PARTS AND FEATURES
Ventilation is required around the refrigerator to
help with the dissipation of heat, operate at
maximum efficiency and at lower power consumption.
The recommended clearance space should be at least
12 11
10
100mm for all sides and 200mm from the top.
1
2
3
Power Supply
9
4
The refrigerator is designed to only operate on a
5
power supply of 220/240 volts 50 hertz. Please
6 make sure it is connected to a power point with
the correct earthed three-point socket.
7
8
Power Line Cord
The power cord should not be lengthened or
Cabinet
folded while in operation. Please make sure
Evaporator Compartment
that the cord is accessible and any excess cord
is kept close to the compressor at the back of
Drip Tray
the refrigerator. Make sure that the power
Shelf
cord isn't damaged before plugging into power
socket.
Glass cover
Compressor(back)
Crisper box
Leveling Legs
Protection from Moisture
Bottle Racks
Avoid placing the refrigerator in places where
heavy moisture is present. This is to minimise
10 10 Recessed Handle
the possibility of rust to any metal parts.
Door switch
11 11
Temperature Control Knob
12 12
1
2.Correct Positioning 2.Correct Positioning
Protection from Heat
The refrigerator should not be placed near
any kind of heat source or in direct sunlight.
Stable positioning
¡À ¡À
Please ensure that the refrigerator is placed
on a flat, solid floor. It should not be placed
¡À ¡À
on any soft surface. If the refrigerator is not
on a stable surface adjust the feet on the bottom.
(+220-240)V~
+ _ 10%
50Hz
10%
230V~
60Hz
Keep Away from Danger
Do not place the refrigerator near combustible
or flammable substances such as, gas, petrol,
N N
alcohol, lacquer or oils.
Moving
When moving or relocating the refrigerator,
to try avoid having the refrigerator tilt more
than 45 degrees. At no point should the
refrigerator be turned upside down.
3.Cautions 3.Cautions
Water contained in food or getting into air inside the refrigerator by
opening doors may form a layer of frost inside, It will weaken the
refrigerator when the frost is thick, while it is more than 2mm thick,
you should defrost.
Defrosting in freezer chamber is operated manually. Before defrosting,
take the food, the ice tray and the shelf out into the cold storing
chamber temporarily then set the knob of the temperature regulator
to position"0"(where the compressor will stop working) and leave the
door open until ice and frost dissolve thoroughly deposited at the
bottom drip tray of the freezer chamber. Take out the drip tray and
discard the water carefully. In the case of speeding up the defrosting,
you may put a bowl of warm water (about 50 ) into the freezer
chamber, and be sure to set the knob of the temperature regulator to
original position after defrosting.
It's inadvisable to heat the freezer chamber directly with hot water
or hair dryer while defrosting to prevent deformation of the inner
case.
It's also inadvisable to scrape of ice and frost or separate food from the
containers which have been congealed together with the food with
sharp tool or wooden bars, so as not to damage the inner casing or
the surface of the evaporator.
If the supply cord of this appliance is damaged, it must only be
replaced by a repair shop appointed by the manufacturer,
because special purpose tools are required.
