Mini Radio Instructions
FM/AM Digital Display Radio with Clock
12
11
13
16
1
2
10
9
8
Apperance Diagram
& Function Indication
1) Display screen
2) Tuning indicator
3) Hour adjustment button
3
4) Minute adjustment button
4
5) Tuner
6) Alarm function button
5
7) Volume control
6
8) Time set button
9) Alarm time button
7
10) Power OFF button
11) AM button
12) FM button
13) Telescopic Antenna
14) Hand belt
15) Earphone jack
16) Battery slot
Technical index
1) Frequency range
FM 87-108 MHz
MW 526.5-1606.5 KHz
2) Sensitivity
FM ) 2 0µV
MW ) 5 V/m
14
3) Single-signal Selectivity 10dB
4) Power: DC 3V battery x2 AAA
15
1.5V (not supplied)
5) Speaker: ø4mm/4 1 /0.25W
6) Earphone: ø3.5mm 32 1
7) Unit size: 92 x 54 x 20mm
8) Weight: 82g (without battery)
6975
Advertisement
Table of Contents
Related Manuals for Coopers Mini Radio 6975
Summary of Contents for Coopers Mini Radio 6975
- Page 1 Mini Radio Instructions 6975 FM/AM Digital Display Radio with Clock Apperance Diagram & Function Indication 1) Display screen 2) Tuning indicator 3) Hour adjustment button 4) Minute adjustment button 5) Tuner 6) Alarm function button 7) Volume control 8) Time set button 9) Alarm time button 10) Power OFF button 11) AM button...
- Page 2 8 7 6 Use Antenna 1) To receive MW stations the radio uses the internal magnetic antenna, you can adjust the reception by rotating the radio. LCD Explanation 1) FM Frequency unit indication 2) AM Frequency unit indication 2) To receive FM stations use the telescopic antenna on top 3) Frequency or time indication of the radio, to get the best results change the length and 4) Alarm indication...
